upnp.c File Reference

#include <sys/version.h>
#include <sys/thread.h>
#include <sys/socket.h>
#include <sys/device.h>
#include <sys/event.h>
#include <sys/timer.h>
#include <net/if_var.h>
#include <arpa/inet.h>
#include <pro/httpd.h>
#include <stdlib.h>
#include <stdio.h>
#include <stdint.h>
#include <string.h>

Include dependency graph for upnp.c:

Go to the source code of this file.

Defines
#define	__MAIN_C__
#define	UPNP_FULFIL_SPEC   0
#define	UPNP_SERVICE_STACK   ((1024 * NUT_THREAD_STACK_MULT) + NUT_THREAD_STACK_ADD)
#define	UPNP_CGI_NAME   "upnp.cgi"
#define	UPNP_UUID_PART1   "56F9C1D5-5083-4ee5-A6B3-"
#define	SSDP_IP   0xfaffffefU
#define	SSDP_PORT   1900
#define	SSDP_BUFFER_SIZE   512
#define	SSDP_NOTIFY_TIMEOUT   300000U
Functions
void	NotifyTask (void *arg)
void	SSDPTask (void *arg)
void	upnp_Init (void)

---

Define Documentation

#define __MAIN_C__

Definition at line 43 of file upnp.c.

#define UPNP_FULFIL_SPEC   0

Definition at line 69 of file upnp.c.

#define UPNP_SERVICE_STACK   ((1024 * NUT_THREAD_STACK_MULT) + NUT_THREAD_STACK_ADD)

Definition at line 72 of file upnp.c.

Referenced by upnp_Init().

#define UPNP_CGI_NAME   "upnp.cgi"

Definition at line 75 of file upnp.c.

Referenced by upnp_Init().

#define UPNP_UUID_PART1   "56F9C1D5-5083-4ee5-A6B3-"

Definition at line 76 of file upnp.c.

Referenced by SSDPTask().

#define SSDP_IP   0xfaffffefU

Definition at line 78 of file upnp.c.

Referenced by SSDPTask(), and upnp_Init().

#define SSDP_PORT   1900

Definition at line 79 of file upnp.c.

Referenced by SSDPTask().

#define SSDP_BUFFER_SIZE   512

Definition at line 80 of file upnp.c.

Referenced by NotifyTask(), and SSDPTask().

#define SSDP_NOTIFY_TIMEOUT   300000U

Definition at line 81 of file upnp.c.

Referenced by NotifyTask().

---

Function Documentation

void NotifyTask

(

void *

arg

)

Definition at line 318 of file upnp.c.

References malloc(), NutSleep(), NutThreadYield(), NutUdpCreateSocket(), SSDP_BUFFER_SIZE, and SSDP_NOTIFY_TIMEOUT.

Referenced by upnp_Init().

Here is the call graph for this function:

void SSDPTask

(

void *

arg

)

Definition at line 342 of file upnp.c.

References ifnet::if_local_ip, ifnet::if_mac, inet_ntoa(), malloc(), NUT_VERSION_MAJOR, NUT_VERSION_MINOR, NUT_WAIT_INFINITE, NutSleep(), NutThreadYield(), NutUdpCreateSocket(), NutUdpReceiveFrom(), NutUdpSendTo(), sprintf, SSDP_BUFFER_SIZE, SSDP_IP, SSDP_PORT, strstr(), strtol(), and UPNP_UUID_PART1.

Referenced by upnp_Init().

Here is the call graph for this function:

void upnp_Init

(

void

)

Examples:

httpd_upnp/httpserv.c.

Definition at line 445 of file upnp.c.

References _NUTDEVICE::dev_icb, NotifyTask(), NutDeviceLookup(), NutNetIfAddMcastAddr(), NutRegisterCgi(), NutThreadCreate(), printf, puts, SSDP_IP, SSDPTask(), UPNP_CGI_NAME, and UPNP_SERVICE_STACK.

Referenced by main().

Here is the call graph for this function:
