lan91.h File Reference

#include <dev/netbuf.h>
#include <net/if_var.h>

Include dependency graph for lan91.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Defines
#define	LAN91_BASE_ADDR   0xC000
#define	LAN91_BSR   (LAN91_BASE_ADDR + 0x0E)
	Bank select register.
#define	LAN91_TCR   (LAN91_BASE_ADDR + 0x00)
	Bank 0 - Transmit control register.
#define	LAN91_TCR_SWFDUP   0x8000
#define	LAN91_TCR_EPH_LOOP   0x2000
#define	LAN91_TCR_STP_SQET   0x1000
#define	LAN91_TCR_FDUPLX   0x0800
#define	LAN91_TCR_MON_CSN   0x0400
#define	LAN91_TCR_NOCRC   0x0100
#define	LAN91_TCR_PAD_EN   0x0080
#define	LAN91_TCR_FORCOL   0x0004
#define	LAN91_TCR_LOOP   0x0002
#define	LAN91_TCR_TXENA   0x0001
#define	LAN91_EPHSR   (LAN91_BASE_ADDR + 0x02)
	Bank 0 - EPH status register.
#define	LAN91_RCR   (LAN91_BASE_ADDR + 0x04)
	Bank 0 - Receive control register.
#define	LAN91_RCR_SOFT_RST   0x8000
#define	LAN91_RCR_FILT_CAR   0x4000
#define	LAN91_RCR_ABORT_ENB   0x2000
#define	LAN91_RCR_STRIP_CRC   0x0200
#define	LAN91_RCR_RXEN   0x0100
#define	LAN91_RCR_ALMUL   0x0004
#define	LAN91_RCR_PRMS   0x0002
#define	LAN91_RCR_RX_ABORT   0x0001
#define	LAN91_ECR   (LAN91_BASE_ADDR + 0x06)
	Bank 0 - Counter register.
#define	LAN91_MIR   (LAN91_BASE_ADDR + 0x08)
	Bank 0 - Memory information register.
#define	LAN91_RPCR   (LAN91_BASE_ADDR + 0x0A)
	Bank 0 - Receive / PHY control register.
#define	LAN91_RPCR_SPEED   0x2000
#define	LAN91_RPCR_DPLX   0x1000
#define	LAN91_RPCR_ANEG   0x0800
#define	LAN91_RPCR_LEDA_PAT   0x0000
#define	LAN91_RPCR_LEDB_PAT   0x0010
#define	LAN91_CR   (LAN91_BASE_ADDR + 0x00)
	Bank 1 - Configuration register.
#define	LAN91_CR_EPH_EN   0x8000
#define	LAN91_BAR   (LAN91_BASE_ADDR + 0x02)
	Bank 1 - Base address register.
#define	LAN91_IAR   (LAN91_BASE_ADDR + 0x04)
	Bank 1 - Individual address register.
#define	LAN91_GPR   (LAN91_BASE_ADDR + 0x0A)
	Bank 1 - General purpose register.
#define	LAN91_CTR   (LAN91_BASE_ADDR + 0x0C)
	Bank 1 - Control register.
#define	LAN91_CTR_RCV_BAD   0x4000
#define	LAN91_CTR_AUTO_RELEASE   0x0800
#define	LAN91_MMUCR   (LAN91_BASE_ADDR + 0x00)
	Bank 2 - MMU command register.
#define	LAN91_MMUCR_BUSY   0x0001
#define	LAN91_MMU_NOP   0
#define	LAN91_MMU_ALO   (1<<5)
#define	LAN91_MMU_RST   (2<<5)
#define	LAN91_MMU_REM   (3<<5)
#define	LAN91_MMU_TOP   (4<<5)
#define	LAN91_MMU_PKT   (5<<5)
#define	LAN91_MMU_ENQ   (6<<5)
#define	LAN91_MMU_RTX   (7<<5)
#define	LAN91_PNR   (LAN91_BASE_ADDR + 0x02)
	Bank 2 - Packet number register.
#define	LAN91_ARR   (LAN91_BASE_ADDR + 0x03)
	Bank 2 - Allocation result register.
#define	LAN91_ARR_FAILED   0x80
#define	LAN91_FIFO   (LAN91_BASE_ADDR + 0x04)
	Bank 2 - FIFO ports register.
#define	LAN91_PTR   (LAN91_BASE_ADDR + 0x06)
	Bank 2 - Pointer register.
#define	LAN91_PTR_RCV   0x8000
#define	LAN91_PTR_AUTO_INCR   0x4000
#define	LAN91_PTR_READ   0x2000
#define	LAN91_PTR_ETEN   0x1000
#define	LAN91_PTR_NOT_EMPTY   0x0800
#define	LAN91_DATA   (LAN91_BASE_ADDR + 0x08)
	Bank 2 - Data register.
#define	LAN91_IST   (LAN91_BASE_ADDR + 0x0C)
	Bank 2 - Interrupt status register.
#define	LAN91_ACK   (LAN91_BASE_ADDR + 0x0C)
	Bank 2 - Interrupt acknowledge register.
#define	LAN91_MSK   (LAN91_BASE_ADDR + 0x0D)
	Bank 2 - Interrupt mask register.
#define	LAN91_INT_MD   0x80
	PHY state change interrupt bit mask.
#define	LAN91_INT_ERCV   0x40
	Early receive interrupt bit mask.
#define	LAN91_INT_EPH   0x20
	Ethernet protocol interrupt bit mask.
#define	LAN91_INT_RX_OVRN   0x10
	Receive overrun interrupt bit mask.
#define	LAN91_INT_ALLOC   0x08
	Transmit allocation interrupt bit mask.
#define	LAN91_INT_TX_EMPTY   0x04
	Transmitter empty interrupt bit mask.
#define	LAN91_INT_TX   0x02
	Transmit complete interrupt bit mask.
#define	LAN91_INT_RCV   0x01
	Receive interrupt bit mask.
#define	LAN91_MT   (LAN91_BASE_ADDR + 0x00)
	Bank 3 - Multicast table register.
#define	LAN91_MGMT   (LAN91_BASE_ADDR + 0x08)
	Bank 3 - Management interface register.
#define	LAN91_MGMT_MDOE   0x08
#define	LAN91_MGMT_MCLK   0x04
#define	LAN91_MGMT_MDI   0x02
#define	LAN91_MGMT_MDO   0x01
#define	LAN91_REV   (LAN91_BASE_ADDR + 0x0A)
	Bank 3 - Revision register.
#define	LAN91_ERCV   (LAN91_BASE_ADDR + 0x0C)
	Bank 3 - Early RCV register.
#define	LAN91_PHYCR   0
	PHY control register.
#define	LAN91_PHYCR_RST   0x8000
#define	LAN91_PHYCR_LPBK   0x4000
#define	LAN91_PHYCR_SPEED   0x2000
#define	LAN91_PHYCR_ANEG_EN   0x1000
#define	LAN91_PHYCR_PDN   0x0800
#define	LAN91_PHYCR_MII_DIS   0x0400
#define	LAN91_PHYCR_ANEG_RST   0x0200
#define	LAN91_PHYCR_DPLX   0x0100
#define	LAN91_PHYCR_COLST   0x0080
#define	LAN91_PHYSR   1
	PHY status register.
#define	LAN91_PHYSR_CAP_T4   0x8000
#define	LAN91_PHYSR_CAP_TXF   0x4000
#define	LAN91_PHYSR_CAP_TXH   0x2000
#define	LAN91_PHYSR_CAP_TF   0x1000
#define	LAN91_PHYSR_CAP_TH   0x0800
#define	LAN91_PHYSR_CAP_SUPR   0x0040
#define	LAN91_PHYSR_ANEG_ACK   0x0020
#define	LAN91_PHYSR_REM_FLT   0x0010
#define	LAN91_PHYSR_CAP_ANEG   0x0008
#define	LAN91_PHYSR_LINK   0x0004
#define	LAN91_PHYSR_JAB   0x0002
#define	LAN91_PHYSR_EXREG   0x0001
#define	LAN91_PHYID1   2
	PHY identifier register 1.
#define	LAN91_PHYID2   3
	PHY identifier register 1.
#define	LAN91_PHYANAD   4
	PHY auto-negotiation advertisement register.
#define	LAN91_PHYANAD_NP   0x8000
#define	LAN91_PHYANAD_ACK   0x4000
#define	LAN91_PHYANAD_RF   0x2000
#define	LAN91_PHYANAD_T4   0x0200
#define	LAN91_PHYANAD_TX_FDX   0x0100
#define	LAN91_PHYANAD_TX_HDX   0x0080
#define	LAN91_PHYANAD_10FDX   0x0040
#define	LAN91_PHYANAD_10_HDX   0x0020
#define	LAN91_PHYANAD_CSMA   0x0001
#define	LAN91_PHYANRC   5
	PHY auto-negotiation remote end capability register.
#define	LAN91_PHYCFR1   16
	PHY configuration register 1.
#define	LAN91_PHYCFR2   17
	PHY configuration register 2.
#define	LAN91_PHYSOR   18
	PHY status output register.
#define	LAN91_PHYSOR_INT   0x8000
#define	LAN91_PHYSOR_LNKFAIL   0x4000
#define	LAN91_PHYSOR_LOSSSYNC   0x2000
#define	LAN91_PHYSOR_CWRD   0x1000
#define	LAN91_PHYSOR_SSD   0x0800
#define	LAN91_PHYSOR_ESD   0x0400
#define	LAN91_PHYSOR_RPOL   0x0200
#define	LAN91_PHYSOR_JAB   0x0100
#define	LAN91_PHYSOR_SPDDET   0x0080
#define	LAN91_PHYSOR_DPLXDET   0x0040
#define	LAN91_PHYMSK   19
	PHY mask register.
#define	LAN91_PHYMSK_MINT   0x8000
#define	LAN91_PHYMSK_MLNKFAIL   0x4000
#define	LAN91_PHYMSK_MLOSSSYN   0x2000
#define	LAN91_PHYMSK_MCWRD   0x1000
#define	LAN91_PHYMSK_MSSD   0x0800
#define	LAN91_PHYMSK_MESD   0x0400
#define	LAN91_PHYMSK_MRPOL   0x0200
#define	LAN91_PHYMSK_MJAB   0x0100
#define	LAN91_PHYMSK_MSPDDT   0x0080
#define	LAN91_PHYMSK_MDPLDT   0x0040
#define	DEV_ETHER   devLan91
Variables
NUTDEVICE	devLan91
	Device information structure.

---

Define Documentation

#define DEV_ETHER   devLan91

Definition at line 372 of file lan91.h.
