Routines for reading and writing directories. More...

Collaboration diagram for Directory Support:

Data Structures
struct	_PHATDIRENT
	Structure of a directory entry. More...
struct	_PHATXDIRENT
	Structure of an extended directory entry. More...
struct	_PHATFIND
Defines
#define	PHAT_MAX_NAMELEN 255
	Maximum length of a base file name.
#define	PHAT_REM_DIRENT 0xE5
#define	PHAT_REM_NAMENT 0x05
#define	PHAT_MAXDIRENT 65536
	Maximum number of directory entries.
Typedefs
typedef struct _PHATDIRENT	PHATDIRENT
	Structure of a directory entry.
typedef struct _PHATXDIRENT	PHATXDIRENT
	Structure of an extended directory entry.
typedef struct _PHATFIND	PHATFIND
Functions
int	PhatDirEntryCreate (NUTFILE ndp, CONST char name, int acc, PHATDIRENT *dirent)
	Create a new directory entry.
int	PhatDirEntryUpdate (NUTFILE *nfp)
	Update directory entry of an opened file or directory.
int	PhatDirEntryFind (NUTFILE ndp, CONST char spec, uint32_t attmsk, PHATFIND *srch)
	Find a directory entry with a specified name.
NUTFILE *	PhatDirOpenParent (NUTDEVICE dev, CONST char path, CONST char **basename)
	Open parent directory of a given path.
int	PhatDirRenameEntry (NUTDEVICE dev, CONST char old_path, CONST char *new_path)
	Rename file.
int	PhatDirReleaseChain (NUTDEVICE dev, PHATDIRENT dent)
	Release a cluster chain of a specified directory entry.
int	PhatDirDelEntry (NUTDEVICE dev, CONST char path, uint32_t flags)
	Remove a directory entry.
NUTFILE *	PhatDirOpen (NUTDEVICE dev, CONST char dpath)
	Open a directory.
int	PhatDirRead (DIR *dir)
	Read the next directory entry.
int	PhatDirCreate (NUTDEVICE dev, char path)
	Create a new subdirectory.
int	PhatDirRemove (NUTDEVICE dev, char path)
	Remove a specified subdirectory.
int	PhatDirEntryStatus (NUTDEVICE dev, CONST char path, struct stat *stp)
	Retrieve status of a specified file.

Detailed Description

Routines for reading and writing directories.

Define Documentation

#define PHAT_MAX_NAMELEN 255

Maximum length of a base file name.

Definition at line 77 of file phatdir.h.

Referenced by PhatDirOpen().

#define PHAT_REM_DIRENT 0xE5

Definition at line 80 of file phatdir.h.

Referenced by MakePhatName(), MakeVisibleName(), and PhatDirRemove().

#define PHAT_REM_NAMENT 0x05

Definition at line 81 of file phatdir.h.

Referenced by MakePhatName(), and MakeVisibleName().

#define PHAT_MAXDIRENT 65536

Maximum number of directory entries.

Definition at line 136 of file phatdir.c.

Typedef Documentation

typedef struct _PHATDIRENT PHATDIRENT

Structure of a directory entry.

Once created, this structure will never change if it points to another directory. Except if the entry is removed.

typedef struct _PHATXDIRENT PHATXDIRENT

Structure of an extended directory entry.

Used for long filenames.

typedef struct _PHATFIND PHATFIND

Function Documentation

int PhatDirEntryCreate	(	NUTFILE *	ndp,
		CONST char *	name,
		int	acc,
		PHATDIRENT *	dirent
	)

Create a new directory entry.

Parameters:

ndp	Handle to the parent directory.
name	Name of the new entry.
acc	Attributes of the new entry.
dirent	Information structure of the new entry.

Returns:: 0 on success. Otherwise -1 is returned.

Definition at line 475 of file phatdir.c.

References _PHATDIRENT::dent_adate, _PHATDIRENT::dent_attr, _PHATDIRENT::dent_cdate, _PHATDIRENT::dent_ctime, _PHATDIRENT::dent_mdate, _PHATDIRENT::dent_mtime, GetDosTimeStamp(), _NUTFILE::nf_fcb, PhatDbgFileInfo(), and stdout.

Referenced by PhatFileOpen().

Here is the call graph for this function:

int PhatDirEntryUpdate ( NUTFILE * nfp )

Update directory entry of an opened file or directory.

Parameters:

nfp	File of which the directory entry will be updated.

Returns:: 0 on success. Otherwise -1 is returned.

Definition at line 499 of file phatdir.c.

References _NUTDEVICE::dev_dcb, memcpy(), _NUTFILE::nf_dev, _NUTFILE::nf_fcb, PhatDbgDirEntry(), PhatSectorLoad(), _PHATSECTBUF::sect_data, _PHATSECTBUF::sect_dirty, stdout, and _PHATVOL::vol_buf.

Here is the call graph for this function:

int PhatDirEntryFind	(	NUTFILE *	ndp,
		CONST char *	spec,
		uint32_t	attmsk,
		PHATFIND *	srch
	)

Find a directory entry with a specified name.

Parameters:

ndp	Pointer to a previously opened directory.
spec	Name of the entry to retrieve.
attmsk	Attribute mask. Entries with attributes not specified in this mask will be ignored.
srch	Optional pointer to a structure which receives the search result.

Returns:: 0 if an entry was found, otherwise -1 is returned.

Definition at line 638 of file phatdir.c.

References _PHATDIRENT::dent_attr, free(), malloc(), _NUTFILE::nf_fcb, PhatFilePosRewind(), _PHATFIND::phfind_ent, _PHATFIND::phfind_name, and strcasecmp.

Referenced by PhatDirDelEntry(), PhatDirEntryStatus(), PhatDirOpen(), PhatDirRenameEntry(), and PhatFileOpen().

Here is the call graph for this function:

NUTFILE* PhatDirOpenParent	(	NUTDEVICE *	dev,
		CONST char *	path,
		CONST char **	basename
	)

Open parent directory of a given path.

Parameters:

dev	Specifies the file system device.
path	Full path.
basename	Points to a pointer which will be set to the last component within the full path.

Returns:: Pointer to a NUTFILE structure if successful or NUTFILE_EOF otherwise.

Definition at line 679 of file phatdir.c.

References free(), GetParentPath(), NUTFILE_EOF, and PhatDirOpen().

Referenced by PhatDirDelEntry(), PhatDirEntryStatus(), PhatDirRenameEntry(), and PhatFileOpen().

Here is the call graph for this function:

int PhatDirRenameEntry	(	NUTDEVICE *	dev,
		CONST char *	old_path,
		CONST char *	new_path
	)

Rename file.

Parameters:

dev	Specifies the file system device.
old_path	Old name and path of the file.
new_path	New name and path of the file.

Returns:: 0 on success, -1 otherwise.

Definition at line 700 of file phatdir.c.

References CONST, EEXIST, ENOENT, errno, free(), malloc(), NUTFILE_EOF, PHAT_FATTR_FILEMASK, PhatDirEntryFind(), PhatDirOpenParent(), PhatFileClose(), _PHATFIND::phfind_ent, _PHATFIND::phfind_pos, and _PHATFIND::phfind_xcnt.

Here is the call graph for this function:

int PhatDirReleaseChain	(	NUTDEVICE *	dev,
		PHATDIRENT *	dent
	)

Release a cluster chain of a specified directory entry.

Parameters:

dev	Specifies the file system device.
dent	Directory entry.

Returns:: 0 on success or -1 on failure.

Definition at line 747 of file phatdir.c.

References _PHATDIRENT::dent_attr, _PHATDIRENT::dent_clust, _PHATDIRENT::dent_clusthi, _NUTDEVICE::dev_dcb, EACCES, errno, Phat12ReleaseChain(), Phat16ReleaseChain(), Phat32ReleaseChain(), PHAT_FATTR_RDONLY, and _PHATVOL::vol_type.

Referenced by PhatDirDelEntry(), and PhatFileOpen().

Here is the call graph for this function:

int PhatDirDelEntry	(	NUTDEVICE *	dev,
		CONST char *	path,
		uint32_t	flags
	)

Remove a directory entry.

Allocated clusters are released.

Parameters:

dev	Specifies the file system device.
path	Name of the entry to remove.
flags	Attributes of the entry to remove.

Returns:: 0 if successful. Otherwise returns an error code.

Definition at line 791 of file phatdir.c.

References CONST, ENOENT, errno, free(), malloc(), NUTFILE_EOF, PhatDirEntryFind(), PhatDirOpenParent(), PhatDirReleaseChain(), PhatFileClose(), _PHATFIND::phfind_ent, _PHATFIND::phfind_pos, and _PHATFIND::phfind_xcnt.

Referenced by PhatDirRemove().

Here is the call graph for this function:

NUTFILE* PhatDirOpen	(	NUTDEVICE *	dev,
		CONST char *	dpath
	)

Open a directory.

Parameters:

dev	Specifies the file system device.
dpath	Full absolute pathname of the directory to open.

Returns:: Pointer to a NUTFILE structure if successful or NUTFILE_EOF otherwise.

Definition at line 825 of file phatdir.c.

References _O_RDONLY, _PHATDIRENT::dent_attr, _PHATDIRENT::dent_clust, _PHATDIRENT::dent_clusthi, _NUTDEVICE::dev_dcb, ENODEV, ENOENT, errno, _PHATFILE::f_clust, _PHATFILE::f_clust_pos, _PHATFILE::f_clust_prv, _PHATFILE::f_de_offs, _PHATFILE::f_de_sect, _PHATFILE::f_dirent, _PHATFILE::f_mode, _PHATFILE::f_pde_clust, _PHATFILE::f_pde_clusthi, _PHATFILE::f_sect_pos, free(), malloc(), memset(), _NUTFILE::nf_dev, _NUTFILE::nf_fcb, _NUTFILE::nf_next, NUTFILE_EOF, PHAT_FATTR_DIR, PHAT_FATTR_FILEMASK, PHAT_MAX_NAMELEN, PhatClusterSector(), PhatDbgFileInfo(), PhatDirEntryFind(), PhatFilePosRewind(), _PHATFIND::phfind_ent, stdout, _PHATVOL::vol_root_clust, and _PHATVOL::vol_type.

Referenced by PhatDirOpenParent().

Here is the call graph for this function:

int PhatDirRead ( DIR * dir )

Read the next directory entry.

Parameters:

dir	Pointer to the internal directory information structure.

Returns:: 0 on success, -1 otherwise.

Definition at line 958 of file phatdir.c.

References dirent::d_name, dirent::d_namlen, dirent::d_type, _dirdesc::dd_buf, _dirdesc::dd_fd, _PHATDIRENT::dent_attr, free(), malloc(), memset(), PHAT_FATTR_DIR, PhatDbgDirEntry(), _PHATFIND::phfind_ent, _PHATFIND::phfind_name, stdout, strcpy(), and strlen().

Here is the call graph for this function:

int PhatDirCreate	(	NUTDEVICE *	dev,
		char *	path
	)

Create a new subdirectory.

One cluster is allocated, initialized to zero and two directory entries are created, '.' and '..'.

Parameters:

dev	Specifies the file system device.
path	Full path to the directory.

Returns:: 0 on success. Otherwise -1 is returned.

Definition at line 997 of file phatdir.c.

References _O_CREAT, _O_EXCL, _O_RDWR, AllocFirstCluster(), _PHATDIRENT::dent_clust, _PHATDIRENT::dent_clusthi, _PHATDIRENT::dent_name, _NUTDEVICE::dev_dcb, _PHATFILE::f_clust, _PHATFILE::f_clust_prv, _PHATFILE::f_dirent, _PHATFILE::f_pde_clust, _PHATFILE::f_pde_clusthi, free(), malloc(), memset(), _NUTFILE::nf_fcb, NUTFILE_EOF, PHAT_FATTR_DIR, PhatFileClose(), PhatFileOpen(), PhatFilePosRewind(), PhatFileWrite(), _PHATVOL::vol_clustsz, _PHATVOL::vol_root_clust, and _PHATVOL::vol_sectsz.

Here is the call graph for this function:

int PhatDirRemove	(	NUTDEVICE *	dev,
		char *	path
	)

Remove a specified subdirectory.

Parameters:

dev	Specifies the file system device.
path	Full path to the directory.

Returns:: 0 on success. Otherwise -1 is returned.

Definition at line 1084 of file phatdir.c.

References _O_RDONLY, _PHATDIRENT::dent_attr, _PHATDIRENT::dent_name, EBUSY, ENOTEMPTY, errno, free(), malloc(), memcmp(), NUTFILE_EOF, PHAT_FATTR_DIR, PHAT_FATTR_FILEMASK, PHAT_REM_DIRENT, PhatDirDelEntry(), PhatFileClose(), PhatFileOpen(), and PhatFileRead().

Here is the call graph for this function:

int PhatDirEntryStatus	(	NUTDEVICE *	dev,
		CONST char *	path,
		struct stat *	stp
	)

Retrieve status of a specified file.

Parameters:

dev	File system device.
path	Path name to the file to query.
stp	Pointer to a structure which receives the result.

return 0 on success, -1 otherwise.

Definition at line 1155 of file phatdir.c.

References _daylight, CONST, _PHATDIRENT::dent_attr, _PHATDIRENT::dent_fsize, _PHATDIRENT::dent_mdate, _PHATDIRENT::dent_mtime, free(), malloc(), memset(), mktime(), NUTFILE_EOF, PHAT_FATTR_DIR, PHAT_FATTR_FILEMASK, PhatDirEntryFind(), PhatDirOpenParent(), PhatFileClose(), _PHATFIND::phfind_ent, stat::st_ino, stat::st_mode, stat::st_mtime, stat::st_nlink, stat::st_size, _tm::tm_hour, _tm::tm_isdst, _tm::tm_mday, _tm::tm_min, _tm::tm_mon, _tm::tm_sec, and _tm::tm_year.

Here is the call graph for this function:
