Block device driver for MM/SD Cards. More...

Collaboration diagram for Multimedia Card Driver:

Data Structures
struct	_MEMCARDSUPP
	Memory card support structure. More...
struct	_MMCIFC
	Low level access information structure. More...
struct	_MMC_CID
	Multimedia card identification register. More...
struct	_MMC_CSD
	Multimedia card identification register. More...
struct	_MMCFCB
	Local multimedia card mount information. More...
Defines
#define	NUTMC_SF_CD 0x01
#define	NUTMC_SF_WP 0x02
#define	NUTMC_IND_OFF 0
#define	NUTMC_IND_READ 1
#define	NUTMC_IND_WRITE 2
#define	NUTMC_IND_ERROR 4
#define	MMCMD_HOST 0x40
#define	MMCMD_RESET_CRC 0x95
#define	MMCMD_GO_IDLE_STATE 0
	Reset card to idle state.
#define	MMCMD_SEND_OP_COND 1
	Activate card's initialization process.
#define	MMCMD_ALL_SEND_CID 2
	Send operation condition register.
#define	MMCMD_SEND_RELATIVE_ADDR 3
	Assign relative card address.
#define	MMCMD_SELECT_CARD 7
	Assign relative card address.
#define	MMCMD_SEND_EXTCSD 8
	Query card's extended CSD.
#define	MMCMD_SEND_CSD 9
	Query card's CSD.
#define	MMCMD_SEND_CID 10
	Query card's CID.
#define	MMCMD_STOP_TRANSMISSION 12
	Stop multiple block transmission.
#define	MMCMD_SEND_STATUS 13
	Query card's status register.
#define	MMCMD_SET_BLOCKLEN 16
	Select block length for following read/write commands.
#define	MMCMD_READ_SINGLE_BLOCK 17
	Initiate single block read.
#define	MMCMD_READ_MULTIPLE_BLOCK 18
	Initiate continuous block read.
#define	MMCMD_WRITE_BLOCK 24
	Initiate single block write.
#define	MMCMD_WRITE_MULTIPLE_BLOCK 25
	Initiate continuous block write.
#define	MMCMD_PROGRAM_CSD 27
	Initiate programming of programmable CSD bits.
#define	MMCMD_SET_WRITE_PROTECT 28
	Enable card's optional write protection.
#define	MMCMD_CLR_WRITE_PROTECT 29
	Disable card's write protection.
#define	MMCMD_SEND_WRITE_PROTECT 30
	Query card's write protect status.
#define	MMCMD_TAG_ERASE_GROUP_START 35
	Set address of the first erase group.
#define	MMCMD_TAG_ERASE_GROUP_END 36
	Set address of the last erase group.
#define	MMCMD_ERASE 38
	Erase previously selected sectors.
#define	MMCMD_SEND_APP_OP_COND 41
	Activate SD card's initialization process.
#define	MMCMD_LOCK_UNLOCK 42
	Set/clear password or lock/unlock the card.
#define	MMCMD_SEND_APP_CMD 55
	Application command follows.
#define	MMCMD_READ_OCR 58
	Query card's operating condition register.
#define	MMCMD_CRC_ON_OFF 59
	Enable or disable CRC mode.
#define	MMR1_IDLE_STATE 0x00
	Card is idle.
#define	MMR1_NOT_IDLE 0x01
	Card is busy.
#define	MMR1_ERASE_RESET 0x02
	Erase sequence was cleared before execution.
#define	MMR1_ILLEGAL_COMMAND 0x04
	Illegal command code detected.
#define	MMR1_COM_CRC_ERROR 0x08
	Bad command CRC detected.
#define	MMR1_ERASE_SEQ_ERROR 0x10
	Bad erase sequence.
#define	MMR1_ADDRESS_ERROR 0x20
	Misaligned address did not match block length.
#define	MMR1_PARAMETER_ERROR 0x40
	Command parameter is out of range.
#define	MMR2_CARD_LOCKED 0x01
	Card is locked.
#define	MMR2_WP_ERASE_SKIP 0x02
	Erasing write protected sector or password error.
#define	MMR2_ERROR 0x04
	General or unknown error occured.
#define	MMR2_CC_ERROR 0x08
	Internal card controller error.
#define	MMR2_ECC_FAILED 0x10
	Bad internal ECC.
#define	MMR2_WP_VIOLATION 0x20
	Failed to write to protected block.
#define	MMR2_ERASE_PARAMETER 0x40
	Invalid erase parameter.
#define	MMR2_OUT_OF_RANGE 0x80
	Command parameter is out of range.
#define	MMCSR_OUT_OF_RANGE 0x80000000
#define	MMCSR_ADDRESS_ERROR 0x40000000
#define	MMCSR_BLOCK_LEN_ERROR 0x20000000
#define	MMCSR_ERASE_SEQ_ERROR 0x10000000
#define	MMCSR_ERASE_PARAM 0x08000000
#define	MMCSR_WP_VIOLATION 0x04000000
#define	MMCSR_COM_CRC_ERROR 0x00800000
#define	MMCSR_ILLEGAL_COMMAND 0x00400000
#define	MMCSR_ERROR 0x00080000
#define	MMCSR_CIDCSD_OVERWRITE 0x00010000
#define	MMCSR_WP_ERASE_SKIP 0x00008000
#define	MMCSR_CARD_ECC_DISABLED 0x00004000
#define	MMCSR_ERASE_RESET 0x00002000
#define	MMCSR_STATE_MASK 0x00001E00
#define	MMCSR_READY_FOR_DATA 0x00000100
#define	MMCSR_IS_IDLE 0x00000000
#define	MMCSR_IS_READY 0x00000200
#define	MMCSR_IS_IDENT 0x00000400
#define	MMCSR_IS_STBY 0x00000600
#define	MMCSR_IS_TRAN 0x00000800
#define	MMCSR_IS_DATA 0x00000A00
#define	MMCSR_IS_RCV 0x00000C00
#define	MMCSR_IS_PRG 0x00000E00
#define	MMCSR_IS_DIS 0x00001000
#define	MMDR_ACCEPTED
#define	MMDR_CRC_ERROR
#define	MMDR_WRITE_ERROR
#define	MMCERR_TIMEOUT 0x00000001
#define	MMCOP_NBUSY 0x80000000
#define	MMCARD_CIDR_SIZE 16
	Number of bytes in the CID register.
#define	MMCARD_CSDR_SIZE 16
	Number of bytes in the CSD register.
#define	MMCARD_OCR_SIZE 32
	Number of bytes in the operating condition register.
#define	MMC_BLOCK_SIZE 512
	Block size.
#define	MMC_MAX_INIT_POLLS 512
	Card init timeout.
#define	MMC_MAX_RESET_POLLS 255
	Card reset timeout.
#define	MMC_MAX_WRITE_POLLS 1024
	Card write timeout.
#define	MMC_MAX_WRITE_RETRIES 32
	Card write retries.
#define	MMC_MAX_READ_RETRIES 8
	Card read retries.
#define	MMC_MAX_REG_POLLS 512
	Register read timeout.
#define	MMC_MAX_CMDACK_POLLS 1024
	Command acknowledge timeout.
#define	MMC_MAX_R1_POLLS 1024
	R1 response timeout.
#define	MMC_BLOCK_SIZE 512
	Block size.
#define	MMC_MAX_INIT_POLLS 512
	Card init timeout.
#define	MMC_MAX_RESET_RETRIES 2
	Card reset timeout.
#define	MMC_MAX_WRITE_RETRIES 2
	Card write retries.
#define	MMC_MAX_READ_RETRIES MMC_MAX_WRITE_RETRIES
	Card read retries.
#define	MMC_MAX_CMDACK_POLLS 1024
	Command acknowledge timeout.
#define	MMC_MAX_READY_POLLS 800
	Card busy timeout.
Typedefs
typedef struct _MEMCARDSUPP	MEMCARDSUPP
	Memory card support structure.
typedef struct _MMCIFC	MMCIFC
	Low level access information structure.
typedef struct _MMC_CID	MMC_CID
	Multimedia card identification register.
typedef struct _MMC_CSD	MMC_CSD
	Multimedia card identification register.
typedef struct _MMCFCB	MMCFCB
	Local multimedia card mount information.
typedef struct _MMCFCB	MMCFCB
	Local multimedia card status information.
Functions
int	MmCardBlockRead (NUTFILE nfp, void buffer, int num)
	Read data blocks from a mounted partition.
int	MmCardBlockWrite (NUTFILE nfp, CONST void buffer, int num)
	Write data blocks to a mounted partition.
int	MmCardBlockWrite_P (NUTFILE *nfp, PGM_P buffer, int num)
	Write data blocks from program space to a mounted partition.
NUTFILE *	MmCardMount (NUTDEVICE dev, CONST char name, int mode, int acc)
	Mount a partition.
int	MmCardUnmount (NUTFILE *nfp)
	Unmount a previously mounted partition.
int	MmCardIOCtl (NUTDEVICE dev, int req, void conf)
	Perform MMC control functions.
int	MmCardDevInit (NUTDEVICE *dev)
	Initialize high level MMC driver.
int	SpiMmcBlockRead (NUTFILE nfp, void buffer, int num)
	Read data blocks from a mounted partition.
int	SpiMmcBlockWrite (NUTFILE nfp, CONST void buffer, int num)
	Write data blocks to a mounted partition.
int	SpiMmcBlockWrite_P (NUTFILE *nfp, PGM_P buffer, int num)
	Write data blocks from program space to a mounted partition.
int	SpiMmcUnmount (NUTFILE *nfp)
	Unmount a previously mounted partition.
NUTFILE *	SpiMmcMount (NUTDEVICE dev, CONST char name, int mode, int acc)
	Mount a partition.
int	SpiMmcIOCtl (NUTDEVICE dev, int req, void conf)
	Perform MMC control functions.
int	SpiMmcInit (NUTDEVICE *dev)
	Initialize MMC driver.
Voltage Ranges
#define	MMCARD_165_195V 0x00000080
#define	MMCARD_20_21V 0x00000100
#define	MMCARD_21_22V 0x00000200
#define	MMCARD_22_23V 0x00000400
#define	MMCARD_23_24V 0x00000800
#define	MMCARD_24_25V 0x00001000
#define	MMCARD_25_26V 0x00002000
#define	MMCARD_26_27V 0x00004000
#define	MMCARD_27_28V 0x00008000
#define	MMCARD_28_29V 0x00010000
#define	MMCARD_29_30V 0x00020000
#define	MMCARD_30_31V 0x00040000
#define	MMCARD_31_32V 0x00080000
#define	MMCARD_32_33V 0x00100000
#define	MMCARD_33_34V 0x00200000
#define	MMCARD_34_35V 0x00400000
#define	MMCARD_35_36V 0x00800000
Control Codes
#define	MMCARD_GETSTATUS 0x2001
	Retrieve card status.
#define	MMCARD_GETOCR 0x2002
	Retrieve operation condition register.
#define	MMCARD_GETCID 0x2003
	Retrieve card identification.
#define	MMCARD_GETCSD 0x2004
	Retrieve card specific data.
#define	MMCARD_GETEXTCSD 0x2005
	Retrieve extended card specific data.

Detailed Description

Block device driver for MM/SD Cards.

Basic SPI bus block device driver for multimedia cards.

Basic block device driver for multimedia cards.

The driver uses SPI mode, but doesn't include any low level hardware access. This must be provided by some additional routines.

 *
 * $Log$
 * Revision 1.15  2009/02/13 14:52:05  haraldkipp
 * Include memdebug.h for heap management debugging support.
 *
 * Revision 1.14  2009/02/06 15:40:29  haraldkipp
 * Using newly available strdup() and calloc().
 * Replaced NutHeap routines by standard malloc/free.
 * Replaced pointer value 0 by NULL.
 *
 * Revision 1.13  2009/01/17 11:26:46  haraldkipp
 * Getting rid of two remaining BSD types in favor of stdint.
 * Replaced 'u_int' by 'unsinged int' and 'uptr_t' by 'uintptr_t'.
 *
 * Revision 1.12  2008/08/11 06:59:42  haraldkipp
 * BSD types replaced by stdint types (feature request #1282721).
 *
 * Revision 1.11  2008/07/14 13:09:30  haraldkipp
 * Allow small MultiMedia Cards without partition table.
 *
 * Revision 1.10  2007/08/30 12:15:06  haraldkipp
 * Configurable MMC timings.
 *
 * Revision 1.9  2006/10/08 16:48:09  haraldkipp
 * Documentation fixed
 *
 * Revision 1.8  2006/07/05 08:03:12  haraldkipp
 * Bugfix. Trailing slash in mount path not properly handled.
 * Thanks to Michael Fischer.
 *
 * Revision 1.7  2006/06/18 16:34:46  haraldkipp
 * Mutex deadlock fixed.
 *
 * Revision 1.6  2006/05/25 09:34:21  haraldkipp
 * Added mutual exclusion lock for multithreaded access.
 *
 * Revision 1.5  2006/04/07 12:29:03  haraldkipp
 * Number of read retries increased. Memory hole fixed.
 * Added ioctl(NUTBLKDEV_MEDIAAVAIL).
 * Card change ioctl() will also return 1 if no card is available.
 *
 * Revision 1.4  2006/02/23 15:43:56  haraldkipp
 * Timeout value increased. Some cards have long write latencies.
 *
 * Revision 1.3  2006/01/22 17:36:31  haraldkipp
 * Some cards need more time to enter idle state.
 * Card access now returns an error after card change detection.
 *
 * Revision 1.2  2006/01/19 18:40:08  haraldkipp
 * Timeouts increased and long time sleeps decreased for better performance.
 *
 * Revision 1.1  2006/01/05 16:30:49  haraldkipp
 * First check-in.
 *
 *
 *

The driver provides generic memory card access, but doesn't include low level hardware support like card detection. This must be provided by a hardware specific support module.

 *
 * $Id$
 *
 *

Define Documentation

#define NUTMC_SF_CD 0x01

Definition at line 70 of file mmcard.h.

Referenced by SpiMmcIOCtl(), and SpiMmcMount().

#define NUTMC_SF_WP 0x02

Definition at line 71 of file mmcard.h.

#define NUTMC_IND_OFF 0

Definition at line 73 of file mmcard.h.

Referenced by SpiMmcBlockRead(), and SpiMmcBlockWrite().

#define NUTMC_IND_READ 1

Definition at line 74 of file mmcard.h.

Referenced by SpiMmcBlockRead().

#define NUTMC_IND_WRITE 2

Definition at line 75 of file mmcard.h.

Referenced by SpiMmcBlockWrite().

#define NUTMC_IND_ERROR 4

Definition at line 76 of file mmcard.h.

Referenced by SpiMmcBlockRead(), and SpiMmcBlockWrite().

#define MMCMD_HOST 0x40

Definition at line 110 of file mmcard.h.

#define MMCMD_RESET_CRC 0x95

Definition at line 111 of file mmcard.h.

#define MMCMD_GO_IDLE_STATE 0

Reset card to idle state.

In idle state the card will not accept any other commands than MMCMD_SEND_OP_COND or MMCMD_READ_OCR.

Definition at line 118 of file mmcard.h.

#define MMCMD_SEND_OP_COND 1

Activate card's initialization process.

Definition at line 121 of file mmcard.h.

#define MMCMD_ALL_SEND_CID 2

Send operation condition register.

Queries the operation condition register content from all cards, which are in idle state.

Definition at line 128 of file mmcard.h.

#define MMCMD_SEND_RELATIVE_ADDR 3

Assign relative card address.

Definition at line 131 of file mmcard.h.

#define MMCMD_SELECT_CARD 7

Assign relative card address.

Definition at line 134 of file mmcard.h.

#define MMCMD_SEND_EXTCSD 8

Query card's extended CSD.

Definition at line 137 of file mmcard.h.

Referenced by SpiMmcIOCtl().

#define MMCMD_SEND_CSD 9

Query card's CSD.

Definition at line 140 of file mmcard.h.

Referenced by MmCardIOCtl(), and SpiMmcIOCtl().

#define MMCMD_SEND_CID 10

Query card's CID.

Definition at line 143 of file mmcard.h.

Referenced by MmCardIOCtl(), and SpiMmcIOCtl().

#define MMCMD_STOP_TRANSMISSION 12

Stop multiple block transmission.

Definition at line 146 of file mmcard.h.

#define MMCMD_SEND_STATUS 13

Query card's status register.

Definition at line 149 of file mmcard.h.

Referenced by MmCardIOCtl(), and SpiMmcIOCtl().

#define MMCMD_SET_BLOCKLEN 16

Select block length for following read/write commands.

Definition at line 152 of file mmcard.h.

#define MMCMD_READ_SINGLE_BLOCK 17

Initiate single block read.

Definition at line 155 of file mmcard.h.

Referenced by SpiMmcBlockRead(), and SpiMmcMount().

#define MMCMD_READ_MULTIPLE_BLOCK 18

Initiate continuous block read.

Definition at line 158 of file mmcard.h.

#define MMCMD_WRITE_BLOCK 24

Initiate single block write.

Definition at line 161 of file mmcard.h.

Referenced by SpiMmcBlockWrite().

#define MMCMD_WRITE_MULTIPLE_BLOCK 25

Initiate continuous block write.

Definition at line 164 of file mmcard.h.

#define MMCMD_PROGRAM_CSD 27

Initiate programming of programmable CSD bits.

Definition at line 167 of file mmcard.h.

#define MMCMD_SET_WRITE_PROTECT 28

Enable card's optional write protection.

Definition at line 170 of file mmcard.h.

#define MMCMD_CLR_WRITE_PROTECT 29

Disable card's write protection.

Definition at line 173 of file mmcard.h.

#define MMCMD_SEND_WRITE_PROTECT 30

Query card's write protect status.

Definition at line 176 of file mmcard.h.

#define MMCMD_TAG_ERASE_GROUP_START 35

Set address of the first erase group.

Definition at line 179 of file mmcard.h.

#define MMCMD_TAG_ERASE_GROUP_END 36

Set address of the last erase group.

Definition at line 182 of file mmcard.h.

#define MMCMD_ERASE 38

Erase previously selected sectors.

Definition at line 185 of file mmcard.h.

#define MMCMD_SEND_APP_OP_COND 41

Activate SD card's initialization process.

Definition at line 188 of file mmcard.h.

#define MMCMD_LOCK_UNLOCK 42

Set/clear password or lock/unlock the card.

Definition at line 191 of file mmcard.h.

#define MMCMD_SEND_APP_CMD 55

Application command follows.

Definition at line 194 of file mmcard.h.

#define MMCMD_READ_OCR 58

Query card's operating condition register.

Definition at line 197 of file mmcard.h.

Referenced by MmCardIOCtl(), and SpiMmcIOCtl().

#define MMCMD_CRC_ON_OFF 59

Enable or disable CRC mode.

In SPI mode CRC is disabled by default.

Definition at line 203 of file mmcard.h.

#define MMR1_IDLE_STATE 0x00

Card is idle.

Definition at line 206 of file mmcard.h.

Referenced by MmCardIOCtl(), and SpiMmcIOCtl().

#define MMR1_NOT_IDLE 0x01

Card is busy.

Definition at line 208 of file mmcard.h.

#define MMR1_ERASE_RESET 0x02

Erase sequence was cleared before execution.

Definition at line 210 of file mmcard.h.

#define MMR1_ILLEGAL_COMMAND 0x04

Illegal command code detected.

Definition at line 212 of file mmcard.h.

#define MMR1_COM_CRC_ERROR 0x08

Bad command CRC detected.

Definition at line 214 of file mmcard.h.

#define MMR1_ERASE_SEQ_ERROR 0x10

Bad erase sequence.

Definition at line 216 of file mmcard.h.

#define MMR1_ADDRESS_ERROR 0x20

Misaligned address did not match block length.

Definition at line 218 of file mmcard.h.

#define MMR1_PARAMETER_ERROR 0x40

Command parameter is out of range.

Definition at line 220 of file mmcard.h.

#define MMR2_CARD_LOCKED 0x01

Card is locked.

Definition at line 224 of file mmcard.h.

#define MMR2_WP_ERASE_SKIP 0x02

Erasing write protected sector or password error.

Definition at line 226 of file mmcard.h.

#define MMR2_ERROR 0x04

General or unknown error occured.

Definition at line 228 of file mmcard.h.

#define MMR2_CC_ERROR 0x08

Internal card controller error.

Definition at line 230 of file mmcard.h.

#define MMR2_ECC_FAILED 0x10

Bad internal ECC.

Definition at line 232 of file mmcard.h.

#define MMR2_WP_VIOLATION 0x20

Failed to write to protected block.

Definition at line 234 of file mmcard.h.

#define MMR2_ERASE_PARAMETER 0x40

Invalid erase parameter.

Definition at line 236 of file mmcard.h.

#define MMR2_OUT_OF_RANGE 0x80

Command parameter is out of range.

Definition at line 238 of file mmcard.h.

#define MMCSR_OUT_OF_RANGE 0x80000000

Definition at line 241 of file mmcard.h.

#define MMCSR_ADDRESS_ERROR 0x40000000

Definition at line 242 of file mmcard.h.

#define MMCSR_BLOCK_LEN_ERROR 0x20000000

Definition at line 243 of file mmcard.h.

#define MMCSR_ERASE_SEQ_ERROR 0x10000000

Definition at line 244 of file mmcard.h.

#define MMCSR_ERASE_PARAM 0x08000000

Definition at line 245 of file mmcard.h.

#define MMCSR_WP_VIOLATION 0x04000000

Definition at line 246 of file mmcard.h.

#define MMCSR_COM_CRC_ERROR 0x00800000

Definition at line 247 of file mmcard.h.

#define MMCSR_ILLEGAL_COMMAND 0x00400000

Definition at line 248 of file mmcard.h.

#define MMCSR_ERROR 0x00080000

Definition at line 249 of file mmcard.h.

#define MMCSR_CIDCSD_OVERWRITE 0x00010000

Definition at line 250 of file mmcard.h.

#define MMCSR_WP_ERASE_SKIP 0x00008000

Definition at line 251 of file mmcard.h.

#define MMCSR_CARD_ECC_DISABLED 0x00004000

Definition at line 252 of file mmcard.h.

#define MMCSR_ERASE_RESET 0x00002000

Definition at line 253 of file mmcard.h.

#define MMCSR_STATE_MASK 0x00001E00

Definition at line 254 of file mmcard.h.

#define MMCSR_READY_FOR_DATA 0x00000100

Definition at line 255 of file mmcard.h.

#define MMCSR_IS_IDLE 0x00000000

Definition at line 257 of file mmcard.h.

#define MMCSR_IS_READY 0x00000200

Definition at line 258 of file mmcard.h.

#define MMCSR_IS_IDENT 0x00000400

Definition at line 259 of file mmcard.h.

#define MMCSR_IS_STBY 0x00000600

Definition at line 260 of file mmcard.h.

#define MMCSR_IS_TRAN 0x00000800

Definition at line 261 of file mmcard.h.

#define MMCSR_IS_DATA 0x00000A00

Definition at line 262 of file mmcard.h.

#define MMCSR_IS_RCV 0x00000C00

Definition at line 263 of file mmcard.h.

#define MMCSR_IS_PRG 0x00000E00

Definition at line 264 of file mmcard.h.

#define MMCSR_IS_DIS 0x00001000

Definition at line 265 of file mmcard.h.

#define MMDR_ACCEPTED

Definition at line 267 of file mmcard.h.

#define MMDR_CRC_ERROR

Definition at line 268 of file mmcard.h.

#define MMDR_WRITE_ERROR

Definition at line 269 of file mmcard.h.

#define MMCERR_TIMEOUT 0x00000001

Definition at line 271 of file mmcard.h.

#define MMCOP_NBUSY 0x80000000

Definition at line 273 of file mmcard.h.

#define MMCARD_CIDR_SIZE 16

Number of bytes in the CID register.

Definition at line 276 of file mmcard.h.

#define MMCARD_CSDR_SIZE 16

Number of bytes in the CSD register.

Definition at line 279 of file mmcard.h.

#define MMCARD_OCR_SIZE 32

Number of bytes in the operating condition register.

Definition at line 282 of file mmcard.h.

#define MMCARD_165_195V 0x00000080

Definition at line 288 of file mmcard.h.

#define MMCARD_20_21V 0x00000100

Definition at line 289 of file mmcard.h.

#define MMCARD_21_22V 0x00000200

Definition at line 290 of file mmcard.h.

#define MMCARD_22_23V 0x00000400

Definition at line 291 of file mmcard.h.

#define MMCARD_23_24V 0x00000800

Definition at line 292 of file mmcard.h.

#define MMCARD_24_25V 0x00001000

Definition at line 293 of file mmcard.h.

#define MMCARD_25_26V 0x00002000

Definition at line 294 of file mmcard.h.

#define MMCARD_26_27V 0x00004000

Definition at line 295 of file mmcard.h.

#define MMCARD_27_28V 0x00008000

Definition at line 296 of file mmcard.h.

#define MMCARD_28_29V 0x00010000

Definition at line 297 of file mmcard.h.

#define MMCARD_29_30V 0x00020000

Definition at line 298 of file mmcard.h.

#define MMCARD_30_31V 0x00040000

Definition at line 299 of file mmcard.h.

#define MMCARD_31_32V 0x00080000

Definition at line 300 of file mmcard.h.

#define MMCARD_32_33V 0x00100000

Definition at line 301 of file mmcard.h.

#define MMCARD_33_34V 0x00200000

Definition at line 302 of file mmcard.h.

#define MMCARD_34_35V 0x00400000

Definition at line 303 of file mmcard.h.

#define MMCARD_35_36V 0x00800000

Definition at line 304 of file mmcard.h.

#define MMCARD_GETSTATUS 0x2001

Retrieve card status.

Definition at line 313 of file mmcard.h.

Referenced by MmCardIOCtl(), and SpiMmcIOCtl().

#define MMCARD_GETOCR 0x2002

Retrieve operation condition register.

Definition at line 315 of file mmcard.h.

Referenced by MmCardIOCtl(), and SpiMmcIOCtl().

#define MMCARD_GETCID 0x2003

Retrieve card identification.

Definition at line 317 of file mmcard.h.

Referenced by MmCardIOCtl(), and SpiMmcIOCtl().

#define MMCARD_GETCSD 0x2004

Retrieve card specific data.

Definition at line 319 of file mmcard.h.

Referenced by MmCardIOCtl(), and SpiMmcIOCtl().

#define MMCARD_GETEXTCSD 0x2005

Retrieve extended card specific data.

Definition at line 321 of file mmcard.h.

Referenced by SpiMmcIOCtl().

#define MMC_BLOCK_SIZE 512

Block size.

Block size in bytes. Do not change unless you are sure that both, the file system and the hardware support it.

Definition at line 132 of file mmcard.c.

#define MMC_MAX_INIT_POLLS 512

Card init timeout.

Max. number of loops waiting for card's idle mode after initialization. An additional delay of 1 ms is added to each loop after one quarter of this value elapsed.

Definition at line 143 of file mmcard.c.

#define MMC_MAX_RESET_POLLS 255

Card reset timeout.

Max. number of loops waiting for card's idle mode after resetting it.

Definition at line 152 of file mmcard.c.

#define MMC_MAX_WRITE_POLLS 1024

Card write timeout.

Max. number of loops waiting for card's idle mode after resetting it. An additional delay of 1 ms is added to each loop after 31/32 of this value elapsed.

Definition at line 163 of file mmcard.c.

#define MMC_MAX_WRITE_RETRIES 32

Card write retries.

Max. number of retries while writing.

Definition at line 172 of file mmcard.c.

#define MMC_MAX_READ_RETRIES 8

Card read retries.

Max. number of retries while reading.

Definition at line 181 of file mmcard.c.

Referenced by MmCardBlockRead(), and MmCardBlockWrite().

#define MMC_MAX_REG_POLLS 512

Register read timeout.

Max. number of loops while reading a card's register.

Definition at line 190 of file mmcard.c.

#define MMC_MAX_CMDACK_POLLS 1024

Command acknowledge timeout.

Max. number of loops waiting for card's acknowledge of a command. An additional delay of 1 ms is added to each loop after three quarter of this value elapsed.

Definition at line 201 of file mmcard.c.

#define MMC_MAX_R1_POLLS 1024

R1 response timeout.

Max. number of loops waiting for card's R1 response.

Definition at line 210 of file mmcard.c.

#define MMC_BLOCK_SIZE 512

Block size.

Block size in bytes. Do not change unless you are sure that both, the file system and the hardware support it.

Definition at line 85 of file spi_mmc.c.

Referenced by SpiMmcBlockRead(), SpiMmcBlockWrite(), SpiMmcInit(), SpiMmcIOCtl(), and SpiMmcMount().

#define MMC_MAX_INIT_POLLS 512

Card init timeout.

Max. number of loops waiting for card's idle mode after initialization. An additional delay of 1 ms is added to each loop after one quarter of this value elapsed.

Definition at line 96 of file spi_mmc.c.

#define MMC_MAX_RESET_RETRIES 2

Card reset timeout.

Max. number of loops waiting for card's idle mode after resetting it.

Definition at line 105 of file spi_mmc.c.

#define MMC_MAX_WRITE_RETRIES 2

Card write retries.

Max. number of retries while writing.

Definition at line 114 of file spi_mmc.c.

#define MMC_MAX_READ_RETRIES MMC_MAX_WRITE_RETRIES

Card read retries.

Max. number of retries while reading.

Definition at line 123 of file spi_mmc.c.

#define MMC_MAX_CMDACK_POLLS 1024

Command acknowledge timeout.

Max. number of loops waiting for card's acknowledge of a command. An additional delay of 1 ms is added to each loop after three quarter of this value elapsed.

Definition at line 134 of file spi_mmc.c.

#define MMC_MAX_READY_POLLS 800

Card busy timeout.

Max. number of loops waiting for card's ready state. An additional delay of 1 ms is added to each loop after one quarter of this value elapsed.

Definition at line 145 of file spi_mmc.c.

Typedef Documentation

typedef struct _MEMCARDSUPP MEMCARDSUPP

Memory card support structure.

typedef struct _MMCIFC MMCIFC

Low level access information structure.

typedef struct _MMC_CID MMC_CID

Multimedia card identification register.

typedef struct _MMC_CSD MMC_CSD

Multimedia card identification register.

typedef struct _MMCFCB MMCFCB

Local multimedia card mount information.

typedef struct _MMCFCB MMCFCB

Local multimedia card status information.

Function Documentation

int MmCardBlockRead	(	NUTFILE *	nfp,
		void *	buffer,
		int	num
	)

Read data blocks from a mounted partition.

Applications should not call this function directly, but use the stdio interface.

Parameters:

nfp	Pointer to a NUTFILE structure, obtained by a previous call to MmCardMount().
buffer	Pointer to the data buffer to fill.
num	Maximum number of blocks to read. However, reading multiple blocks is not yet supported by this driver.

Returns:: The number of blocks actually read. A return value of -1 indicates an error.

Definition at line 596 of file mmcard.c.

References _MMCFCB::fcb_blkbuf, _MMCFCB::fcb_blknum, _MMCFCB::fcb_part, MMC_MAX_READ_RETRIES, _MMCIFC::mmcifc_cd, _NUTFILE::nf_dev, _NUTFILE::nf_fcb, and _DOSPART::part_sect_offs.

int MmCardBlockWrite	(	NUTFILE *	nfp,
		CONST void *	buffer,
		int	num
	)

Write data blocks to a mounted partition.

Applications should not call this function directly, but use the stdio interface.

Parameters:

nfp	Pointer to a NUTFILE structure, obtained by a previous call to MmCardMount().
buffer	Pointer to the data to be written.
num	Maximum number of blocks to write. However, writing multiple blocks is not yet supported by this driver.

Returns:: The number of blocks written. A return value of -1 indicates an error.

Definition at line 649 of file mmcard.c.

References _MMCFCB::fcb_blkbuf, _MMCFCB::fcb_blknum, _MMCFCB::fcb_part, MMC_MAX_READ_RETRIES, _MMCIFC::mmcifc_cd, _NUTFILE::nf_dev, _NUTFILE::nf_fcb, and _DOSPART::part_sect_offs.

int MmCardBlockWrite_P	(	NUTFILE *	nfp,
		PGM_P	buffer,
		int	num
	)

Write data blocks from program space to a mounted partition.

This function is not yet implemented and will always return -1.

Similar to MmCardBlockWrite() except that the data is located in program memory.

Applications should not call this function directly, but use the stdio interface.

Parameters:

nfp	File pointer to a previously opened device.
buffer	Pointer to the data bytes in program space to be written.
num	Maximum number of blocks to write. However, writing multiple blocks is not yet supported by this driver.

Returns:: The number of blocks written. A return value of -1 indicates an error.

Definition at line 707 of file mmcard.c.

NUTFILE* MmCardMount	(	NUTDEVICE *	dev,
		CONST char *	name,
		int	mode,
		int	acc
	)

Mount a partition.

Nut/OS doesn't provide specific routines for mounting. Instead routines for opening files are used.

Applications should not directly call this function, but use the high level stdio routines for opening a file.

Parameters:

dev	Pointer to the MMC device.
name	Partition number followed by a slash followed by a name of the file system device. Both items are optional. If no file system driver name is given, the first file system driver found in the list of registered devices will be used. If no partition number is specified or if partition zero is given, the first active primary partition will be used.
mode	Opening mode. Currently ignored, but _O_RDWR \| _O_BINARY should be used for compatibility with future enhancements.
acc	File attributes, ignored.

Returns:: Pointer to a newly created file pointer to the mounted partition or NUTFILE_EOF in case of any error.

Definition at line 738 of file mmcard.c.

References atoi(), calloc, _NUTDEVICE::dev_icb, _NUTDEVICE::dev_ioctl, _NUTDEVICE::dev_name, _NUTDEVICE::dev_next, _NUTDEVICE::dev_type, DOSPART_MAGICPOS, DOSPART_SECTORPOS, DOSPART_TYPEPOS, ENODEV, ENOMEM, errno, _MMCFCB::fcb_blkbuf, _MMCFCB::fcb_fsdev, _MMCFCB::fcb_part, free(), FS_VOL_MOUNT, IFTYP_FS, MmCardUnmount(), _MMCIFC::mmcifc_cd, _NUTFILE::nf_dev, _NUTFILE::nf_fcb, _NUTFILE::nf_next, nutDeviceList, NUTFILE_EOF, NutHeapAlloc, _DOSPART::part_sect_offs, _DOSPART::part_sects, _DOSPART::part_state, _DOSPART::part_type, printf, PTYPE_EMPTY, PTYPE_FAT12, and strcmp().

Here is the call graph for this function:

int MmCardUnmount ( NUTFILE * nfp )

Unmount a previously mounted partition.

Applications should not directly call this function, but use the high level stdio routines for closing a previously opened file.

Returns:: 0 on success, -1 otherwise.

Definition at line 874 of file mmcard.c.

References _NUTDEVICE::dev_icb, _NUTDEVICE::dev_ioctl, _MMCFCB::fcb_fsdev, free(), FS_VOL_UNMOUNT, _MMCIFC::mmcifc_cd, _NUTFILE::nf_dev, and _NUTFILE::nf_fcb.

Referenced by MmCardMount().

Here is the call graph for this function:

int MmCardIOCtl	(	NUTDEVICE *	dev,
		int	req,
		void *	conf
	)

Perform MMC control functions.

This function is called by the ioctl() function of the C runtime library. Applications should not directly call this function.

Todo:: Card change detection should verify the serial card number.

Parameters:

dev	Identifies the device that receives the device-control function.
req	Requested control function. May be set to one of the following constants: NUTBLKDEV_MEDIACHANGE NUTBLKDEV_INFO NUTBLKDEV_SEEK MMCARD_GETCID MMCARD_GETCSD
conf	Points to a buffer that contains any data required for the given control function or receives data from that function.

Returns:: 0 on success, -1 otherwise.

Definition at line 968 of file mmcard.c.

References _NUTDEVICE::dev_icb, _MMCFCB::fcb_blkbuf, _MMCFCB::fcb_blknum, _MMCFCB::fcb_part, MMCARD_GETCID, MMCARD_GETCSD, MMCARD_GETOCR, MMCARD_GETSTATUS, _MMCIFC::mmcifc_cd, MMCMD_READ_OCR, MMCMD_SEND_CID, MMCMD_SEND_CSD, MMCMD_SEND_STATUS, MMR1_IDLE_STATE, _NUTFILE::nf_fcb, NUTBLKDEV_INFO, NUTBLKDEV_MEDIAAVAIL, NUTBLKDEV_MEDIACHANGE, NUTBLKDEV_SEEK, NutEventPost(), NutEventWait(), _BLKPAR_INFO::par_blkbp, _BLKPAR_SEEK::par_blknum, _BLKPAR_INFO::par_blksz, _BLKPAR_INFO::par_nblks, _BLKPAR_SEEK::par_nfp, _BLKPAR_INFO::par_nfp, and _DOSPART::part_sects.

Here is the call graph for this function:

int MmCardDevInit ( NUTDEVICE * dev )

Initialize high level MMC driver.

Applications should not directly call this function. It is automatically executed during during device registration by NutRegisterDevice().

Parameters:

dev	Identifies the device to initialize.

Returns:: Always zero.

Definition at line 1058 of file mmcard.c.

int SpiMmcBlockRead	(	NUTFILE *	nfp,
		void *	buffer,
		int	num
	)

Read data blocks from a mounted partition.

Applications should not call this function directly, but use the stdio interface.

Parameters:

nfp	Pointer to a NUTFILE structure, obtained by a previous call to SpiMmcMount().
buffer	Pointer to the data buffer to fill.
num	Maximum number of blocks to read. However, reading multiple blocks is not yet supported by this driver.

Returns:: The number of blocks actually read. A return value of -1 indicates an error.

Definition at line 500 of file spi_mmc.c.

References _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, _MMCFCB::fcb_address, _MMCFCB::fcb_blkbuf, _MEMCARDSUPP::mcs_act, _MEMCARDSUPP::mcs_cf, MMC_BLOCK_SIZE, MMCMD_READ_SINGLE_BLOCK, _NUTFILE::nf_dev, _NUTFILE::nf_fcb, NUTASSERT, NUTMC_IND_ERROR, NUTMC_IND_OFF, and NUTMC_IND_READ.

int SpiMmcBlockWrite	(	NUTFILE *	nfp,
		CONST void *	buffer,
		int	num
	)

Write data blocks to a mounted partition.

Applications should not call this function directly, but use the stdio interface.

Parameters:

nfp	Pointer to a NUTFILE structure, obtained by a previous call to SpiMmcMount().
buffer	Pointer to the data to be written. However, writing multiple blocks is not yet supported by this driver.
num	Number of blocks to write.

Returns:: The number of blocks written. A return value of -1 indicates an error.

Definition at line 553 of file spi_mmc.c.

References _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, _MMCFCB::fcb_address, _MMCFCB::fcb_blkbuf, _MEMCARDSUPP::mcs_act, _MEMCARDSUPP::mcs_cf, MMC_BLOCK_SIZE, MMCMD_WRITE_BLOCK, _NUTFILE::nf_dev, _NUTFILE::nf_fcb, NUTASSERT, NUTMC_IND_ERROR, NUTMC_IND_OFF, and NUTMC_IND_WRITE.

int SpiMmcBlockWrite_P	(	NUTFILE *	nfp,
		PGM_P	buffer,
		int	num
	)

Write data blocks from program space to a mounted partition.

This function is not yet implemented and will always return -1.

Similar to SpiMmcBlockWrite() except that the data is located in program memory.

Applications should not call this function directly, but use the stdio interface.

Parameters:

nfp	File pointer to a previously opened device.
buffer	Pointer to the data bytes in program space to be written.
num	Maximum number of blocks to write. However, writing multiple blocks is not yet supported by this driver.

Returns:: The number of blocks written. A return value of -1 indicates an error.

Definition at line 608 of file spi_mmc.c.

int SpiMmcUnmount ( NUTFILE * nfp )

Unmount a previously mounted partition.

Applications should not directly call this function, but use the high level stdio routines for closing a previously opened volume.

Parameters:

nfp	Pointer to a NUTFILE structure, obtained by a previous call to SpiMmcMount().

Returns:: 0 on success, -1 otherwise.

Definition at line 793 of file spi_mmc.c.

References _NUTDEVICE::dev_ioctl, _MMCFCB::fcb_fsdev, free(), FS_VOL_UNMOUNT, _NUTFILE::nf_fcb, and NUTASSERT.

Referenced by SpiMmcMount().

Here is the call graph for this function:

NUTFILE* SpiMmcMount	(	NUTDEVICE *	dev,
		CONST char *	name,
		int	mode,
		int	acc
	)

Mount a partition.

Nut/OS doesn't provide specific routines for mounting. Instead routines for opening files are used.

Applications should not directly call this function, but use the high level stdio routines for opening a file.

Parameters:

dev	Pointer to the MMC device.
name	Partition number followed by a slash followed by a name of the file system device. Both items are optional. If no file system driver name is given, the first file system driver found in the list of registered devices will be used. If no partition number is specified or if partition zero is given, the first active primary partition will be used.
mode	Opening mode. Currently ignored, but _O_RDWR \| _O_BINARY should be used for compatibility with future enhancements.
acc	File attributes, ignored.

Returns:: Pointer to a newly created file pointer to the mounted partition or NUTFILE_EOF in case of any error.

Definition at line 641 of file spi_mmc.c.

References atoi(), calloc, _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, _NUTDEVICE::dev_ioctl, _NUTDEVICE::dev_name, _NUTDEVICE::dev_next, _NUTDEVICE::dev_type, DOSPART_MAGICPOS, DOSPART_SECTORPOS, DOSPART_TYPEPOS, ENODEV, ENOMEM, errno, _MMCFCB::fcb_blkbuf, _MMCFCB::fcb_fsdev, _MMCFCB::fcb_part, free(), FS_VOL_MOUNT, IFTYP_FS, _MEMCARDSUPP::mcs_cf, _MEMCARDSUPP::mcs_sf, MMC_BLOCK_SIZE, MMCMD_READ_SINGLE_BLOCK, _NUTFILE::nf_dev, _NUTFILE::nf_fcb, _NUTFILE::nf_next, nutDeviceList, NUTFILE_EOF, NutHeapAlloc, NUTMC_SF_CD, _DOSPART::part_sect_offs, _DOSPART::part_sects, _DOSPART::part_state, _DOSPART::part_type, printf, PTYPE_EMPTY, PTYPE_FAT12, SpiMmcUnmount(), and strcmp().

Here is the call graph for this function:

int SpiMmcIOCtl	(	NUTDEVICE *	dev,
		int	req,
		void *	conf
	)

Perform MMC control functions.

This function is called by the ioctl() function of the C runtime library. Applications should not directly call this function.

Todo:: Card change detection should verify the serial card number.

Parameters:

dev	Identifies the device that receives the device-control function.
req	Requested control function. May be set to one of the following constants: NUTBLKDEV_MEDIACHANGE NUTBLKDEV_INFO NUTBLKDEV_SEEK MMCARD_GETCID MMCARD_GETCSD
conf	Points to a buffer that contains any data required for the given control function or receives data from that function.

Returns:: 0 on success, -1 otherwise.

Definition at line 835 of file spi_mmc.c.

References _NUTSPIBUS::bus_release, _NUTSPIBUS::bus_transfer, _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, _MMCFCB::fcb_address, _MMCFCB::fcb_blkbuf, _MMCFCB::fcb_part, MMC_BLOCK_SIZE, MMCARD_GETCID, MMCARD_GETCSD, MMCARD_GETEXTCSD, MMCARD_GETOCR, MMCARD_GETSTATUS, MMCMD_READ_OCR, MMCMD_SEND_CID, MMCMD_SEND_CSD, MMCMD_SEND_EXTCSD, MMCMD_SEND_STATUS, MMR1_IDLE_STATE, _NUTFILE::nf_fcb, _NUTSPINODE::node_bus, NUTBLKDEV_INFO, NUTBLKDEV_MEDIAAVAIL, NUTBLKDEV_MEDIACHANGE, NUTBLKDEV_SEEK, NUTMC_SF_CD, _BLKPAR_INFO::par_blkbp, _BLKPAR_SEEK::par_blknum, _BLKPAR_INFO::par_blksz, _BLKPAR_INFO::par_nblks, _BLKPAR_SEEK::par_nfp, _BLKPAR_INFO::par_nfp, _DOSPART::part_sect_offs, and _DOSPART::part_sects.

int SpiMmcInit ( NUTDEVICE * dev )

Initialize MMC driver.

Applications should not directly call this function. It is automatically executed during during device registration by NutRegisterDevice().

Parameters:

dev	Identifies the device to initialize.

Returns:: Always zero.

Definition at line 928 of file spi_mmc.c.

References memset(), and MMC_BLOCK_SIZE.

Here is the call graph for this function:

Data Structures

Defines

Typedefs

Functions

Voltage Ranges

Control Codes

Detailed Description

Define Documentation

Typedef Documentation

Function Documentation
