#include <arch/arm/v5te.h>#include <arch/arm/atmel/at91_tc.h>#include <arch/arm/atmel/at91_us.h>#include <arch/arm/atmel/at91_dbgu.h>#include <arch/arm/atmel/at91_emac.h>#include <arch/arm/atmel/at91_spi.h>#include <arch/arm/atmel/at91_aic.h>#include <arch/arm/atmel/at91_pio.h>#include <arch/arm/atmel/at91_pmc.h>#include <arch/arm/atmel/at91_rstc.h>#include <arch/arm/atmel/at91_wdt.h>#include <arch/arm/atmel/at91_ssc.h>#include <arch/arm/atmel/at91_twi.h>#include <arch/arm/atmel/at91_smc.h>#include <arch/arm/atmel/at91_mci.h>#include <arch/arm/atmel/at91_matrix.h>#include <arch/arm/atmel/at91_ccfg.h>#include <arch/arm/atmel/at91_sdramc.h>#include <arch/arm/atmel/at91_adc.h>
Go to the source code of this file.
Defines | |
| #define | FLASH_BASE 0x100000UL |
| #define | RAM_BASE 0x200000UL |
| #define | TC_BASE 0xFFFA0000 |
| Timer/counter base address. | |
| #define | UDP_BASE 0xFFFA4000 |
| USB device port base address. | |
| #define | MCI_BASE 0xFFFA8000 |
| MMC/SDCard interface base address. | |
| #define | TWI_BASE 0xFFFAC000 |
| Two-wire interface base address. | |
| #define | USART0_BASE 0xFFFB0000 |
| USART 0 base address. | |
| #define | USART1_BASE 0xFFFB4000 |
| USART 1 base address. | |
| #define | USART2_BASE 0xFFFB8000 |
| USART 2 base address. | |
| #define | SSC_BASE 0xFFFBC000 |
| Serial synchronous controller base address. | |
| #define | ISI_BASE 0xFFFC0000 |
| Image sensor interface base address. | |
| #define | EMAC_BASE 0xFFFC4000 |
| EMAC base address. | |
| #define | SPI0_BASE 0xFFFC8000 |
| SPI0 0 base address. | |
| #define | SPI1_BASE 0xFFFCC000 |
| SPI0 1 base address. | |
| #define | USART3_BASE 0xFFFD0000 |
| USART 3 base address. | |
| #define | USART4_BASE 0xFFFD4000 |
| USART 4 base address. | |
| #define | USART5_BASE 0xFFFD8000 |
| USART 5 base address. | |
| #define | TC345_BASE 0xFFFDC000 |
| Timer/counter 3, 4 and 5 base address. | |
| #define | ADC_BASE 0xFFFE0000 |
| ADC base address. | |
| #define | ECC_BASE 0xFFFFE800 |
| ECC base address. | |
| #define | SDRAMC_BASE 0xFFFFEA00 |
| SDRAMC base address. | |
| #define | SMC_BASE 0xFFFFEC00 |
| SMC base address. | |
| #define | MATRIX_BASE 0xFFFFEE00 |
| MATRIX base address. | |
| #define | CCFG_BASE 0xFFFFEF10 |
| CCFG base address. | |
| #define | AIC_BASE 0xFFFFF000 |
| AIC base address. | |
| #define | DBGU_BASE 0xFFFFF200 |
| DBGU base address. | |
| #define | PIOA_BASE 0xFFFFF400 |
| PIO A base address. | |
| #define | PIOB_BASE 0xFFFFF600 |
| PIO B base address. | |
| #define | PIOC_BASE 0xFFFFF800 |
| PIO C base address. | |
| #define | PMC_BASE 0xFFFFFC00 |
| PMC base address. | |
| #define | RSTC_BASE 0xFFFFFD00 |
| Resect controller register base address. | |
| #define | RTT_BASE 0xFFFFFD20 |
| Realtime timer base address. | |
| #define | PIT_BASE 0xFFFFFD30 |
| Periodic interval timer base address. | |
| #define | WDT_BASE 0xFFFFFD40 |
| Watch Dog register base address. | |
| #define | PERIPH_RPR_OFF 0x00000100 |
| Receive pointer register offset. | |
| #define | PERIPH_RCR_OFF 0x00000104 |
| Receive counter register offset. | |
| #define | PERIPH_TPR_OFF 0x00000108 |
| Transmit pointer register offset. | |
| #define | PERIPH_TCR_OFF 0x0000010C |
| Transmit counter register offset. | |
| #define | PERIPH_RNPR_OFF 0x00000110 |
| Receive next pointer register offset. | |
| #define | PERIPH_RNCR_OFF 0x00000114 |
| Receive next counter register offset. | |
| #define | PERIPH_TNPR_OFF 0x00000118 |
| Transmit next pointer register offset. | |
| #define | PERIPH_TNCR_OFF 0x0000011C |
| Transmit next counter register offset. | |
| #define | PERIPH_PTCR_OFF 0x00000120 |
| PDC transfer control register offset. | |
| #define | PERIPH_PTSR_OFF 0x00000124 |
| PDC transfer status register offset. | |
| #define | PDC_RXTEN 0x00000001 |
| Receiver transfer enable. | |
| #define | PDC_RXTDIS 0x00000002 |
| Receiver transfer disable. | |
| #define | PDC_TXTEN 0x00000100 |
| Transmitter transfer enable. | |
| #define | PDC_TXTDIS 0x00000200 |
| Transmitter transfer disable. | |
| #define | DBGU_HAS_PDC |
| #define | SPI_HAS_PDC |
| #define | SSC_HAS_PDC |
| #define | USART_HAS_PDC |
| #define | USART_HAS_MODE |
| #define | MCI_HAS_PDC |
| #define | PMC_HAS_PLLB |
| #define | PMC_HAS_MDIV |
| #define | PIO_HAS_MULTIDRIVER |
| #define | PIO_HAS_PULLUP |
| #define | PIO_HAS_PERIPHERALSELECT |
| #define | PIO_HAS_OUTPUTWRITEENABLE |
Peripheral Identifiers and Interrupts | |
| #define | FIQ_ID 0 |
| Fast interrupt. | |
| #define | SYSC_ID 1 |
| System interrupt. | |
| #define | PIOA_ID 2 |
| Parallel I/O controller A. | |
| #define | PIOB_ID 3 |
| Parallel I/O controller B. | |
| #define | PIOC_ID 4 |
| Parallel I/O controller C. | |
| #define | ADC_ID 5 |
| Analog to digital converter. | |
| #define | US0_ID 6 |
| USART 0. | |
| #define | US1_ID 7 |
| USART 1. | |
| #define | US2_ID 8 |
| USART 2. | |
| #define | MCI_ID 9 |
| MMC interface. | |
| #define | UDP_ID 10 |
| USB device port. | |
| #define | TWI_ID 11 |
| Two wire interface. | |
| #define | SPI0_ID 12 |
| Serial peripheral 0. | |
| #define | SPI1_ID 13 |
| Serial peripheral 1. | |
| #define | SSC_ID 14 |
| Serial peripheral interface. | |
| #define | TC0_ID 17 |
| Timer/counter 0. | |
| #define | TC1_ID 18 |
| Timer/counter 1. | |
| #define | TC2_ID 19 |
| Timer/counter 2. | |
| #define | UHP_ID 20 |
| USB host port. | |
| #define | EMAC_ID 21 |
| Ethernet MAC. | |
| #define | ISI_ID 22 |
| Image sensor interface. | |
| #define | US3_ID 23 |
| USART 3. | |
| #define | US4_ID 24 |
| USART 4. | |
| #define | US5_ID 25 |
| USART 5. | |
| #define | TC3_ID 26 |
| Timer/counter 3. | |
| #define | TC4_ID 27 |
| Timer/counter 4. | |
| #define | TC5_ID 28 |
| Timer/counter 5. | |
| #define | IRQ0_ID 29 |
| External interrupt 0. | |
| #define | IRQ1_ID 30 |
| External interrupt 1. | |
| #define | IRQ2_ID 31 |
| External interrupt 2. | |
USART Peripheral Multiplexing | |
| #define | PA31_SCK0_A 31 |
| Channel 0 serial clock pin. | |
| #define | PB4_TXD0_A 4 |
| Channel 0 transmit data pin. | |
| #define | PB5_RXD0_A 5 |
| Channel 0 receive data pin. | |
| #define | PB27_CTS0_A 27 |
| Channel 0 clear to send pin. | |
| #define | PB26_RTS0_A 26 |
| Channel 0 request to send pin. | |
| #define | PB25_RI0_A 25 |
| Channel 0 ring indicator pin. | |
| #define | PB22_DSR0_A 22 |
| Channel 0 data set ready pin. | |
| #define | PB23_DCD0_A 23 |
| Channel 0 data carrier detect pin. | |
| #define | PB24_DTR0_A 24 |
| Channel 0 data terminal ready pin. | |
| #define | PA29_SCK1_A 29 |
| Channel 1 serial clock pin. | |
| #define | PB6_TXD1_A 6 |
| Channel 1 transmit data pin. | |
| #define | PB7_RXD1_A 7 |
| Channel 1 receive data pin. | |
| #define | PB29_CTS1_A 29 |
| Channel 1 clear to send pin. | |
| #define | PB28_RTS1_A 28 |
| Channel 1 request to send pin. | |
| #define | PA30_SCK2_A 30 |
| Channel 2 serial clock pin. | |
| #define | PB8_TXD2_A 8 |
| Channel 2 transmit data pin. | |
| #define | PB9_RXD2_A 9 |
| Channel 2 receive data pin. | |
| #define | PA5_CTS2_A 5 |
| Channel 2 clear to send pin. | |
| #define | PA4_RTS2_A 4 |
| Channel 2 request to send pin. | |
| #define | PC0_SCK3_B 0 |
| Channel 3 serial clock pin. | |
| #define | PB10_TXD3_A 10 |
| Channel 3 transmit data pin. | |
| #define | PB11_RXD3_A 11 |
| Channel 3 receive data pin. | |
| #define | PC10_CTS3_B 10 |
| Channel 3 clear to send pin. | |
| #define | PC8_RTS3_B 8 |
| Channel 3 request to send pin. | |
| #define | PA31_TXD4_B 31 |
| Channel 4 transmit data pin. | |
| #define | PA30_RXD4_B 30 |
| Channel 4 receive data pin. | |
| #define | PB12_TXD5_A 12 |
| Channel 5 transmit data pin. | |
| #define | PB13_RXD5_A 13 |
| Channel 5 receive data pin. | |
SPI Peripheral Multiplexing | |
| #define | PA0_SPI0_MISO_A 0 |
| Channel 0 master input slave output pin. | |
| #define | PA1_SPI0_MOSI_A 1 |
| Channel 0 master output slave input pin. | |
| #define | PA2_SPI0_SPCK_A 2 |
| Channel 0 serial clock pin. | |
| #define | PA3_SPI0_NPCS0_A 3 |
| Channel 0 chip select 0 pin. | |
| #define | PC11_SPI0_NPCS1_B 11 |
| Channel 0 chip select 1 pin. | |
| #define | PC16_SPI0_NPCS2_B 16 |
| Channel 0 chip select 2 pin. | |
| #define | PC17_SPI0_NPCS3_B 17 |
| Channel 0 chip select 3 pin. | |
| #define | SPI0_PINS _BV(PA0_SPI0_MISO_A) | _BV(PA1_SPI0_MOSI_A) | _BV(PA2_SPI0_SPCK_A) |
| #define | SPI0_PIO_BASE PIOA_BASE |
| #define | SPI0_PSR_OFF PIO_ASR_OFF |
| #define | SPI0_CS0_PIN _BV(PA3_SPI0_NPCS0_A) |
| #define | SPI0_CS0_PIO_BASE PIOA_BASE |
| #define | SPI0_CS0_PSR_OFF PIO_ASR_OFF |
| #define | SPI0_CS1_PIN _BV(PC11_SPI0_NPCS1_B) |
| #define | SPI0_CS1_PIO_BASE PIOC_BASE |
| #define | SPI0_CS1_PSR_OFF PIO_BSR_OFF |
| #define | PB0_SPI1_MISO_A 0 |
| Channel 1 master input slave output pin. | |
| #define | PB1_SPI1_MOSI_A 1 |
| Channel 1 master output slave input pin. | |
| #define | PB2_SPI1_SPCK_A 2 |
| Channel 1 serial clock pin. | |
| #define | PB3_SPI1_NPCS0_A 3 |
| Channel 1 chip select 0 pin. | |
| #define | PC5_SPI1_NPCS1_B 5 |
| Channel 1 chip select 1 pin. | |
| #define | PC18_SPI1_NPCS1_B 18 |
| Channel 1 chip select 1 pin. | |
| #define | PC4_SPI1_NPCS2_B 4 |
| Channel 1 chip select 2 pin. | |
| #define | PC19_SPI1_NPCS2_B 19 |
| Channel 1 chip select 2 pin. | |
| #define | PC3_SPI1_NPCS3_B 3 |
| Channel 1 chip select 3 pin. | |
| #define | PC20_SPI1_NPCS3_B 20 |
| Channel 1 chip select 3 pin. | |
| #define | SPI1_PINS _BV(PB0_SPI1_MISO_A) | _BV(PB1_SPI1_MOSI_A) | _BV(PB2_SPI1_SPCK_A) |
| #define | SPI1_PIO_BASE PIOB_BASE |
| #define | SPI1_PSR_OFF PIO_ASR_OFF |
| #define | SPI1_CS0_PIN _BV(PB3_SPI1_NPCS0_A) |
| #define | SPI1_CS0_PIO_BASE PIOB_BASE |
| #define | SPI1_CS0_PSR_OFF PIO_ASR_OFF |
| #define | SPI1_CS3_PIN _BV(PC3_SPI1_NPCS3_B) |
| #define | SPI1_CS3_PIO_BASE PIOC_BASE |
| #define | SPI1_CS3_PSR_OFF PIO_BSR_OFF |
Image Sensor Interface Peripheral Multiplexing | |
| #define | PB20_ISI_D0_B 20 |
| Image sensor data bit 0 pin. | |
| #define | PB21_ISI_D1_B 21 |
| Image sensor data bit 1 pin. | |
| #define | PB22_ISI_D2_B 22 |
| Image sensor data bit 2 pin. | |
| #define | PB23_ISI_D3_B 23 |
| Image sensor data bit 3 pin. | |
| #define | PB24_ISI_D4_B 24 |
| Image sensor data bit 4 pin. | |
| #define | PB25_ISI_D5_B 25 |
| Image sensor data bit 5 pin. | |
| #define | PB26_ISI_D6_B 26 |
| Image sensor data bit 6 pin. | |
| #define | PB27_ISI_D7_B 27 |
| Image sensor data bit 7 pin. | |
| #define | PB10_ISI_D8_B 10 |
| Image sensor data bit 8 pin. | |
| #define | PB11_ISI_D9_B 11 |
| Image sensor data bit 9 pin. | |
| #define | PB12_ISI_D10_B 12 |
| Image sensor data bit 10 pin. | |
| #define | PB13_ISI_D11_B 13 |
| Image sensor data bit 11 pin. | |
| #define | PB28_ISI_PCK_B 28 |
| Image sensor data clock pin. | |
| #define | PB29_ISI_VSYNC_B 29 |
| Image sensor vertical sync pin. | |
| #define | PB30_ISI_HSYNC_B 30 |
| Image sensor horizontal sync pin. | |
| #define | PB31_ISI_MCK_B 31 |
| Image sensor reference clock pin. | |
MultiMedia Card and SDCard Interface Peripheral Multiplexing | |
| #define | PA8_MCCK_A 8 |
| MultiMedia card clock pin. | |
| #define | PA7_MCCDA_A 7 |
| MultiMedia card slot A command pin. | |
| #define | PA6_MCDA0_A 6 |
| MultiMedia card slot A data bit 0 pin. | |
| #define | PA9_MCDA1_A 9 |
| MultiMedia card slot A data bit 1 pin. | |
| #define | PA10_MCDA2_A 10 |
| MultiMedia card slot A data bit 2 pin. | |
| #define | PA11_MCDA3_A 11 |
| MultiMedia card slot A data bit 3 pin. | |
| #define | PA1_MCCDB_B 1 |
| MultiMedia card slot B command pin. | |
| #define | PA0_MCDB0_B 0 |
| MultiMedia card slot B data bit 0 pin. | |
| #define | PA5_MCDB1_B 5 |
| MultiMedia card slot B data bit 1 pin. | |
| #define | PA4_MCDB2_B 4 |
| MultiMedia card slot B data bit 2 pin. | |
| #define | PA3_MCDB3_B 3 |
| MultiMedia card slot B data bit 3 pin. | |
EMAC Interface Peripheral Multiplexing | |
| #define | PA10_ETX2_B 10 |
| Transmit data bit 2 pin. | |
| #define | PA11_ETX3_B 11 |
| Transmit data bit 3 pin. | |
| #define | PA12_ETX0_A 12 |
| Transmit data bit 0 pin. | |
| #define | PA13_ETX1_A 13 |
| Transmit data bit 1 pin. | |
| #define | PA14_ERX0_A 14 |
| Receive data bit 0 pin. | |
| #define | PA15_ERX1_A 15 |
| Receive data bit 1 pin. | |
| #define | PA16_ETXEN_A 16 |
| Transmit enable pin. | |
| #define | PA17_ERXDV_A 17 |
| Data valid pin. | |
| #define | PA18_ERXER_A 18 |
| Receive error pin. | |
| #define | PA19_ETXCK_A 19 |
| Transmit clock pin. | |
| #define | PA20_EMDC_A 20 |
| Management data clock pin. | |
| #define | PA21_EMDIO_A 21 |
| Management data I/O pin. | |
| #define | PA22_ETXER_B 22 |
| Transmit error pin. | |
| #define | PA23_ETX2_B 23 |
| Transmit data bit 2 pin. | |
| #define | PA24_ETX3_B 24 |
| Transmit data bit 3 pin. | |
| #define | PA25_ERX2_B 25 |
| Receive data bit 2 pin. | |
| #define | PA26_ERX3_B 26 |
| Receive data bit 3 pin. | |
| #define | PA27_ERXCK_B 27 |
| Receive clock pin. | |
| #define | PA28_ECRS_B 28 |
| Carrier sense pin. | |
| #define | PA29_ECOL_B 29 |
| Collision detect pin. | |
| #define | PC21_EF100_B 21 |
| Force 100Mbit pin. | |
ADC Interface Peripheral Multiplexing | |
| #define | PA22_ADTRG_A 22 |
| ADC trigger pin. | |
Debug Unit Peripheral Multiplexing | |
| #define | PB14_DRXD_A 14 |
| Debug unit receive data pin. | |
| #define | PB15_DTXD_A 15 |
| Debug unit transmit data pin. | |
Synchronous Serial Controller Peripheral Multiplexing | |
| #define | PB18_TD0_A 18 |
| Transmit data pin. | |
| #define | PB19_RD0_A 19 |
| Receive data pin. | |
| #define | PB16_TK0_A 16 |
| Transmit clock pin. | |
| #define | PB20_RK0_A 20 |
| Receive clock pin. | |
| #define | PB17_TF0_A 17 |
| Transmit frame sync. pin. | |
| #define | PB21_RF0_A 21 |
| Receive frame sync. pin. | |
Two Wire Interface Peripheral Multiplexing | |
| #define | PA23_TWD_A 23 |
| Two wire serial data pin. | |
| #define | PA24_TWCK_A 24 |
| Two wire serial clock pin. | |
Timer/Counter Peripheral Multiplexing | |
| #define | PA25_TCLK0_A 25 |
| Timer/counter 0 external clock input. | |
| #define | PA26_TIOA0_A 26 |
| Timer/counter 0 I/O line A. | |
| #define | PC9_TIOB0_B 9 |
| Timer/counter 0 I/O line B. | |
| #define | PB6_TCLK1_B 6 |
| Timer/counter 1 external clock input. | |
| #define | PA27_TIOA1_A 27 |
| Timer/counter 1 I/O line A. | |
| #define | PC7_TIOB1_A 7 |
| Timer/counter 1 I/O line B. | |
| #define | PB7_TCLK2_B 7 |
| Timer/counter 2 external clock input. | |
| #define | PA28_TIOA2_A 28 |
| Timer/counter 2 I/O line A. | |
| #define | PC6_TIOB2_A 6 |
| Timer/counter 2 I/O line B. | |
| #define | PB16_TCLK3_B 16 |
| Timer/counter 3 external clock input. | |
| #define | PB0_TIOA3_B 0 |
| Timer/counter 3 I/O line A. | |
| #define | PB1_TIOB3_B 1 |
| Timer/counter 3 I/O line B. | |
| #define | PB17_TCLK4_B 17 |
| Timer/counter 4 external clock input. | |
| #define | PB2_TIOA4_B 2 |
| Timer/counter 4 I/O line A. | |
| #define | PB18_TIOB4_B 18 |
| Timer/counter 4 I/O line B. | |
| #define | PC22_TCLK5_B 22 |
| Timer/counter 5 external clock input. | |
| #define | PB3_TIOA5_B 3 |
| Timer/counter 5 I/O line A. | |
| #define | PB19_TIOB5_B 19 |
| Timer/counter 5 I/O line B. | |
Clocks, Oscillators and PLLs Peripheral Multiplexing | |
| #define | PB30_PCK0_A 30 |
| Programmable clock 0 output pin. | |
| #define | PC1_PCK0_B 1 |
| Programmable clock 0 output pin. | |
| #define | PB31_PCK1_A 31 |
| Programmable clock 1 output pin. | |
| #define | PC2_PCK1_B 2 |
| Programmable clock 1 output pin. | |
CompactFlash Peripheral Multiplexing | |
| #define | PC10_A25_CFRNW_A 10 |
| Read not write pin. | |
| #define | PC8_NCS4_CFCS0_A 8 |
| Chip select line 0 pin. | |
| #define | PC9_NCS5_CFCS1_A 9 |
| Chip select line 1 pin. | |
| #define | PC6_CFCE1_B 6 |
| Chip enable line 1 pin. | |
| #define | PC7_CFCE2_B 7 |
| Chip enable line 2 pin. | |
External Bus Interface Peripheral Multiplexing | |
| #define | PC16_D16_A 16 |
| Data bus bit 16 pin. | |
| #define | PC17_D17_A 17 |
| Data bus bit 17 pin. | |
| #define | PC18_D18_A 18 |
| Data bus bit 18 pin. | |
| #define | PC19_D19_A 19 |
| Data bus bit 19 pin. | |
| #define | PC20_D20_A 20 |
| Data bus bit 20 pin. | |
| #define | PC21_D21_A 21 |
| Data bus bit 21 pin. | |
| #define | PC22_D22_A 22 |
| Data bus bit 22 pin. | |
| #define | PC23_D23_A 23 |
| Data bus bit 23 pin. | |
| #define | PC24_D24_A 24 |
| Data bus bit 24 pin. | |
| #define | PC25_D25_A 25 |
| Data bus bit 25 pin. | |
| #define | PC26_D26_A 26 |
| Data bus bit 26 pin. | |
| #define | PC27_D27_A 27 |
| Data bus bit 27 pin. | |
| #define | PC28_D28_A 28 |
| Data bus bit 28 pin. | |
| #define | PC29_D29_A 29 |
| Data bus bit 29 pin. | |
| #define | PC30_D30_A 30 |
| Data bus bit 30 pin. | |
| #define | PC31_D31_A 31 |
| Data bus bit 31 pin. | |
| #define | PC4_A23_A 4 |
| Address bus bit 23 pin. | |
| #define | PC5_A24_A 5 |
| Address bus bit 24 pin. | |
| #define | PC11_NCS2_A 11 |
| Negated chip select 2 pin. | |
| #define | PC14_NCS3_NANDCS_A 14 |
| Negated chip select 3 pin. | |
| #define | PC13_NCS6_B 13 |
| Negated chip select 6 pin. | |
| #define | PC12_NCS7_B 12 |
| Negated chip select 7 pin. | |
| #define | PC15_NWAIT_A 15 |
| External wait signal pin. | |
Advanced Interrupt Controller Peripheral Multiplexing | |
| #define | PC13_FIQ_A 13 |
| Fast interrupt input pin. | |
| #define | PC12_IRQ0_A 12 |
| External interrupt 0 input pin. | |
| #define | PC15_IRQ1_B 15 |
| External interrupt 1 input pin. | |
| #define | PC14_IRQ2_B 14 |
| External interrupt 2 input pin. | |
| #define FLASH_BASE 0x100000UL |
Definition at line 75 of file at91sam9260.h.
| #define RAM_BASE 0x200000UL |
Definition at line 76 of file at91sam9260.h.
| #define TC_BASE 0xFFFA0000 |
Timer/counter base address.
Definition at line 78 of file at91sam9260.h.
| #define UDP_BASE 0xFFFA4000 |
USB device port base address.
Definition at line 79 of file at91sam9260.h.
| #define MCI_BASE 0xFFFA8000 |
MMC/SDCard interface base address.
Definition at line 80 of file at91sam9260.h.
| #define TWI_BASE 0xFFFAC000 |
Two-wire interface base address.
Definition at line 81 of file at91sam9260.h.
| #define USART0_BASE 0xFFFB0000 |
USART 0 base address.
Definition at line 82 of file at91sam9260.h.
| #define USART1_BASE 0xFFFB4000 |
USART 1 base address.
Definition at line 83 of file at91sam9260.h.
| #define USART2_BASE 0xFFFB8000 |
USART 2 base address.
Definition at line 84 of file at91sam9260.h.
| #define SSC_BASE 0xFFFBC000 |
Serial synchronous controller base address.
Definition at line 85 of file at91sam9260.h.
| #define ISI_BASE 0xFFFC0000 |
Image sensor interface base address.
Definition at line 86 of file at91sam9260.h.
| #define EMAC_BASE 0xFFFC4000 |
EMAC base address.
Definition at line 87 of file at91sam9260.h.
| #define SPI0_BASE 0xFFFC8000 |
SPI0 0 base address.
Definition at line 88 of file at91sam9260.h.
| #define SPI1_BASE 0xFFFCC000 |
SPI0 1 base address.
Definition at line 89 of file at91sam9260.h.
| #define USART3_BASE 0xFFFD0000 |
USART 3 base address.
Definition at line 90 of file at91sam9260.h.
| #define USART4_BASE 0xFFFD4000 |
USART 4 base address.
Definition at line 91 of file at91sam9260.h.
| #define USART5_BASE 0xFFFD8000 |
USART 5 base address.
Definition at line 92 of file at91sam9260.h.
| #define TC345_BASE 0xFFFDC000 |
Timer/counter 3, 4 and 5 base address.
Definition at line 93 of file at91sam9260.h.
| #define ADC_BASE 0xFFFE0000 |
ADC base address.
Definition at line 94 of file at91sam9260.h.
| #define ECC_BASE 0xFFFFE800 |
ECC base address.
Definition at line 95 of file at91sam9260.h.
| #define SDRAMC_BASE 0xFFFFEA00 |
SDRAMC base address.
Definition at line 96 of file at91sam9260.h.
| #define SMC_BASE 0xFFFFEC00 |
SMC base address.
Definition at line 97 of file at91sam9260.h.
| #define MATRIX_BASE 0xFFFFEE00 |
MATRIX base address.
Definition at line 98 of file at91sam9260.h.
| #define CCFG_BASE 0xFFFFEF10 |
CCFG base address.
Definition at line 99 of file at91sam9260.h.
| #define AIC_BASE 0xFFFFF000 |
AIC base address.
Definition at line 100 of file at91sam9260.h.
| #define DBGU_BASE 0xFFFFF200 |
DBGU base address.
Definition at line 101 of file at91sam9260.h.
| #define PIOA_BASE 0xFFFFF400 |
PIO A base address.
Definition at line 102 of file at91sam9260.h.
| #define PIOB_BASE 0xFFFFF600 |
PIO B base address.
Definition at line 103 of file at91sam9260.h.
| #define PIOC_BASE 0xFFFFF800 |
PIO C base address.
Definition at line 104 of file at91sam9260.h.
| #define PMC_BASE 0xFFFFFC00 |
PMC base address.
Definition at line 105 of file at91sam9260.h.
| #define RSTC_BASE 0xFFFFFD00 |
Resect controller register base address.
Definition at line 106 of file at91sam9260.h.
| #define RTT_BASE 0xFFFFFD20 |
Realtime timer base address.
Definition at line 107 of file at91sam9260.h.
| #define PIT_BASE 0xFFFFFD30 |
Periodic interval timer base address.
Definition at line 108 of file at91sam9260.h.
| #define WDT_BASE 0xFFFFFD40 |
Watch Dog register base address.
Definition at line 109 of file at91sam9260.h.
| #define PERIPH_RPR_OFF 0x00000100 |
Receive pointer register offset.
Definition at line 111 of file at91sam9260.h.
| #define PERIPH_RCR_OFF 0x00000104 |
Receive counter register offset.
Definition at line 112 of file at91sam9260.h.
| #define PERIPH_TPR_OFF 0x00000108 |
Transmit pointer register offset.
Definition at line 113 of file at91sam9260.h.
| #define PERIPH_TCR_OFF 0x0000010C |
Transmit counter register offset.
Definition at line 114 of file at91sam9260.h.
| #define PERIPH_RNPR_OFF 0x00000110 |
Receive next pointer register offset.
Definition at line 115 of file at91sam9260.h.
| #define PERIPH_RNCR_OFF 0x00000114 |
Receive next counter register offset.
Definition at line 116 of file at91sam9260.h.
| #define PERIPH_TNPR_OFF 0x00000118 |
Transmit next pointer register offset.
Definition at line 117 of file at91sam9260.h.
| #define PERIPH_TNCR_OFF 0x0000011C |
Transmit next counter register offset.
Definition at line 118 of file at91sam9260.h.
| #define PERIPH_PTCR_OFF 0x00000120 |
PDC transfer control register offset.
Definition at line 119 of file at91sam9260.h.
| #define PERIPH_PTSR_OFF 0x00000124 |
PDC transfer status register offset.
Definition at line 120 of file at91sam9260.h.
| #define PDC_RXTEN 0x00000001 |
Receiver transfer enable.
Definition at line 122 of file at91sam9260.h.
| #define PDC_RXTDIS 0x00000002 |
Receiver transfer disable.
Definition at line 123 of file at91sam9260.h.
| #define PDC_TXTEN 0x00000100 |
Transmitter transfer enable.
Definition at line 124 of file at91sam9260.h.
| #define PDC_TXTDIS 0x00000200 |
Transmitter transfer disable.
Definition at line 125 of file at91sam9260.h.
| #define DBGU_HAS_PDC |
Definition at line 127 of file at91sam9260.h.
| #define SPI_HAS_PDC |
Definition at line 128 of file at91sam9260.h.
| #define SSC_HAS_PDC |
Definition at line 129 of file at91sam9260.h.
| #define USART_HAS_PDC |
Definition at line 130 of file at91sam9260.h.
| #define USART_HAS_MODE |
Definition at line 131 of file at91sam9260.h.
| #define MCI_HAS_PDC |
Definition at line 132 of file at91sam9260.h.
| #define PMC_HAS_PLLB |
Definition at line 133 of file at91sam9260.h.
| #define PMC_HAS_MDIV |
Definition at line 134 of file at91sam9260.h.
| #define PIO_HAS_MULTIDRIVER |
Definition at line 136 of file at91sam9260.h.
| #define PIO_HAS_PULLUP |
Definition at line 137 of file at91sam9260.h.
| #define PIO_HAS_PERIPHERALSELECT |
Definition at line 138 of file at91sam9260.h.
| #define PIO_HAS_OUTPUTWRITEENABLE |
Definition at line 139 of file at91sam9260.h.
