wlan.h File Reference

#include <dev/netbuf.h>
#include <net/if_var.h>

Include dependency graph for wlan.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Data Structures
struct	_wlan_wep_key
struct	_wlan_config
struct	_wlan_status
Defines
#define	DEV_ETHER   devWlan
#define	WLAN_NETWORK_NAME_MAX_LEN   32
#define	WLAN_WEP_MAX_KEY_COUNT   4
#define	WLAN_WEP_MAX_KEY_SIZE   16
Typedefs
typedef struct _wlan_wep_key	WLAN_WEP_KEY
typedef struct _wlan_config	WLAN_CONFIG
typedef struct _wlan_status	WLAN_STATUS
Enumerations
enum	WLAN_IOCTL { WLAN_IOCTL_GET_MAC_ADDRESS = 1, WLAN_IOCTL_SET_CONFIG, WLAN_IOCTL_GET_STATUS }
enum	WLAN_MODE { WLAN_MODE_STOP = 0, WLAN_MODE_STATION, WLAN_MODE_ADHOC }
enum	WLAN_STATUS_PORT {   WLAN_STATUS_PORT_DISABLE = 1, WLAN_STATUS_PORT_SEARCHING = 2, WLAN_STATUS_PORT_CONN_IBSS = 3, WLAN_STATUS_PORT_CONN_ESS = 4,   WLAN_STATUS_PORT_OOR_ESS = 5 }
enum	WLAN_WEP { WLAN_USE_NO_WEP = 0, WLAN_USE_64BIT_WEP = 5, WLAN_USE_128BIT_WEP = 13 }
Functions
int	WlanInit (NUTDEVICE *dev)
int	WlanIOCtl (NUTDEVICE *dev, int req, void *conf)
int	WlanOutput (NUTDEVICE *dev, NETBUF *nb)
Variables
NUTDEVICE	devWlan

---

Define Documentation

#define DEV_ETHER   devWlan

Definition at line 53 of file wlan.h.

#define WLAN_NETWORK_NAME_MAX_LEN   32

Definition at line 59 of file wlan.h.

#define WLAN_WEP_MAX_KEY_COUNT   4

Definition at line 64 of file wlan.h.

Referenced by wlandrv_IOCTL().

#define WLAN_WEP_MAX_KEY_SIZE   16

Definition at line 65 of file wlan.h.

Referenced by wlandrv_IOCTL().

---

Typedef Documentation

typedef struct _wlan_wep_key WLAN_WEP_KEY

typedef struct _wlan_config WLAN_CONFIG

typedef struct _wlan_status WLAN_STATUS

---

Enumeration Type Documentation

enum WLAN_IOCTL

Enumerator:

WLAN_IOCTL_GET_MAC_ADDRESS
WLAN_IOCTL_SET_CONFIG
WLAN_IOCTL_GET_STATUS

Definition at line 74 of file wlan.h.

enum WLAN_MODE

Enumerator:

WLAN_MODE_STOP
WLAN_MODE_STATION
WLAN_MODE_ADHOC

Definition at line 85 of file wlan.h.

enum WLAN_STATUS_PORT

Enumerator:

WLAN_STATUS_PORT_DISABLE
WLAN_STATUS_PORT_SEARCHING
WLAN_STATUS_PORT_CONN_IBSS
WLAN_STATUS_PORT_CONN_ESS
WLAN_STATUS_PORT_OOR_ESS

Definition at line 94 of file wlan.h.

enum WLAN_WEP

Enumerator:

WLAN_USE_NO_WEP
WLAN_USE_64BIT_WEP
WLAN_USE_128BIT_WEP

Definition at line 105 of file wlan.h.

---

Function Documentation

int WlanInit

(

NUTDEVICE *

dev

)

Definition at line 145 of file wlan.c.

References _NUTDEVICE::dev_dcb, ERROR, memset(), NutHeapAlloc, OK, wlandrv_Attach(), wlandrv_Init(), and wlandrv_ProbeDevice().

Here is the call graph for this function:

int WlanIOCtl	(	NUTDEVICE *	dev,
		int	req,
		void *	conf
	)

Definition at line 202 of file wlan.c.

References wlandrv_IOCTL().

Here is the call graph for this function:

int WlanOutput	(	NUTDEVICE *	dev,
		NETBUF *	nb
	)

Definition at line 224 of file wlan.c.

References ERROR, and wlandrv_PutPacket().

Here is the call graph for this function:

---

Variable Documentation

NUTDEVICE devWlan

Definition at line 103 of file wlan.c.
