#include <cfg/os.h>
#include <cfg/chat.h>
#include <stdint.h>
#include <stdio.h>

Include dependency graph for chat.h:

This graph shows which files directly or indirectly include this file:

Data Structures
struct	NUTCHAT
Defines
#define	CHAT_ARG_SEND 0
#define	CHAT_ARG_ABORT 1
#define	CHAT_ARG_TIMEOUT 2
#define	CHAT_ARG_REPORT 3
#define	CHAT_MAX_ABORTS 10
	Maximum number of abort strings.
#define	CHAT_MAX_REPORT_SIZE 32
	Maximum size of report strings.
#define	CHAT_DEFAULT_TIMEOUT 45
	Default timeout.
Functions
void	NutTraceChat (FILE *stream, uint8_t flags)
	Control chat tracing.
int	NutChatExpectString (NUTCHAT ci, char str)
	Wait for a specific string to appear.
int	NutChatExpect (NUTCHAT ci, char str)
int	NutChatSend (NUTCHAT ci, char str)
	Process a chat send argument.
NUTCHAT *	NutChatCreate (int fd)
	Create a NUTCHAT structure.
void	NutChatDestroy (NUTCHAT *ci)
	Destroy a previously created NUTCHAT structure.
int	NutChat (int fd, CONST char *script)
	Execute a conversational exchange with a serial device.
int	NutChat_P (int fd, PGM_P script)
	Execute a conversational exchange with a serial device.
Variables
uint8_t *	chat_report

Define Documentation

#define CHAT_ARG_SEND 0

Definition at line 79 of file chat.h.

Referenced by NutChatSend().

#define CHAT_ARG_ABORT 1

Definition at line 80 of file chat.h.

Referenced by NutChatExpect(), and NutChatSend().

#define CHAT_ARG_TIMEOUT 2

Definition at line 81 of file chat.h.

Referenced by NutChatExpect(), and NutChatSend().

#define CHAT_ARG_REPORT 3

Definition at line 82 of file chat.h.

Referenced by NutChatExpect(), and NutChatSend().

#define CHAT_MAX_ABORTS 10

Maximum number of abort strings.

Definition at line 88 of file chat.h.

Referenced by NutChatSend().

#define CHAT_MAX_REPORT_SIZE 32

Maximum size of report strings.

Definition at line 95 of file chat.h.

Referenced by NutChatExpectString(), and NutChatSend().

#define CHAT_DEFAULT_TIMEOUT 45

Default timeout.

Definition at line 102 of file chat.h.

Referenced by NutChatSend().

Function Documentation

void NutTraceChat	(	FILE *	stream,
		uint8_t	flags
	)

Control chat tracing.

Parameters:

stream	Pointer to a previously opened stream or null to disable trace output.
flags	Flags to enable specific traces.

Definition at line 89 of file chat.c.

References fprintf_P, and prog_char.

int NutChatExpectString	(	NUTCHAT *	ci,
		char *	str
	)

Wait for a specific string to appear.

Parameters:

ci	Pointer to a NUTCHAT structure, which must have been created by NutChatCreate().
str	Expected string. May be empty if nothing is expected.

Returns:: 0 on success, 3 in case of a timeout error while waiting for an expected string, or the index of an abort string plus 4, if one has been received.

Definition at line 131 of file chat.c.

References _read(), NUTCHAT::chat_abomat, NUTCHAT::chat_abort, NUTCHAT::chat_aborts, NUTCHAT::chat_fd, CHAT_MAX_REPORT_SIZE, NUTCHAT::chat_repmat, chat_report, NUTCHAT::chat_report_search, NUTCHAT::chat_report_state, fprintf(), fprintf_P, fputc(), fputs_P, and prog_char.

Referenced by NutChatExpect().

Here is the call graph for this function:

int NutChatExpect	(	NUTCHAT *	ci,
		char *	str
	)

Definition at line 357 of file chat.c.

References NUTCHAT::chat_arg, CHAT_ARG_ABORT, CHAT_ARG_REPORT, CHAT_ARG_TIMEOUT, NUTCHAT::chat_fd, NUTCHAT::chat_repmat, NUTCHAT::chat_report_state, NutChatExpectString(), and strcmp().

Here is the call graph for this function:

int NutChatSend	(	NUTCHAT *	ci,
		char *	str
	)

Process a chat send argument.

Parameters:

ci	Pointer to a NUTCHAT structure, which must have been created by NutChatCreate().
str	String containing the chat send argument.

Returns:: 0 on success, 1 in case of invalid parameters, 2 in case of an I/O error, 3 in case of a timeout error while waiting for an expected string, or the index of an abort string plus 4, if one has been received.

Definition at line 413 of file chat.c.

References _ioctl(), atol(), NUTCHAT::chat_abort, NUTCHAT::chat_aborts, NUTCHAT::chat_arg, CHAT_ARG_ABORT, CHAT_ARG_REPORT, CHAT_ARG_SEND, CHAT_ARG_TIMEOUT, CHAT_DEFAULT_TIMEOUT, NUTCHAT::chat_fd, CHAT_MAX_ABORTS, CHAT_MAX_REPORT_SIZE, chat_report, NUTCHAT::chat_report_search, malloc(), strlen(), and UART_SETREADTIMEOUT.

Here is the call graph for this function:

NUTCHAT* NutChatCreate ( int fd )

Create a NUTCHAT structure.

Returns:: Pointer to a new NUTCHAT structure.

Definition at line 516 of file chat.c.

References NUTCHAT::chat_fd, malloc(), and memset().

Here is the call graph for this function:

void NutChatDestroy ( NUTCHAT * ci )

Destroy a previously created NUTCHAT structure.

Parameters:

ci	Pointer to a NUTCHAT structure, which must have been created by NutChatCreate().

Definition at line 533 of file chat.c.

References NUTCHAT::chat_abort, NUTCHAT::chat_aborts, and free().

Here is the call graph for this function:

int NutChat	(	int	fd,
		CONST char *	script
	)

Execute a conversational exchange with a serial device.

Its primary purpose is to establish a modem connection.

Parameters:

fd	Descriptor of a previously opened device.
script	Pointer to a string containing the chat script.

Returns:: 0 on success, 1 in case of invalid parameters, 2 in case of an I/O error, 3 in case of a timeout error while waiting for an expected string, or the index of an abort string plus 4, if one has been received.

Examples:: pppc/pppc.c.

Definition at line 662 of file chat.c.

References free(), and strdup().

Here is the call graph for this function:

int NutChat_P	(	int	fd,
		PGM_P	script
	)

Execute a conversational exchange with a serial device.

Similar to NutChat() except that the chat string is located in program memory.

Returns:: 0 on success, 1 in case of invalid parameters, 2 in case of an I/O error, 3 in case of a timeout error while waiting for an expected string, or the index of an abort string plus 4, if one has been received.

Definition at line 689 of file chat.c.

References free(), malloc(), strcpy_P, and strlen_P.

Here is the call graph for this function:

Variable Documentation

uint8_t* chat_report

Definition at line 75 of file chat.c.

Referenced by NutChatExpectString(), and NutChatSend().
