Nut/OS configuration structure. More...

Collaboration diagram for System Configuration:

Data Structures
struct	_CONFOS
	Operating system configuration structure. More...
Defines
#define	CONFOS_EE_OFFSET 0
	Non-volatile memory location.
#define	CONFOS_EE_MAGIC "OS"
#define	MAX_HOSTNAME_LEN 15
	Maximum number of characters allowed for hostname.
#define	CONFOS_VIRGIN_HOSTNAME "ethernut"
	Default hostname.
Typedefs
typedef struct _CONFOS	CONFOS
	Operating system configuration type.
Functions
int	NutLoadConfig (void)
	Load Nut/OS configuration from non-volatile memory.
int	NutSaveConfig (void)
	Save Nut/OS configuration in non-volatile memory.
Variables
CONFOS	confos
	Global system configuration structure.
CONFOS	confos
	Global system configuration structure.

Detailed Description

Nut/OS configuration structure.

Define Documentation

#define CONFOS_EE_OFFSET 0

Non-volatile memory location.

Offset into non-volatile memory, where Nut/OS stores the system configuration. The default may be overridden by the Configurator.

Definition at line 103 of file confos.h.

Referenced by NutLoadConfig(), and NutSaveConfig().

#define CONFOS_EE_MAGIC "OS"

Definition at line 107 of file confos.h.

Referenced by NutLoadConfig(), and NutSaveConfig().

#define MAX_HOSTNAME_LEN 15

Maximum number of characters allowed for hostname.

Intentionally not MAXHOSTNAMELEN to avoid conflicts with existing C libraries.

Definition at line 117 of file confos.h.

Referenced by NutSaveConfig().

#define CONFOS_VIRGIN_HOSTNAME "ethernut"

Default hostname.

Used on virgin systems without any valid configuration.

Definition at line 126 of file confos.h.

Referenced by NutLoadConfig().

Typedef Documentation

typedef struct _CONFOS CONFOS

Operating system configuration type.

Definition at line 132 of file confos.h.

Function Documentation

int NutLoadConfig ( void )

Load Nut/OS configuration from non-volatile memory.

This routine is automatically called during system initialization. It tries to read the OS configuration structure CONFOS from non-volatile memory, starting at /ref CONFOS_EE_OFFSET.

The routine may fail, if

non-volatile memory is not supported,
non-volatile memory contains invalid data,
the configuration structure has changed.

Returns:: 0 if OK, -1 on failures, in which case the hostname will be set to CONFOS_VIRGIN_HOSTNAME.

Definition at line 114 of file confos.c.

References CONFOS_EE_MAGIC, CONFOS_EE_OFFSET, CONFOS_VIRGIN_HOSTNAME, _CONFOS::hostname, _CONFOS::magic, memcmp(), NUTASSERT, NutNvMemLoad(), _CONFOS::size, strcpy(), and strlen().

Referenced by NutIdle().

Here is the call graph for this function:

int NutSaveConfig ( void )

Save Nut/OS configuration in non-volatile memory.

Since Nut/OS version 4.7.5, this routine is no longer called automatically during system initialization. Thus, if NutLoadConfig() fails, then the non-volatile memory remains invalid and NutLoadConfig() will again fail during the next system start.
