AT45D DataFlash defines. More...

#include <sys/types.h>
#include <stdint.h>

Include dependency graph for at45d.h:

This graph shows which files directly or indirectly include this file:

Data Structures
struct	_AT45D_INFO
	AT45D DataFlash parameter structure. More...
Typedefs
typedef CONST struct _AT45D_INFO	AT45D_INFO
	AT45D DataFlash parameter structure type.
Variables
AT45D_INFO	at45d_info []
	Table of known AT45D DataFlash chips.
uint_fast8_t	at45d_known_types
	Number of known AT45D DataFlash chips.
AT45D DataFlash Commands
#define	DFCMD_CONT_READ_LF 0x03
	Continuos read (low frequency).
#define	DFCMD_CONT_READ_HF 0x0B
	Continuos read (high frequency).
#define	DFCMD_BLOCK_ERASE 0x50
	Block erase.
#define	DFCMD_SECTOR_ERASE 0x7C
	Sector erase.
#define	DFCMD_PAGE_ERASE 0x81
	Page erase.
#define	DFCMD_BUF1_PROG 0x82
	Main memory page program through buffer 1.
#define	DFCMD_BUF1_FLASH 0x83
	Buffer 1 flash with page erase.
#define	DFCMD_BUF1_WRITE 0x84
	Buffer 1 write.
#define	DFCMD_BUF2_PROG 0x85
	Main memory page program through buffer 2.
#define	DFCMD_BUF2_FLASH 0x86
	Buffer 2 flash with page erase.
#define	DFCMD_BUF2_WRITE 0x87
	Buffer 2 write.
#define	DFCMD_BUF1_FLASH_NE 0x88
	Buffer 1 flash without page erase.
#define	DFCMD_BUF2_FLASH_NE 0x89
	Buffer 2 flash without page erase.
#define	DFCMD_CHIP_ERASE 0xC7
	Chip erase.
#define	DFCMD_BUF1_READ_LF 0xD1
	Buffer 1 read (low frequency).
#define	DFCMD_READ_PAGE 0xD2
	Read main memory page.
#define	DFCMD_BUF2_READ_LF 0xD3
	Buffer 2 read (low frequency).
#define	DFCMD_BUF1_READ 0xD4
	Buffer 1 read.
#define	DFCMD_BUF2_READ 0xD6
	Buffer 2 read.
#define	DFCMD_READ_STATUS 0xD7
	Read status register.
#define	DFCMD_CONT_READ 0xE8
	Continuos read (legacy).
AT45D DataFlash Status Bits
#define	AT45D_STATUS_RDY 0x80
	Ready (not busy) flag.
#define	AT45D_STATUS_COMP 0x40
	Last compare result.
#define	AT45D_STATUS_DENSITY 0x3C
	Device type code.
#define	AT45D_STATUS_PROTECT 0x02
	Sector protection flag.
#define	AT45D_STATUS_PAGE_SIZE 0x01
	Set when binary page size is configured.

Detailed Description

AT45D DataFlash defines.

 * $Id: at45d.h 3653 2011-11-14 15:20:31Z haraldkipp $
 *

Definition in file at45d.h.

Define Documentation

#define DFCMD_CONT_READ_LF 0x03

Continuos read (low frequency).

Reads a continous stream in low speed mode. Automatically switches to the the page and wraps to the first page after the last has been read. Note, that the data buffers are not used for this operation.

Definition at line 59 of file at45d.h.

#define DFCMD_CONT_READ_HF 0x0B

Continuos read (high frequency).

Reads a continous stream in high speed mode. Automatically switches to the the page and wraps to the first page after the last has been read. Note, that the data buffers are not used for this operation.

Definition at line 67 of file at45d.h.

#define DFCMD_BLOCK_ERASE 0x50

Block erase.

Definition at line 71 of file at45d.h.

#define DFCMD_SECTOR_ERASE 0x7C

Sector erase.

Definition at line 75 of file at45d.h.

#define DFCMD_PAGE_ERASE 0x81

Page erase.

Definition at line 79 of file at45d.h.

Referenced by SpiAt45dPageErase().

#define DFCMD_BUF1_PROG 0x82

Main memory page program through buffer 1.

Definition at line 83 of file at45d.h.

#define DFCMD_BUF1_FLASH 0x83

Buffer 1 flash with page erase.

Definition at line 87 of file at45d.h.

Referenced by SpiAt45dPageWrite().

#define DFCMD_BUF1_WRITE 0x84

Buffer 1 write.

Definition at line 91 of file at45d.h.

Referenced by SpiAt45dPageWrite().

#define DFCMD_BUF2_PROG 0x85

Main memory page program through buffer 2.

Definition at line 94 of file at45d.h.

#define DFCMD_BUF2_FLASH 0x86

Buffer 2 flash with page erase.

Definition at line 98 of file at45d.h.

#define DFCMD_BUF2_WRITE 0x87

Buffer 2 write.

Definition at line 102 of file at45d.h.

#define DFCMD_BUF1_FLASH_NE 0x88

Buffer 1 flash without page erase.

Definition at line 106 of file at45d.h.

#define DFCMD_BUF2_FLASH_NE 0x89

Buffer 2 flash without page erase.

Definition at line 110 of file at45d.h.

#define DFCMD_CHIP_ERASE 0xC7

Chip erase.

Definition at line 113 of file at45d.h.

#define DFCMD_BUF1_READ_LF 0xD1

Buffer 1 read (low frequency).

Definition at line 117 of file at45d.h.

#define DFCMD_READ_PAGE 0xD2

Read main memory page.

Automatically wraps to the first byte of the same page after the last byte had been read. The data buffers are left unchanged.

Definition at line 124 of file at45d.h.

#define DFCMD_BUF2_READ_LF 0xD3

Buffer 2 read (low frequency).

Definition at line 128 of file at45d.h.

#define DFCMD_BUF1_READ 0xD4

Buffer 1 read.

Definition at line 132 of file at45d.h.

#define DFCMD_BUF2_READ 0xD6

Buffer 2 read.

Definition at line 136 of file at45d.h.

#define DFCMD_READ_STATUS 0xD7

Read status register.

Definition at line 140 of file at45d.h.

Referenced by At45dNodeStatus().

#define DFCMD_CONT_READ 0xE8

Continuos read (legacy).

Reads a continous stream. Automatically switches to the the page and wraps to the first page after the last has been read. Note, that the data buffers are not used for this operation.

Definition at line 148 of file at45d.h.

Referenced by SpiAt45dPageRead().

#define AT45D_STATUS_RDY 0x80

Ready (not busy) flag.

Definition at line 157 of file at45d.h.

#define AT45D_STATUS_COMP 0x40

Last compare result.

Definition at line 159 of file at45d.h.

#define AT45D_STATUS_DENSITY 0x3C

Device type code.

Definition at line 161 of file at45d.h.

Referenced by At45dNodeProbe(), and SpiAt45dInit().

#define AT45D_STATUS_PROTECT 0x02

Sector protection flag.

Definition at line 163 of file at45d.h.

#define AT45D_STATUS_PAGE_SIZE 0x01

Set when binary page size is configured.

Definition at line 165 of file at45d.h.

Referenced by At45dNodeProbe(), and SpiAt45dInit().

Typedef Documentation

typedef CONST struct _AT45D_INFO AT45D_INFO

AT45D DataFlash parameter structure type.

Definition at line 172 of file at45d.h.
