External AVR device programming. More...
Go to the source code of this file.
Defines | |
#define | AVRTARGET_CHIPERASE_TIMEOUT 200 |
Maximum time (in milliseconds) to wait for chip erase done. | |
#define | AVRTARGET_PAGEWRITE_TIMEOUT 10 |
Maximum time (in milliseconds) to wait for page write done. | |
#define | AVR_FUSES_NEVER_PROG 0x00F88062UL |
Safe fuse programming mask. | |
#define | AVR_FUSES_ALWAYS_PROG 0x0000201DUL |
Safe fuse unprogramming mask. | |
#define | AVRTARGET_SPI_MODE 0 |
#define | AVRTARGET_SPI_RATE 500000 |
#define | AVRTARGET_NO_SPI_DEVICE |
Functions | |
int | AvrTargetInit (void) |
Initialize programming interface. | |
void | AvrTargetSelect (ureg_t act) |
Set or clear the chip select line. | |
void | AvrTargetReset (ureg_t act) |
Set or release the target's reset line. | |
uint32_t | AvrTargetCmd (uint32_t cmd) |
Send programming command and return response. | |
int | AvrTargetProgEnable (void) |
Enable target's programming mode. | |
uint32_t | AvrTargetSignature (void) |
Retrieve the target's signature. | |
uint32_t | AvrTargetFusesRead (void) |
Retrieve the target's fuses. | |
uint32_t | AvrTargetFusesWriteSafe (uint32_t fuses) |
Program the target's fuses in a safe way. | |
int | AvrTargetPollReady (unsigned int tmo) |
Poll target for becoming ready. | |
int | AvrTargetChipErase (void) |
Erase the target chip. | |
void | AvrTargetPageLoad (uint32_t page, CONST uint8_t *data) |
Load target's program memory page buffer. | |
int | AvrTargetPageWrite (uint32_t page) |
Write page buffer contents to program memory. | |
int | AvrTargetPageVerify (uint32_t page, CONST uint8_t *data) |
Verify program memory page contents. |
External AVR device programming.
Copyright (C) 2007 by egnite Software GmbH. All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. 2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. 3. Neither the name of the copyright holders nor the names of contributors may be used to endorse or promote products derived from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY EGNITE SOFTWARE GMBH AND CONTRIBUTORS ``AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL EGNITE SOFTWARE GMBH OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
For additional information see http://www.ethernut.de/
* * $Log$ * Revision 1.3 2009/01/17 11:26:46 haraldkipp * Getting rid of two remaining BSD types in favor of stdint. * Replaced 'u_int' by 'unsinged int' and 'uptr_t' by 'uintptr_t'. * * Revision 1.2 2008/08/11 06:59:41 haraldkipp * BSD types replaced by stdint types (feature request #1282721). * * Revision 1.1 2007/04/12 09:01:38 haraldkipp * New API allows to program external AVR devices. * * *
Definition in file avrtarget.c.
