Routines for Atmel AT49 flash memory chips. More...

#include <cfg/os.h>
#include <cfg/memory.h>
#include <sys/event.h>
#include <sys/timer.h>
#include <stdlib.h>
#include <string.h>
#include <dev/at49bv.h>

Include dependency graph for at49bv.c:

Go to the source code of this file.

Defines
#define	FLASH_CHIP_BASE 0x10000000
	Base address of the flash memory chip.
#define	FLASH_CONF_SECTOR 0x6000
	Address offset of the configuration sector.
#define	FLASH_CONF_SIZE 512
	Size of the configuration area.
#define	FLASH_ERASE_WAIT 3000
#define	FLASH_CHIP_ERASE_WAIT 50000
#define	FLASH_WRITE_POLLS 1000
#define	FLASH_UNLOCK(base)
#define	FLASH_COMMAND(base, cmd)
#define	FLASH_CMD_ERASE 0x80
#define	FLASH_CMD_ERASE_CHIP 0x10
#define	FLASH_CMD_ERASE_SECTOR 0x30
#define	FLASH_CMD_ENTER_ID 0x90
#define	FLASH_CMD_EXIT_ID 0xF0
#define	FLASH_CMD_PROGRAM 0xA0
Typedefs
typedef unsigned short	flashdat_t
typedef unsigned long	flashadr_t
typedef volatile flashdat_t *	flashptr_t
Functions
unsigned long	At49bvInit (void)
unsigned long long	AT49bvReadProtectionRegister (int factory)
	Read user or factory id from protection register.
int	At49bvSectorErase (unsigned int off)
	Erase sector at the specified offset.
int	At49bvChipErase (void)
	Erase entire flash memory chip.
int	At49bvSectorRead (unsigned int off, void *data, unsigned int len)
	Read data from flash memory.
int	At49bvSectorWrite (unsigned int off, CONST void *data, unsigned int len)
	Write data into flash memory.
int	At49bvParamRead (unsigned int pos, void *data, unsigned int len)
	Load configuration parameters from flash memory.
int	At49bvParamWrite (unsigned int pos, CONST void *data, unsigned int len)
	Store configuration parameters in flash memory.

Detailed Description

Routines for Atmel AT49 flash memory chips.

 *
 * $Log$
 * Revision 1.6  2009/01/17 11:26:46  haraldkipp
 * Getting rid of two remaining BSD types in favor of stdint.
 * Replaced 'u_int' by 'unsinged int' and 'uptr_t' by 'uintptr_t'.
 *
 * Revision 1.5  2008/08/11 06:59:41  haraldkipp
 * BSD types replaced by stdint types (feature request #1282721).
 *
 * Revision 1.4  2008/07/17 11:51:18  olereinhardt
 * Added function AT49bvReadProtectionRegister to read the 64bit factory
 * or user id
 *
 * Revision 1.3  2006/10/08 16:48:09  haraldkipp
 * Documentation fixed
 *
 * Revision 1.2  2006/05/25 09:33:35  haraldkipp
 * Bugfix. At49bvParamWrite() returned an error when flash sector contents
 * was equal to the contents to write.
 *
 * Revision 1.1  2006/04/07 13:51:36  haraldkipp
 * AT49BV flash memory support added. A single sector may be used to
 * store system configurations in case there is no EEPROM available.
 *
 *
 *

Definition in file at49bv.c.

Define Documentation

#define FLASH_CHIP_BASE 0x10000000

Base address of the flash memory chip.

Definition at line 81 of file at49bv.c.

Referenced by At49bvSectorErase(), At49bvSectorRead(), At49bvSectorWrite(), and ShowHardwareConfiguration().

#define FLASH_CONF_SECTOR 0x6000

Address offset of the configuration sector.

Definition at line 87 of file at49bv.c.

Referenced by At49bvParamRead(), and At49bvParamWrite().

#define FLASH_CONF_SIZE 512

Size of the configuration area.

During write operations a buffer with this size is allocated from heap and may cause memory problems with large sectors. Thus, this value may be less than the size of the configuration sector, in which case the rest of the sector is unused.

Definition at line 98 of file at49bv.c.

Referenced by At49bvParamWrite().

#define FLASH_ERASE_WAIT 3000

Definition at line 102 of file at49bv.c.

Referenced by At49bvSectorErase().

#define FLASH_CHIP_ERASE_WAIT 50000

Definition at line 106 of file at49bv.c.

Referenced by At49bvChipErase().

#define FLASH_WRITE_POLLS 1000

Definition at line 110 of file at49bv.c.

Referenced by At49bvSectorWrite().

#define FLASH_UNLOCK ( base )

Value:

{ \
    base[0x0555] = 0xAA; \
    base[0x0AAA] = 0x55; \
}

Definition at line 125 of file at49bv.c.

Referenced by At49bvChipErase(), At49bvInit(), AT49bvReadProtectionRegister(), At49bvSectorErase(), and At49bvSectorWrite().

#define FLASH_COMMAND	(	base,
		cmd
	)

Value:

{ \
    base[0x0555] = cmd; \
}

Definition at line 130 of file at49bv.c.

Referenced by At49bvChipErase(), At49bvInit(), AT49bvReadProtectionRegister(), At49bvSectorErase(), and At49bvSectorWrite().

#define FLASH_CMD_ERASE 0x80

Definition at line 134 of file at49bv.c.

Referenced by At49bvChipErase(), and At49bvSectorErase().

#define FLASH_CMD_ERASE_CHIP 0x10

Definition at line 135 of file at49bv.c.

Referenced by At49bvChipErase().

#define FLASH_CMD_ERASE_SECTOR 0x30

Definition at line 136 of file at49bv.c.

Referenced by At49bvSectorErase().

#define FLASH_CMD_ENTER_ID 0x90

Definition at line 138 of file at49bv.c.

Referenced by At49bvInit(), and AT49bvReadProtectionRegister().

#define FLASH_CMD_EXIT_ID 0xF0

Definition at line 139 of file at49bv.c.

Referenced by At49bvInit(), and AT49bvReadProtectionRegister().

#define FLASH_CMD_PROGRAM 0xA0

Definition at line 141 of file at49bv.c.

Referenced by At49bvSectorWrite().

Typedef Documentation

typedef unsigned short flashdat_t

Definition at line 117 of file at49bv.c.

typedef unsigned long flashadr_t

Definition at line 120 of file at49bv.c.

typedef volatile flashdat_t* flashptr_t

Definition at line 121 of file at49bv.c.

Function Documentation

unsigned long At49bvInit ( void )

Definition at line 164 of file at49bv.c.

References FLASH_CMD_ENTER_ID, FLASH_CMD_EXIT_ID, FLASH_COMMAND, and FLASH_UNLOCK.

unsigned long long AT49bvReadProtectionRegister ( int factory )

Read user or factory id from protection register.

Parameters:

factory If true, read factory id, otherwise read user id

Returns:: The ID read, 64 bit long!

Definition at line 185 of file at49bv.c.

References FLASH_CMD_ENTER_ID, FLASH_CMD_EXIT_ID, FLASH_COMMAND, and FLASH_UNLOCK.

int At49bvSectorErase ( unsigned int off )

Erase sector at the specified offset.

Definition at line 217 of file at49bv.c.

References FLASH_CHIP_BASE, FLASH_CMD_ERASE, FLASH_CMD_ERASE_SECTOR, FLASH_COMMAND, FLASH_ERASE_WAIT, and FLASH_UNLOCK.

Referenced by At49bvParamWrite().

int At49bvChipErase ( void )

Erase entire flash memory chip.

Definition at line 232 of file at49bv.c.

References FLASH_CHIP_ERASE_WAIT, FLASH_CMD_ERASE, FLASH_CMD_ERASE_CHIP, FLASH_COMMAND, and FLASH_UNLOCK.

int At49bvSectorRead	(	unsigned int	off,
		void *	data,
		unsigned int	len
	)

Read data from flash memory.

Parameters:

off	Start location within the chip, starting at 0.
data	Points to a buffer that receives the data.
len	Number of bytes to read.

Returns:: 0 on success or -1 in case of an error.

Definition at line 251 of file at49bv.c.

References FLASH_CHIP_BASE, and memcpy().

Referenced by At49bvParamRead(), and At49bvParamWrite().

Here is the call graph for this function:

int At49bvSectorWrite	(	unsigned int	off,
		CONST void *	data,
		unsigned int	len
	)

Write data into flash memory.

The related sector must have been erased before calling this function.

Parameters:

off	Start location within the chip, starting at 0.
data	Points to a buffer that contains the bytes to be written.
len	Number of bytes to write.

Returns:: 0 on success or -1 in case of an error.

Definition at line 269 of file at49bv.c.

References FLASH_CHIP_BASE, FLASH_CMD_PROGRAM, FLASH_COMMAND, FLASH_UNLOCK, and FLASH_WRITE_POLLS.

Referenced by At49bvParamWrite().

int At49bvParamRead	(	unsigned int	pos,
		void *	data,
		unsigned int	len
	)

Load configuration parameters from flash memory.

Parameters:

pos	Start location within configuration sector.
data	Points to a buffer that receives the contents.
len	Number of bytes to read.

Returns:: Always 0.

Definition at line 302 of file at49bv.c.

References At49bvSectorRead(), and FLASH_CONF_SECTOR.

Referenced by NutNvMemLoad().

Here is the call graph for this function:

int At49bvParamWrite	(	unsigned int	pos,
		CONST void *	data,
		unsigned int	len
	)

Store configuration parameters in flash memory.

Parameters:

pos	Start location within configuration sector.
data	Points to a buffer that contains the bytes to store.
len	Number of bytes to store.

Returns:: 0 on success or -1 in case of an error.

Definition at line 316 of file at49bv.c.

References At49bvSectorErase(), At49bvSectorRead(), At49bvSectorWrite(), FLASH_CONF_SECTOR, FLASH_CONF_SIZE, free(), malloc(), memcmp(), and memcpy().

Referenced by NutNvMemSave().

Here is the call graph for this function:
