Nut/OS  4.10.3
API Reference
phatdir.h File Reference

PHAT file system. More...

#include <dirent.h>
#include <sys/stat.h>
Include dependency graph for phatdir.h:
This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Data Structures

 Structure of a directory entry. More...
 Structure of an extended directory entry. More...
struct  _PHATFIND


#define PHAT_MAX_NAMELEN   255
 Maximum length of a base file name.
#define PHAT_REM_DIRENT   0xE5
#define PHAT_REM_NAMENT   0x05


 Structure of a directory entry.
 Structure of an extended directory entry.
typedef struct _PHATFIND PHATFIND


int PhatDirEntryCreate (NUTFILE *ndp, CONST char *name, int acc, PHATDIRENT *dirent)
 Create a new directory entry.
int PhatDirEntryUpdate (NUTFILE *ndp)
 Update directory entry of an opened file or directory.
int PhatDirReleaseChain (NUTDEVICE *dev, PHATDIRENT *dent)
 Release a cluster chain of a specified directory entry.
int PhatDirDelEntry (NUTDEVICE *dev, CONST char *path, uint32_t flags)
 Remove a directory entry.
int PhatDirRenameEntry (NUTDEVICE *dev, CONST char *old_path, CONST char *new_path)
 Rename file.
NUTFILEPhatDirOpen (NUTDEVICE *dev, CONST char *dpath)
 Open a directory.
NUTFILEPhatDirOpenParent (NUTDEVICE *dev, CONST char *path, CONST char **basename)
 Open parent directory of a given path.
int PhatDirEntryFind (NUTFILE *nfp, CONST char *spec, uint32_t flags, PHATFIND *srch)
 Find a directory entry with a specified name.
int PhatDirRead (DIR *dir)
 Read the next directory entry.
int PhatDirCreate (NUTDEVICE *dev, char *path)
 Create a new subdirectory.
int PhatDirRemove (NUTDEVICE *dev, char *path)
 Remove a specified subdirectory.
int PhatDirEntryStatus (NUTDEVICE *dev, CONST char *path, struct stat *s)
 Retrieve status of a specified file.

Detailed Description

PHAT file system.

 * $Log$
 * Revision 1.4  2008/08/11 07:00:19  haraldkipp
 * BSD types replaced by stdint types (feature request #1282721).
 * Revision 1.3  2006/10/08 16:42:56  haraldkipp
 * Not optimal, but simple and reliable exclusive access implemented.
 * Fixes bug #1486539. Furthermore, bug #1567790, which had been rejected,
 * had been reported correctly and is now fixed.
 * Revision 1.2  2006/06/18 16:41:55  haraldkipp
 * Support for long filenames (VFAT) added.
 * New function PhatDirReleaseChain() simplifies code.
 * Static function PhatDirOpenParentPath() replaced by global
 * PhatDirOpenParent().
 * Added const attribute to path parameter of PhatDirOpen().
 * Revision 1.1  2006/01/05 16:32:52  haraldkipp
 * First check-in.

Definition in file phatdir.h.
