Linked List. More...

Collaboration diagram for LiLi:

Data Structures
struct	_LILI_NODE
	Node object structure. More...
struct	_LILI
	List object structure. More...
Defines
#define	LiLiIsLifo(list) (((list)->lst_flags & LILI_F_ORDER) == LILI_F_LIFO)
	Return true if the given list is a last in, first out queue.
#define	LiLiIsFifo(list) (((list)->lst_flags & LILI_F_ORDER) == LILI_F_FIFO)
	Return true if the given list is a first in, first out queue.
#define	LiLiIsSorted(list) (((list)->lst_flags & LILI_F_ORDER) == LILI_F_SORT)
	Return true if the given list is sorted.
#define	LiLiIsEmpty(list) ((list)->lst_head == NULL)
	Return true if the given list is empty.
#define	LiLiHasUniqueItems(list) (((list)->lst_flags & LILI_F_UNIQUE) == LILI_F_UNIQUE)
	Return true if the given list has unique items only.
#define	LiLiFirstNode(list) ((list)->lst_head)
	Return the first node object of a given list.
#define	LiLiLastNode(list) ((list)->lst_tail)
	Return the last node object of a given list.
#define	LiLiNextNode(node) ((node)->nod_nxt)
	Return the next node object of a given node.
#define	LiLiPreviousNode(node) ((node)->nod_prv)
	Return the previous node object of a given node.
#define	LiLiNodeItem(node) ((node)->nod_itm)
	Return the item reference of a given node.
Typedefs
typedef intptr_t	LILI_ITEMREF
	Type of an item reference.
typedef LILI_ITEMREF(*	LiLiItemCreateFunc )(LILI_ITEMREF)
typedef void(*	LiLiItemDestroyFunc )(LILI_ITEMREF)
typedef int(*	LiLiItemCompareFunc )(LILI_ITEMREF, LILI_ITEMREF)
typedef struct _LILI_NODE	LILI_NODE
	Node object type.
typedef struct _LILI	LILI
	List object type.
Functions
void	LiLiRemoveNode (LILI list, LILI_NODE node)
	Remove a given node from the list.
LILI_NODE *	LiLiInsertItemAfterNode (LILI list, LILI_NODE node, LILI_ITEMREF ref)
LILI_NODE *	LiLiInsertItemBeforeNode (LILI list, LILI_NODE node, LILI_ITEMREF ref)
LILI *	LiLiCreate (uint8_t flags, LiLiItemCreateFunc icre, LiLiItemDestroyFunc ides, LiLiItemCompareFunc icmp)
	Create a linked list.
void	LiLiClean (LILI *list)
	Remove all items from a list.
void	LiLiDestroy (LILI *list)
	Destroy a linked list.
LILI_NODE *	LiLiLocateItem (LILI *list, LILI_ITEMREF ref)
	Find the node's location by a given item.
LILI_NODE *	LiLiFindItem (LILI *list, LILI_ITEMREF ref)
	Find the node of a given item.
int	LiLiPushItem (LILI *list, LILI_ITEMREF ref)
	Add an item to the list.
int	LiLiPopItem (LILI list, LILI_ITEMREF refp)
	Remove the next item from the list.
int	LiLiCompareStringItems (LILI_ITEMREF ref1, LILI_ITEMREF ref2)
	Compare two string items.
LILI_ITEMREF	LiLiCreateStringItemCopy (LILI_ITEMREF ref)
	Create a copy of a referenced string item.
void	LiLiDestroyStringItemCopy (LILI_ITEMREF ref)
	Destroy the string item copy.
int	LiLiNodes (LILI *list)
	Return the number of nodes in a given list.
List attribute flags
#define	LILI_F_LIFO 0x00
	Last in, first out queue.
#define	LILI_F_FIFO 0x01
	First in, first out queue.
#define	LILI_F_SORT 0x02
	Sorted list.
#define	LILI_F_ORDER 0x03
	List order mask.
#define	LILI_F_UNIQUE 0x80
	Allow unique items only.

Detailed Description

Linked List.

Define Documentation

#define LILI_F_LIFO 0x00

Last in, first out queue.

Definition at line 58 of file lili.h.

#define LILI_F_FIFO 0x01

First in, first out queue.

Definition at line 60 of file lili.h.

#define LILI_F_SORT 0x02

Sorted list.

Definition at line 62 of file lili.h.

#define LILI_F_ORDER 0x03

List order mask.

Definition at line 64 of file lili.h.

#define LILI_F_UNIQUE 0x80

Allow unique items only.

Definition at line 66 of file lili.h.

#define LiLiIsLifo ( list ) (((list)->lst_flags & LILI_F_ORDER) == LILI_F_LIFO)

Return true if the given list is a last in, first out queue.

Definition at line 102 of file lili.h.

#define LiLiIsFifo ( list ) (((list)->lst_flags & LILI_F_ORDER) == LILI_F_FIFO)

Return true if the given list is a first in, first out queue.

Definition at line 107 of file lili.h.

Referenced by LiLiPopItem().

#define LiLiIsSorted ( list ) (((list)->lst_flags & LILI_F_ORDER) == LILI_F_SORT)

Return true if the given list is sorted.

Definition at line 112 of file lili.h.

Referenced by LiLiFindItem(), and LiLiPushItem().

#define LiLiIsEmpty ( list ) ((list)->lst_head == NULL)

Return true if the given list is empty.

Definition at line 117 of file lili.h.

#define LiLiHasUniqueItems ( list ) (((list)->lst_flags & LILI_F_UNIQUE) == LILI_F_UNIQUE)

Return true if the given list has unique items only.

Definition at line 122 of file lili.h.

Referenced by LiLiPushItem().

#define LiLiFirstNode ( list ) ((list)->lst_head)

Return the first node object of a given list.

Definition at line 127 of file lili.h.

Referenced by LiLiFindItem(), LiLiLocateItem(), LiLiNodes(), LiLiPopItem(), and LiLiPushItem().

#define LiLiLastNode ( list ) ((list)->lst_tail)

Return the last node object of a given list.

Definition at line 132 of file lili.h.

Referenced by LiLiPopItem(), and LiLiPushItem().

#define LiLiNextNode ( node ) ((node)->nod_nxt)

Return the next node object of a given node.

Definition at line 137 of file lili.h.

Referenced by LiLiFindItem(), LiLiLocateItem(), and LiLiNodes().

#define LiLiPreviousNode ( node ) ((node)->nod_prv)

Return the previous node object of a given node.

Definition at line 142 of file lili.h.

#define LiLiNodeItem ( node ) ((node)->nod_itm)

Return the item reference of a given node.

Definition at line 147 of file lili.h.

Referenced by LiLiClean(), LiLiFindItem(), LiLiLocateItem(), LiLiPopItem(), and LiLiPushItem().

Typedef Documentation

typedef intptr_t LILI_ITEMREF

Type of an item reference.

Definition at line 70 of file lili.h.

typedef LILI_ITEMREF(* LiLiItemCreateFunc)(LILI_ITEMREF)

Definition at line 72 of file lili.h.

typedef void(* LiLiItemDestroyFunc)(LILI_ITEMREF)

Definition at line 73 of file lili.h.

typedef int(* LiLiItemCompareFunc)(LILI_ITEMREF, LILI_ITEMREF)

Definition at line 74 of file lili.h.

typedef struct _LILI_NODE LILI_NODE

Node object type.

Definition at line 77 of file lili.h.

typedef struct _LILI LILI

List object type.

Definition at line 87 of file lili.h.

Function Documentation

void LiLiRemoveNode	(	LILI *	list,
		LILI_NODE *	node
	)

Remove a given node from the list.

Special applications may use this function instead of LiLiPopItem().

The caller must make sure, that this node is a member of the specified list. After returning from this function, this pointer is no longer usable.

Note, that this call will not destroy the copy of an associated item object.

Parameters:

list	Pointer to a list object, obtained from a previous call to LiLiCreate().
node	Pointer to the node object to remove. Ignored if NULL.

Definition at line 107 of file lili.c.

References free(), _LILI::lst_head, _LILI::lst_tail, _LILI_NODE::nod_nxt, _LILI_NODE::nod_prv, and NUTASSERT.

Referenced by LiLiPopItem().

Here is the call graph for this function:

LILI_NODE* LiLiInsertItemAfterNode	(	LILI *	list,
		LILI_NODE *	node,
		LILI_ITEMREF	ref
	)

Definition at line 147 of file lili.c.

References _LILI::lst_head, _LILI::lst_icreate, _LILI::lst_tail, malloc(), _LILI_NODE::nod_itm, _LILI_NODE::nod_nxt, _LILI_NODE::nod_prv, and NUTASSERT.

Referenced by LiLiPushItem().

Here is the call graph for this function:

LILI_NODE* LiLiInsertItemBeforeNode	(	LILI *	list,
		LILI_NODE *	node,
		LILI_ITEMREF	ref
	)

Definition at line 194 of file lili.c.

References _LILI::lst_head, _LILI::lst_icreate, _LILI::lst_tail, malloc(), _LILI_NODE::nod_itm, _LILI_NODE::nod_nxt, _LILI_NODE::nod_prv, and NUTASSERT.

Referenced by LiLiPushItem().

Here is the call graph for this function:

LILI* LiLiCreate	(	uint8_t	flags,
		LiLiItemCreateFunc	icre,
		LiLiItemDestroyFunc	ides,
		LiLiItemCompareFunc	icmp
	)

Create a linked list.

Parameters:

flags	Attribute flags, either LILI_F_LIFO for a last-in first-out queue, LILI_F_FIFO for a first-in first-out queue, or LILI_F_SORT for a sorted list. Any of them may be or'ed with the attribute flag LILI_F_UNIQUE to avoid duplicate entries.
icre	Pointer to a function, which is called to create an item for adding to the list. If NULL, the item reference itself is used in the list. See LiLiCreateStringItemCopy().
ides	Pointer to a function, which is called to destroy an item. Set to NULL, if the item reference is used in the list. See LiLiDestroyStringItemCopy().
icmp	Pointer to a function, which is called to compare items. If NULL, the item reference values are directly compared. See LiLiCompareStringItems().

Returns:: Pointer to a list object on success, otherwise a NULL pointer is returned.

Definition at line 247 of file lili.c.

References calloc, _LILI::lst_flags, _LILI::lst_icompare, _LILI::lst_icreate, and _LILI::lst_idestroy.

void LiLiClean ( LILI * list )

Remove all items from a list.

This function will not release the list object. Use LiLiDestroy() to release the complete list.

Parameters:

list	Pointer to a list object, obtained from a previous call to LiLiCreate().

Definition at line 273 of file lili.c.

References free(), LiLiNodeItem, _LILI::lst_head, _LILI::lst_idestroy, _LILI::lst_tail, _LILI_NODE::nod_nxt, and NUTASSERT.

Referenced by LiLiDestroy().

Here is the call graph for this function:

void LiLiDestroy ( LILI * list )

Destroy a linked list.

This function will remove all nodes, destroy item object copies and finally destroy the list object.

Parameters:

list	Pointer to a list object to destroy, obtained from a previous call to LiLiCreate(),

Definition at line 301 of file lili.c.

References free(), and LiLiClean().

Here is the call graph for this function:

LILI_NODE* LiLiLocateItem	(	LILI *	list,
		LILI_ITEMREF	ref
	)

Find the node's location by a given item.

Like LiLiFindItem(), but returns the first node of which the item is larger than the given item. This function is useful for sorted lists only.

Parameters:

list	Pointer to a list object, obtained from a previous call to LiLiCreate().
ref	Reference of the item to search for.

Returns:: Pointer to the node, or NULL if no node was found.

Definition at line 66 of file lpushpop.c.

References LiLiFirstNode, LiLiNextNode, LiLiNodeItem, _LILI::lst_icompare, and NUTASSERT.

Referenced by LiLiPushItem().

LILI_NODE* LiLiFindItem	(	LILI *	list,
		LILI_ITEMREF	ref
	)

Find the node of a given item.

Like LiLiLocateItem(), but searches for an exact match. If the list is unsorted, all nodes will be scanned.

Parameters:

list	Pointer to a list object, obtained from a previous call to LiLiCreate().
ref	Reference of the item to search for.

Returns:: Pointer to the node, or NULL if no node was found.

Definition at line 93 of file lpushpop.c.

References LiLiFirstNode, LiLiIsSorted, LiLiNextNode, LiLiNodeItem, _LILI::lst_icompare, and NUTASSERT.

Referenced by LiLiPushItem().

int LiLiPushItem	(	LILI *	list,
		LILI_ITEMREF	ref
	)

Add an item to the list.

In most cases this function will be used by applications to add new items to a list.

If the attribute LILI_F_SORT has been set when creating the list, then a node will be inserted before the first node, of which the item is larger or equal than the given one.

If the attribute LILI_F_UNIQUE has been set and if a node with the same item is already a member of the list, then no new node will be added. This adds significant overhead to LIFO and FIFO queues.

Parameters:

list	Pointer to a list object, obtained from a previous call to LiLiCreate().
ref	The item's reference. If a function for creating an item has been specified, if will be called before inserting a new node.

Returns:: 0 if a new node had been successfully added or of the given item already exists in a unique list. On errors, -1 is returned.

Definition at line 137 of file lpushpop.c.

References LiLiFindItem(), LiLiFirstNode, LiLiHasUniqueItems, LiLiInsertItemAfterNode(), LiLiInsertItemBeforeNode(), LiLiIsSorted, LiLiLastNode, LiLiLocateItem(), LiLiNodeItem, _LILI::lst_icompare, and NUTASSERT.

Here is the call graph for this function:

int LiLiPopItem	(	LILI *	list,
		LILI_ITEMREF *	refp
	)

Remove the next item from the list.

Parameters:

list	Pointer to a list object, obtained from a previous call to LiLiCreate().
refp	Pointer that receives the item's reference of the removed node. If a copy of the item object has been created during list insertion, then the caller is responsible for destroying it.

Returns:: -1 if the list is empty, otherwise 0 is returned.

Definition at line 191 of file lpushpop.c.

References LiLiFirstNode, LiLiIsFifo, LiLiLastNode, LiLiNodeItem, LiLiRemoveNode(), and NUTASSERT.

Here is the call graph for this function:

int LiLiCompareStringItems	(	LILI_ITEMREF	ref1,
		LILI_ITEMREF	ref2
	)

Compare two string items.

A pointer to this function can be passed to LiLiCreate(), if the items of a sorted list are simple strings.

Parameters:

ref1	Reference of the first string.
ref2	Reference of the second string.

Returns:: An integer less than, equal to, or greater than zero, if the first string is less than, equal, or greater than the second string, resp.

Definition at line 65 of file lstrcmp.c.

References strcmp().

Here is the call graph for this function:

LILI_ITEMREF LiLiCreateStringItemCopy ( LILI_ITEMREF ref )

Create a copy of a referenced string item.

A pointer to this function can be passed to LiLiCreate(), if the list items are simple strings.

Note, that the result is not checked during list insertion. If not enough memory is available to create a copy, then a reference value of zero is stored in the node object.

Parameters:

ref	Reference of the original string. Actually this is a pointer to the string. If 0, no copy is created.

Returns:: Reference of a successfully created copy, otherwise 0.

Definition at line 70 of file lstrcopy.c.

References strdup().

Here is the call graph for this function:

void LiLiDestroyStringItemCopy ( LILI_ITEMREF ref )

Destroy the string item copy.

A pointer to this function can be passed to LiLiCreate(), if the list items are simple strings.

Parameters:

ref	Reference of the string copy to destroy. Ignored if 0.

Definition at line 86 of file lstrcopy.c.

References free().

Here is the call graph for this function:

int LiLiNodes ( LILI * list )

Return the number of nodes in a given list.

Use LiLiIsEmpty(), if you need a simple check for an empty list.

Parameters:

list	Pointer to a list object, obtained from a previous call to LiLiCreate().

Returns:: The number of nodes.

Definition at line 63 of file lutil.c.

References LiLiFirstNode, LiLiNextNode, and NUTASSERT.

Data Structures

Defines

Typedefs

Functions

List attribute flags

Detailed Description

Define Documentation

Typedef Documentation

Function Documentation
