PHAT16 Support

PHAT16 specific routines. More...

Collaboration diagram for PHAT16 Support:

Defines
#define	PHAT16CMASK   0xFFFF
Functions
int	Phat16GetClusterLink (NUTDEVICE *dev, uint32_t clust, uint32_t *link)
	Get link value of a specified cluster.
int	Phat16SetClusterLink (NUTDEVICE *dev, uint32_t clust, uint32_t link)
	Set link value of a specified cluster.
int	Phat16ReleaseChain (NUTDEVICE *dev, uint32_t first)
	Release a cluster chain.

---

Detailed Description

PHAT16 specific routines.

---

Define Documentation

#define PHAT16CMASK   0xFFFF

Definition at line 58 of file phat16.h.

Referenced by AllocFirstCluster(), Phat16GetClusterLink(), Phat16ReleaseChain(), PhatFilePosSet(), PhatFileRead(), and PhatFileWrite().

---

Function Documentation

int Phat16GetClusterLink	(	NUTDEVICE *	dev,
		uint32_t	clust,
		uint32_t *	link
	)

Get link value of a specified cluster.

Parameters:

dev	Specifies the file system device.
clust	Get the link of this cluster.
link	Pointer to a variable which will receive the link.

Returns:

0 on success or -1 on failure.

Definition at line 103 of file phat16.c.

References _NUTDEVICE::dev_dcb, PHAT16CMASK, PHATEOC, PhatSectorLoad(), _PHATSECTBUF::sect_data, and _PHATVOL::vol_buf.

Referenced by Phat16ReleaseChain(), PhatFilePosSet(), PhatFileRead(), and PhatFileWrite().

Here is the call graph for this function:

int Phat16SetClusterLink	(	NUTDEVICE *	dev,
		uint32_t	clust,
		uint32_t	link
	)

Set link value of a specified cluster.

Parameters:

dev	Specifies the file system device.
clust	This cluster will be linked.
link	Link to this cluster.

Returns:

0 on success or -1 on failure.

Definition at line 137 of file phat16.c.

References _NUTDEVICE::dev_dcb, PhatSectorLoad(), _PHATSECTBUF::sect_data, _PHATSECTBUF::sect_dirty, _PHATVOL::vol_buf, and _PHATVOL::vol_tab_sect.

Referenced by AllocFirstCluster(), and Phat16ReleaseChain().

Here is the call graph for this function:

int Phat16ReleaseChain	(	NUTDEVICE *	dev,
		uint32_t	first
	)

Release a cluster chain.

Parameters:

dev	Specifies the file system device.
first	First cluster of the chain to release.

Returns:

0 on success or -1 on failure.

Definition at line 165 of file phat16.c.

References _NUTDEVICE::dev_dcb, PHAT16CMASK, Phat16GetClusterLink(), Phat16SetClusterLink(), PHATEOC, and _PHATVOL::vol_numfree.

Referenced by PhatDirReleaseChain().

Here is the call graph for this function:
