SAM7X EMAC

SAM7X EMAC registers. More...

Collaboration diagram for SAM7X EMAC:

Functions
void	EmacRxThread (void *arg)
int	EmacOutput (NUTDEVICE *dev, NETBUF *nb)
	Send Ethernet packet.
int	EmacInit (NUTDEVICE *dev)
	Initialize Ethernet hardware.
Variables
NUTDEVICE	devAt91Emac
	Device information structure.

---

Detailed Description

SAM7X EMAC registers.

---

Function Documentation

void EmacRxThread

(

void *

arg

)

Definition at line 563 of file at91sam7x_emac.c.

References _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, EMAC_IER, ETHER_IS_UNICAST, ifnet::if_mac, ifnet::if_recv, _NETBUF::nb_dl, _EMACINFO::ni_insane, _EMACINFO::ni_mutex, _EMACINFO::ni_rx_rdy, _EMACINFO::ni_tx_quelen, _EMACINFO::ni_tx_queued, NutEventPost(), NutEventWait(), NutIrqEnable(), NutNetBufFree(), NutSleep(), NutThreadSetPriority(), outr, sig_EMAC, and _NBDATA::sz.

Here is the call graph for this function:

int EmacOutput	(	NUTDEVICE *	dev,
		NETBUF *	nb
	)

Send Ethernet packet.

Todo:

This routine does not work.

Parameters:

dev	Identifies the device to use.
nb	Network buffer structure containing the packet to be sent. The structure must have been allocated by a previous call NutNetBufAlloc().

Returns:

0 on success, -1 in case of any errors.

Definition at line 649 of file at91sam7x_emac.c.

References _NUTDEVICE::dev_dcb, _EMACINFO::ni_insane, _EMACINFO::ni_mutex, _EMACINFO::ni_tx_rdy, NutEventPost(), NutEventWait(), _BufDescriptor::stat, and TXS_USED.

Here is the call graph for this function:

int EmacInit

(

NUTDEVICE *

dev

)

Initialize Ethernet hardware.

Applications should do not directly call this function. It is automatically executed during during device registration by NutRegisterDevice().

Parameters:

dev	Identifies the device to initialize.

Definition at line 706 of file at91sam7x_emac.c.

References _NUTDEVICE::dev_dcb, EmacRxThread(), memset(), NUT_THREAD_NICRXSTACK, NUT_THREAD_STACK_ADD, NUT_THREAD_STACK_MULT, NutRegisterIrqHandler(), NutThreadCreate(), and sig_EMAC.

Here is the call graph for this function:

---

Variable Documentation

NUTDEVICE devAt91Emac

Initial value:

 {
    0,
    {'e', 't', 'h', '0', 0, 0, 0, 0, 0},
    IFTYP_NET,
    0,
    0,
    &ifn_eth0,
    &dcb_eth0,
    EmacInit,
    0,
    0,
    0,

    0,

    0,
    0,
    0
}

Device information structure.

A pointer to this structure must be passed to NutRegisterDevice() to bind this Ethernet device driver to the Nut/OS kernel. An application may then call NutNetIfConfig() with the name eth0 of this driver to initialize the network interface.

Definition at line 763 of file at91sam7x_emac.c.
