usart.h File Reference

Synchronous/asynchronous serial device definitions. More...

#include <dev/uart.h>

Include dependency graph for usart.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Data Structures
struct	_RINGBUF
	Character device ring buffer structure. More...
struct	_USARTDCB
	USART device low level information structure. More...
Defines
#define	USART_MF_RTSCONTROL   0x0001
#define	USART_MF_CTSSENSE   0x0002
#define	USART_MF_DTRCONTROL   0x0004
#define	USART_MF_DSRSENSE   0x0008
#define	USART_MF_DCDSENSE   0x0010
#define	USART_MF_SENSEMASK   0x001A
#define	USART_MF_CONTROLMASK   0x0005
#define	USART_MF_XONXOFF   0x0020
	Software handshake.
#define	USART_MF_LOCALECHO   0x0040
#define	USART_MF_COOKEDMODE   0x0080
#define	USART_MF_NOBUFFER   0x0100
#define	USART_MF_LINEBUFFER   0x0200
#define	USART_MF_BUFFERMASK   0x0300
#define	USART_MF_HALFDUPLEX   0x0400
#define	USART_MF_BLOCKREAD   0x0800
#define	USART_SF_RTSOFF   0x0001
#define	USART_SF_CTSOFF   0x0002
#define	USART_SF_DTROFF   0x0004
#define	USART_SF_DSROFF   0x0008
#define	USART_SF_DCDOFF   0x0010
#define	USART_SF_TXDISABLED   0x0040
#define	USART_SF_RXDISABLED   0x0080
Typedefs
typedef struct _USARTDCB	USARTDCB
Ring Buffer
#define	USART_RXBUFSIZ   256
	Initial receive buffer size.
#define	USART_RXHIWMARK   240
	Receiver's initial high water mark.
#define	USART_RXLOWMARK   208
	Receiver's initial low water mark.
#define	USART_TXBUFSIZ   64
	Initial transmit buffer size.
#define	USART_TXHIWMARK   56
	Transmitter's initial high water mark.
#define	USART_TXLOWMARK   40
	Transmitter's initial low water mark.
typedef struct _RINGBUF	RINGBUF
	Character device ring buffer type.
Initial UART Configuration
#define	USART_INITSPEED   115200
	Initial bit rate.
Function Prototypes
int	UsartInit (NUTDEVICE *dev)
	Initialize the USART device.
int	UsartIOCtl (NUTDEVICE *dev, int req, void *conf)
	Perform USART control functions.
int	UsartRead (NUTFILE *fp, void *buffer, int size)
	Read from device.
int	UsartWrite (NUTFILE *fp, CONST void *buffer, int len)
	Write a device or file.
int	UsartWrite_P (NUTFILE *fp, PGM_P buffer, int len)
	Write a device or file.
NUTFILE *	UsartOpen (NUTDEVICE *dev, CONST char *name, int mode, int acc)
	Open an USART device.
int	UsartClose (NUTFILE *fp)
	Close an USART device.
long	UsartSize (NUTFILE *fp)
	Retrieves the number of characters in input buffer.

---

Detailed Description

Synchronous/asynchronous serial device definitions.

Definition in file usart.h.
