_NUTTIMERINFO Struct Reference

Timer information structure. More...

#include <sys/timer.h>

Collaboration diagram for _NUTTIMERINFO:

Data Fields
NUTTIMERINFO *	tn_next
	Link to next timer.
NUTTIMERINFO *	tn_prev
	Link to previous timer.
uint32_t	tn_ticks
	Number of system ticks. Set to zero on one-shot timers.
uint32_t	tn_ticks_left
	Decremented by one on each system tick intervall.
void(*	tn_callback )(HANDLE, void *)
	Callback function.
volatile void *	tn_arg
	Argument pointer passed to callback function.

---

Detailed Description

Timer information structure.

Examples:

httpd/httpserv.c.

Definition at line 127 of file timer.h.

---

Field Documentation

NUTTIMERINFO* _NUTTIMERINFO::tn_next

Link to next timer.

Examples:

httpd/httpserv.c.

Definition at line 130 of file timer.h.

Referenced by NutTimerInsert(), NutTimerProcessElapsed(), and NutTimerStop().

NUTTIMERINFO* _NUTTIMERINFO::tn_prev

Link to previous timer.

Definition at line 133 of file timer.h.

Referenced by NutTimerInsert(), NutTimerProcessElapsed(), and NutTimerStop().

uint32_t _NUTTIMERINFO::tn_ticks

Number of system ticks. Set to zero on one-shot timers.

Examples:

httpd/httpserv.c.

Definition at line 137 of file timer.h.

Referenced by NutDumpTimerList(), NutTimerCreate(), NutTimerProcessElapsed(), and NutTimerStop().

uint32_t _NUTTIMERINFO::tn_ticks_left

Decremented by one on each system tick intervall.

Examples:

httpd/httpserv.c.

Definition at line 140 of file timer.h.

Referenced by NutTimerCreate(), NutTimerInsert(), NutTimerProcessElapsed(), and NutTimerStop().

void(* _NUTTIMERINFO::tn_callback)(HANDLE, void *)

Callback function.

Definition at line 143 of file timer.h.

Referenced by NutTimerCreate(), NutTimerProcessElapsed(), and NutTimerStop().

volatile void* _NUTTIMERINFO::tn_arg

Argument pointer passed to callback function.

Definition at line 146 of file timer.h.

Referenced by NutTimerCreate(), and NutTimerProcessElapsed().

---

The documentation for this struct was generated from the following file:

• include/sys/timer.h
