This graph shows which files directly or indirectly include this file:

MMC Control Register
#define	MCI_CR_OFF 0x00000000
	Control register offset.
#define	MCI_CR (MCI_BASE + MCI_CR_OFF)
	Control register address.
#define	MCI_MCIEN 0x00000001
	Interface enable.
#define	MCI_MCIDIS 0x00000002
	Interface disable.
#define	MCI_PWSEN 0x00000004
	Power save mode enable.
#define	MCI_PWSDIS 0x00000008
	Power save mode disable.
#define	MCI_SWRST 0x00000080
	Software reset.
MMC Mode Register
#define	MCI_MR_OFF 0x00000004
	Mode register offset.
#define	MCI_MR (MCI_BASE + MCI_MR_OFF)
	Mode register address.
#define	MCI_CLKDIV 0x000000FF
	Clock divider mask.
#define	MCI_CLKDIV_LSB 0
	Clock divider LSB.
#define	MCI_PWSDIV 0x00000700
	Power saving divider mask.
#define	MCI_PWSDIV_LSB 8
	Power saving divider LSB.
#define	MCI_RDPROOF 0x00000800
	Enable read proof.
#define	MCI_WRPROOF 0x00001000
	Enable write proof.
#define	MCI_PDCFBYTE 0x00002000
	Force PDC byte transfer.
#define	MCI_PDCPADV 0x00004000
	PDC padding value.
#define	MCI_PDCMODE 0x00008000
	PDC-oriented mode.
#define	MCI_BLKLEN 0xFFFF0000
	Data block length mask.
#define	MCI_BLKLEN_LSB 16
	Data block length LSB.
MMC Data Timeout Register
#define	MCI_DTOR_OFF 0x00000008
	Data timeout register offset.
#define	MCI_DTOR (MCI_BASE + MCI_DTOR_OFF)
	Data timeout register address.
#define	MCI_DTOCYC 0x0000000F
	Data timeout cycle number mask.
#define	MCI_DTOCYC_LSB 0
	Data timeout cycle number LSB.
#define	MCI_DTOMUL 0x00000070
	Data timeout multiplier mask.
#define	MCI_DTOMUL_1 0x00000000
	Data timeout multiplier 1.
#define	MCI_DTOMUL_16 0x00000010
	Data timeout multiplier 16.
#define	MCI_DTOMUL_128 0x00000020
	Data timeout multiplier 128.
#define	MCI_DTOMUL_256 0x00000030
	Data timeout multiplier 256.
#define	MCI_DTOMUL_1K 0x00000040
	Data timeout multiplier 1024.
#define	MCI_DTOMUL_4K 0x00000050
	Data timeout multiplier 4096.
#define	MCI_DTOMUL_64K 0x00000060
	Data timeout multiplier 65536.
#define	MCI_DTOMUL_1M 0x00000070
	Data timeout multiplier 1048576.
MMC SDCard/SDIO Register
#define	MCI_SDCR_OFF 0x0000000C
	SDC/SDIO register offset.
#define	MCI_SDCR (MCI_BASE + MCI_SDCR_OFF)
	SDC/SDIO register address.
#define	MCI_SDCSEL 0x00000003
	SDC/SDIO slot mask.
#define	MCI_SDCSEL_SLOTA 0x00000000
	Slot A selected.
#define	MCI_SDCSEL_SLOTB 0x00000001
	Slot B selected.
#define	MCI_SDCBUS 0x00000080
	SDC/SDIO 4-bit bus.
MMC Argument Register
#define	MCI_ARGR_OFF 0x00000010
	Argument register offset.
#define	MCI_ARGR (MCI_BASE + MCI_ARGR_OFF)
	Argument register address.
MMC Command Register
#define	MCI_CMDR_OFF 0x00000014
	Command register offset.
#define	MCI_CMDR (MCI_BASE + MCI_CMDR_OFF)
	Command register address.
#define	MCI_CMDNB 0x0000003F
	Command number mask.
#define	MCI_CMDNB_LSB 0
	Command number LSB.
#define	MCI_RSPTYP 0x000000C0
	Response type mask.
#define	MCI_RSPTYP_NONE 0x00000000
	No response.
#define	MCI_RSPTYP_48 0x00000040
	48-bit response.
#define	MCI_RSPTYP_136 0x00000080
	136-bit response.
#define	MCI_SPCMD 0x00000700
	Special command mask.
#define	MCI_SPCMD_NONE 0x00000000
	Not a special command.
#define	MCI_SPCMD_INIT 0x00000100
	Initialization command.
#define	MCI_SPCMD_SYNC 0x00000200
	Synchronized command.
#define	MCI_SPCMD_ICMD 0x00000400
	Interrupt command.
#define	MCI_SPCMD_IRSP 0x00000500
	Interrupt response.
#define	MCI_OPDCMD 0x00000800
	Open drain command.
#define	MCI_OPCMD MCI_OPDCMD
	Open drain command. Deprecated spelling.
#define	MCI_MAXLAT 0x00001000
	Maximum latency for command to response.
#define	MCI_TRCMD 0x00030000
	Transfer command mask.
#define	MCI_TRCMD_NONE 0x00000000
	No data transfer.
#define	MCI_TRCMD_START 0x00010000
	Start data transfer.
#define	MCI_TRCMD_STOP 0x00020000
	Stop data transfer.
#define	MCI_TRDIR 0x00040000
	Read transfer.
#define	MCI_TRTYP 0x00380000
	Transfer type mask.
#define	MCI_TRTYP_MMC_SBLK 0x00000000
	MMC/SDC single block transfer.
#define	MCI_TRTYP_MMC_MBLK 0x00080000
	MMC/SDC multiple block transfer.
#define	MCI_TRTYP_MMC_STREAM 0x00100000
	MMC stream transfer.
#define	MCI_TRTYP_SDIO_BYTE 0x00200000
	SDIO byte transfer.
#define	MCI_TRTYP_SDIO_BLK 0x00280000
	SDIO block transfer.
#define	MCI_IOSPCMD 0x03000000
	Specila SDIO command mask.
#define	MCI_IOSPCMD_NONE 0x00000000
	Not a special SDIO command.
#define	MCI_IOSPCMD_SUSPEND 0x01000000
	SDIO suspend command.
#define	MCI_IOSPCMD_RESUME 0x02000000
	SDIO resume command.
MMC Block Register
#define	MCI_BLKR_OFF 0x00000018
	Block register offset.
#define	MCI_BLKR (MCI_BASE + MCI_BLKR_OFF)
	Block register address.
#define	MCI_BCNT 0x0000FFFF
	MMC/SDIO block count or SDIO byte count mask.
#define	MCI_BCNT_LSB 0
	MMC/SDIO block count or SDIO byte count LSB.
MMC Response Register
#define	MCI_RSPR_OFF 0x00000020
	Response register offset.
#define	MCI_RSPR (MCI_BASE + MCI_RSPR_OFF)
	Response register address.
MMC Receive Data Register
#define	MCI_RDR_OFF 0x00000030
	Receive data register offset.
#define	MCI_RDR (MCI_BASE + MCI_RDR_OFF)
	Receive data register address.
MMC Transmit Data Register
#define	MCI_TDR_OFF 0x00000034
	Transmit data register offset.
#define	MCI_TDR (MCI_BASE + MCI_TDR_OFF)
	Transmit data register address.
MMC Interrupt and Status Registers
#define	MCI_SR_OFF 0x00000040
	Status register offset.
#define	MCI_SR (MCI_BASE + MCI_SR_OFF)
	Status register address.
#define	MCI_IER_OFF 0x00000044
	Enable register offset.
#define	MCI_IER (MCI_BASE + MCI_IER_OFF)
	Enable register address.
#define	MCI_IDR_OFF 0x00000048
	Disable register offset.
#define	MCI_IDR (MCI_BASE + MCI_IDR_OFF)
	Disable register address.
#define	MCI_IMR_OFF 0x0000004C
	Mask register offset.
#define	MCI_IMR (MCI_BASE + MCI_IMR_OFF)
	Mask register address.
#define	MCI_CMDRDY 0x00000001
	Command ready.
#define	MCI_RXRDY 0x00000002
	Receiver ready.
#define	MCI_TXRDY 0x00000004
	Transmit ready.
#define	MCI_BLKE 0x00000008
	Data block ended.
#define	MCI_DTIP 0x00000010
	Data transfer in progress.
#define	MCI_NOTBUSY 0x00000020
	MCI not busy.
#define	MCI_ENDRX 0x00000040
	End of receive buffer.
#define	MCI_ENDTX 0x00000080
	End of transmit buffer.
#define	MCI_SDIOIRQA 0x00000100
	Undocumented.
#define	MCI_SDIOIRQB 0x00000200
	Undocumented.
#define	MCI_RXBUFF 0x00004000
	Receive buffer full.
#define	MCI_TXBUFE 0x00008000
	Transmit buffer empty.
#define	MCI_RINDE 0x00010000
	Response index error.
#define	MCI_RDIRE 0x00020000
	Response direction error.
#define	MCI_RCRCE 0x00040000
	Response CRC error.
#define	MCI_RENDE 0x00080000
	Response end bit error.
#define	MCI_RTOE 0x00100000
	Response timeout error.
#define	MCI_DCRCE 0x00200000
	Data CRC error.
#define	MCI_DTOE 0x00400000
	Date timeout error.
#define	MCI_OVRE 0x40000000
	Overrun error.
#define	MCI_UNRE 0x80000000
	Underrun error.
