Routines for Atmel AT45 serial DataFlash memory chips. More...

#include <cfg/os.h>
#include <cfg/memory.h>
#include <dev/blockdev.h>
#include <sys/nutdebug.h>
#include <sys/timer.h>
#include <string.h>
#include <dev/at45d.h>
#include <dev/spi_at45d.h>

Include dependency graph for spi_at45d.c:

Go to the source code of this file.

Defines
#define	AT45_WRITE_POLLS 1000
Functions
int	SpiAt45dCommand (NUTDEVICE dev, uint8_t op, uint32_t parm, int oplen, CONST void txbuf, void *rxbuf, int xlen)
	Send DataFlash command.
uint8_t	SpiAt45dStatus (NUTDEVICE *dev)
	Query the status of the DataFlash.
int	SpiAt45dWaitReady (NUTDEVICE *dev, uint32_t tmo, int poll)
	Wait until DataFlash memory cycle finished.
int	SpiAt45dPageErase (NUTDEVICE *dev, uint32_t pgn)
	Erase specified DataFlash page.
int	SpiAt45dChipErase (NUTDEVICE *dev)
	Erase all DataFlash pages.
int	SpiAt45dInit (NUTDEVICE *dev)
	Initialize the DataFlash device.
int	SpiAt45dPageRead (NUTDEVICE dev, uint32_t pgn, void data, int len)
	Read data from DataFlash memory.
int	SpiAt45dPageWrite (NUTDEVICE dev, uint32_t pgn, CONST void data, int len)
	Write data to DataFlash memory.
int	SpiAt45dPageWrite_P (NUTDEVICE *dev, uint32_t pgn, PGM_P data, int len)
uint32_t	SpiAt45dPages (NUTDEVICE *dev)
	Return the number of pages.
int	SpiAt45dPageSize (NUTDEVICE *dev)
	Return the page size.
int	SpiAt45dIOCtl (NUTDEVICE dev, int req, void conf)
	Perform block I/O device control functions.

Detailed Description

Routines for Atmel AT45 serial DataFlash memory chips.

 * $Id: spi_at45d.c 3653 2011-11-14 15:20:31Z haraldkipp $
 *

Definition in file spi_at45d.c.

Define Documentation

#define AT45_WRITE_POLLS 1000

Definition at line 59 of file spi_at45d.c.

Referenced by SpiAt45dPageWrite().

Function Documentation

int SpiAt45dCommand	(	NUTDEVICE *	dev,
		uint8_t	op,
		uint32_t	parm,
		int	oplen,
		CONST void *	txbuf,
		void *	rxbuf,
		int	xlen
	)

Send DataFlash command.

Parameters:

dev	Specifies the DataFlash device.
op	Command operation code.
parm	Optional command parameter.
oplen	Command length.
txbuf	Pointer to the transmit data buffer, may be set to NULL.
rxbuf	Pointer to the receive data buffer, may be set to NULL.
xlen	Number of byte to receive and/or transmit.

Definition at line 197 of file spi_at45d.c.

References _NUTDEVICE::dev_icb, and NUTASSERT.

uint8_t SpiAt45dStatus ( NUTDEVICE * dev )

Query the status of the DataFlash.

Parameters:

dev	Specifies the Flash device.

Returns:: 0 on success or -1 in case of an error.

Definition at line 210 of file spi_at45d.c.

References _NUTDEVICE::dev_icb, and NUTASSERT.

int SpiAt45dWaitReady	(	NUTDEVICE *	dev,
		uint32_t	tmo,
		int	poll
	)

Wait until DataFlash memory cycle finished.

Parameters:

dev	Specifies the DataFlash device.

Returns:: 0 on success or -1 in case of an error.

Definition at line 223 of file spi_at45d.c.

References _NUTDEVICE::dev_icb, and NUTASSERT.

int SpiAt45dPageErase	(	NUTDEVICE *	dev,
		uint32_t	pgn
	)

Erase specified DataFlash page.

Parameters:

dev	Specifies the registered DataFlash device.
pgn	Page number to erase, starting at 0.

Returns:: 0 on success or -1 in case of an error.

Definition at line 237 of file spi_at45d.c.

References _NUTBLOCKIO::blkio_info, _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, DFCMD_PAGE_ERASE, and NUTASSERT.

int SpiAt45dChipErase ( NUTDEVICE * dev )

Erase all DataFlash pages.

Definition at line 259 of file spi_at45d.c.

int SpiAt45dInit ( NUTDEVICE * dev )

Initialize the DataFlash device.

This routine determines the DataFlash type. It is internally called by Nut/OS during device registration.

The driver framework may call this function more than once.

Parameters:

dev	Specifies the DataFlash device.

Returns:: 0 on success or -1 if no valid DataFlash was found.

Definition at line 276 of file spi_at45d.c.

References at45d_info, at45d_known_types, AT45D_STATUS_DENSITY, AT45D_STATUS_PAGE_SIZE, _NUTBLOCKIO::blkio_blk_cnt, _NUTBLOCKIO::blkio_blk_siz, _NUTBLOCKIO::blkio_info, _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, and NUTASSERT.

int SpiAt45dPageRead	(	NUTDEVICE *	dev,
		uint32_t	pgn,
		void *	data,
		int	len
	)

Read data from DataFlash memory.

Parameters:

dev	Specifies the registered DataFlash device.
pgn	Page number to read, starting at 0.
data	Points to a buffer that receives the data.
len	Number of bytes to read.

Returns:: The number of bytes actually read. A return value of -1 indicates an error.

Definition at line 320 of file spi_at45d.c.

References _NUTBLOCKIO::blkio_info, _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, DFCMD_CONT_READ, and NUTASSERT.

Referenced by SpiAt45dConfigRead(), and SpiAt45dConfigWrite().

int SpiAt45dPageWrite	(	NUTDEVICE *	dev,
		uint32_t	pgn,
		CONST void *	data,
		int	len
	)

Write data to DataFlash memory.

Each page will be automatically erased before writing the data. If the last page is not completely filled with new data, the contents of remaining bytes at the end of the page is undetermined.

Parameters:

dev	Specifies the registered DataFlash device.
pgn	The page number.
data	Points to the buffer that contains the bytes to be written.
len	Number of bytes available in the buffer. This may be less than the page size, in which case the remaining bytes of the page will be set to 0xff.

Returns:: The number of bytes actually written. A return value of -1 indicates an error.

Definition at line 360 of file spi_at45d.c.

References AT45_WRITE_POLLS, _NUTBLOCKIO::blkio_info, _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, DFCMD_BUF1_FLASH, DFCMD_BUF1_WRITE, and NUTASSERT.

Referenced by SpiAt45dConfigWrite().

int SpiAt45dPageWrite_P	(	NUTDEVICE *	dev,
		uint32_t	pgn,
		PGM_P	data,
		int	len
	)

Definition at line 414 of file spi_at45d.c.

uint32_t SpiAt45dPages ( NUTDEVICE * dev )

Return the number of pages.

Parameters:

dev	Specifies the registered DataFlash device.

Returns:: The total number of pages available in this device.

Definition at line 427 of file spi_at45d.c.

References _NUTBLOCKIO::blkio_info, _NUTDEVICE::dev_dcb, and NUTASSERT.

int SpiAt45dPageSize ( NUTDEVICE * dev )

Return the page size.

Parameters:

dev	Specifies the registered DataFlash device.

Returns:: The number of bytes per page.

Definition at line 446 of file spi_at45d.c.

References _NUTBLOCKIO::blkio_info, _NUTDEVICE::dev_dcb, and NUTASSERT.

Referenced by SpiAt45dConfigSize(), and SpiAt45dConfigWrite().

int SpiAt45dIOCtl	(	NUTDEVICE *	dev,
		int	req,
		void *	conf
	)

Perform block I/O device control functions.

This function is called by the ioctl() function of the C runtime library. Applications should not directly call this function.

Parameters:

dev	Identifies the device that receives the control command.
req	Requested control command. May be set to one of the following constants: NUTBLKDEV_MEDIAAVAIL NUTBLKDEV_MEDIACHANGE
conf	Points to a buffer that contains any data required for the given control function or receives data from that function.

Returns:: 0 on success, -1 otherwise.

Definition at line 475 of file spi_at45d.c.

References NUTASSERT, NUTBLKDEV_MEDIAAVAIL, and NUTBLKDEV_MEDIACHANGE.
