Block device driver definitions. More...

#include <sys/types.h>
#include <stdint.h>
#include <sys/device.h>
#include <sys/file.h>

Include dependency graph for blockdev.h:

This graph shows which files directly or indirectly include this file:

Data Structures
struct	_BLKPAR_SEEK
	Block seek parameter structure. More...
struct	_BLKPAR_INFO
	Device information parameter structure. More...
struct	_NUTBLOCKIO
	Generic block I/O device interface structure. More...
Typedefs
typedef struct _BLKPAR_SEEK	BLKPAR_SEEK
	Block seek parameter structure.
typedef struct _BLKPAR_INFO	BLKPAR_INFO
	Device information parameter structure.
typedef struct _NUTBLOCKIO	NUTBLOCKIO
	Generic block I/O device interface structure type.
Functions
int	NutBlockDeviceInit (NUTDEVICE *dev)
	Initialize the block I/O device.
NUTFILE *	NutBlockDeviceOpen (NUTDEVICE dev, CONST char name, int mode, int acc)
	Mount a volume.
int	NutBlockDeviceClose (NUTFILE *nfp)
	Unmount a currently mounted volume.
int	NutBlockDeviceIOCtl (NUTDEVICE dev, int req, void conf)
	Perform block I/O device control functions.
int	NutBlockDeviceRead (NUTFILE nfp, void buffer, int num)
	Read data blocks from a mounted volume.
int	NutBlockDeviceWrite (NUTFILE nfp, CONST void buffer, int num)
	Write data blocks to a mounted volume.
long	NutBlockDeviceSize (NUTFILE *nfp)
	Return the size of a mounted volume.
int	NutBlockDeviceWrite_P (NUTFILE *nfp, PGM_P buffer, int num)
	Write data blocks from program space to a mounted volume.
Control Codes
#define	NUTBLKDEV_MEDIAAVAIL 0x1200
	Query for media change.
#define	NUTBLKDEV_MEDIACHANGE 0x1201
	Query for media change.
#define	NUTBLKDEV_INFO 0x1202
	Retrieve device information.
#define	NUTBLKDEV_SEEK 0x1203
	Block seek request.

Detailed Description

Block device driver definitions.

 *
 * $Log$
 * Revision 1.4  2009/01/09 17:59:05  haraldkipp
 * Added target independent AT45D block device drivers and non-volatile
 * memory support based on the new bus controllers.
 *
 * Revision 1.3  2008/08/11 06:59:59  haraldkipp
 * BSD types replaced by stdint types (feature request #1282721).
 *
 * Revision 1.2  2006/04/07 12:57:48  haraldkipp
 * Added ioctl(NUTBLKDEV_MEDIAAVAIL).
 *
 * Revision 1.1  2006/01/05 16:32:05  haraldkipp
 * First check-in.
 *
 *
 *

Definition in file blockdev.h.

Function Documentation

int NutBlockDeviceInit ( NUTDEVICE * dev )

Initialize the block I/O device.

This dummy routine may be used by drivers, which do not need any specific initialization.

Parameters:

dev	Specifies the device.

Returns:: Always 0.

Definition at line 131 of file blockdev.c.

References NUTASSERT.

NUTFILE* NutBlockDeviceOpen	(	NUTDEVICE *	dev,
		CONST char *	name,
		int	mode,
		int	acc
	)

Mount a volume.

Nut/OS doesn't provide specific routines for mounting. Instead routines for opening files are used.

Applications should not directly call this function, but use the high level stdio routines for opening a file.

Parameters:

dev	Specifies the block I/O device.
name	Partition number followed by a slash followed by a name of the file system device. Both items are optional. If no file system driver name is given, the first file system driver found in the list of registered devices will be used. If no partition number is specified or if partition zero is given, the first active primary partition will be used.
mode	Opening mode. Currently ignored, but _O_RDWR \| _O_BINARY should be used for compatibility with future enhancements.
acc	File attributes, ignored.

Returns:: Pointer to a newly created file pointer to the mounted partition or NUTFILE_EOF in case of any error.

Definition at line 163 of file blockdev.c.

References _NUTBLOCKIO::blkio_blk_cnt, _NUTBLOCKIO::blkio_blk_siz, _NUTBLOCKIO::blkio_vol_bot, _NUTBLOCKIO::blkio_vol_top, _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_ioctl, ENODEV, errno, free(), FS_VOL_MOUNT, _FSCP_VOL_MOUNT::fscp_bmnt, _FSCP_VOL_MOUNT::fscp_part_type, IFTYP_FS, malloc(), _NUTFILE::nf_dev, _NUTFILE::nf_fcb, _NUTFILE::nf_next, NUTASSERT, NutDeviceLookup(), NUTFILE_EOF, _BLOCKVOLUME::vol_blk_buf, _BLOCKVOLUME::vol_blk_cnt, _BLOCKVOLUME::vol_blk_len, _BLOCKVOLUME::vol_blk_num, _BLOCKVOLUME::vol_blk_off, and _BLOCKVOLUME::vol_fsdev.

Here is the call graph for this function:

int NutBlockDeviceClose ( NUTFILE * nfp )

Unmount a currently mounted volume.

Parameters:

nfp	File pointer to a previously mounted volume.

Returns:: 0 on success, -1 otherwise.

Definition at line 241 of file blockdev.c.

References _NUTDEVICE::dev_ioctl, free(), FS_VOL_UNMOUNT, _NUTFILE::nf_fcb, NUTASSERT, and _BLOCKVOLUME::vol_fsdev.

Here is the call graph for this function:

int NutBlockDeviceIOCtl	(	NUTDEVICE *	dev,
		int	req,
		void *	conf
	)

Perform block I/O device control functions.

This function is called by the ioctl() function of the C runtime library. Applications should not directly call this function.

Unkown requests are passed to the block I/O device.

Parameters:

dev	Identifies the device that receives the device-control function.
req	Requested control function. May be set to one of the following constants: NUTBLKDEV_INFO, conf points to a BLKPAR_INFO structure. NUTBLKDEV_SEEK, conf points to a BLKPAR_SEEK structure.
conf	Points to a buffer that contains any data required for the given control function or receives data from that function.

Returns:: 0 on success, -1 otherwise.

Definition at line 280 of file blockdev.c.

References _NUTBLOCKIO::blkio_ioctl, _NUTDEVICE::dev_dcb, _NUTFILE::nf_fcb, NUTASSERT, NUTBLKDEV_INFO, NUTBLKDEV_SEEK, _BLKPAR_INFO::par_blkbp, _BLKPAR_SEEK::par_blknum, _BLKPAR_INFO::par_blksz, _BLKPAR_INFO::par_nblks, _BLKPAR_SEEK::par_nfp, _BLKPAR_INFO::par_nfp, _BLOCKVOLUME::vol_blk_buf, _BLOCKVOLUME::vol_blk_cnt, _BLOCKVOLUME::vol_blk_len, and _BLOCKVOLUME::vol_blk_num.

int NutBlockDeviceRead	(	NUTFILE *	nfp,
		void *	buffer,
		int	num
	)

Read data blocks from a mounted volume.

The current position may have been set by a previous I/O control NUTBLKDEV_SEEK.

Applications should not call this function directly, but use the stdio interface.

Parameters:

nfp	File pointer to a previously mounted volume.
buffer	Pointer to the data buffer to fill.
num	Number of blocks to read.

Returns:: The number of blocks actually read. The current position is set to the next unread block. A return value of -1 indicates an error.

Definition at line 348 of file blockdev.c.

References _NUTBLOCKIO::blkio_read, _NUTDEVICE::dev_dcb, _NUTFILE::nf_dev, _NUTFILE::nf_fcb, NUTASSERT, _BLOCKVOLUME::vol_blk_cnt, _BLOCKVOLUME::vol_blk_len, _BLOCKVOLUME::vol_blk_num, and _BLOCKVOLUME::vol_blk_off.

int NutBlockDeviceWrite	(	NUTFILE *	nfp,
		CONST void *	buffer,
		int	num
	)

Write data blocks to a mounted volume.

The current position may have been set by a previous I/O control NUTBLKDEV_SEEK.

Applications should not call this function directly, but use the stdio interface.

Parameters:

nfp	File pointer to a previously mounted volume.
buffer	Pointer to the data to be written.
num	Number of blocks to write.

Returns:: The number of blocks actually written. The current position is set to the next block. A return value of -1 indicates an error.

Definition at line 400 of file blockdev.c.

References _NUTBLOCKIO::blkio_write, CONST, _NUTDEVICE::dev_dcb, _NUTFILE::nf_dev, _NUTFILE::nf_fcb, NUTASSERT, _BLOCKVOLUME::vol_blk_cnt, _BLOCKVOLUME::vol_blk_len, _BLOCKVOLUME::vol_blk_num, and _BLOCKVOLUME::vol_blk_off.

long NutBlockDeviceSize ( NUTFILE * nfp )

Return the size of a mounted volume.

Parameters:

nfp	File pointer to a previously mounted volume.

Returns:: Total number of bytes.

Definition at line 495 of file blockdev.c.

References _NUTFILE::nf_fcb, NUTASSERT, _BLOCKVOLUME::vol_blk_cnt, and _BLOCKVOLUME::vol_blk_len.

int NutBlockDeviceWrite_P	(	NUTFILE *	nfp,
		PGM_P	buffer,
		int	num
	)

Write data blocks from program space to a mounted volume.

Similar to NutBlockDeviceWrite() except that the data is located in program memory.

Applications should not call this function directly, but use the stdio interface.

Parameters:

nfp	File pointer to a previously mounted volume.
buffer	Pointer to the data bytes in program space to be written.
num	Number of blocks to write.

Returns:: The number of blocks actually written. The current position is set to the next block. A return value of -1 indicates an error.

Definition at line 452 of file blockdev.c.

References _NUTBLOCKIO::blkio_write, _NUTBLOCKIO::blkio_write_P, _NUTDEVICE::dev_dcb, _NUTFILE::nf_dev, _NUTFILE::nf_fcb, NUTASSERT, PGM_P, _BLOCKVOLUME::vol_blk_cnt, _BLOCKVOLUME::vol_blk_len, _BLOCKVOLUME::vol_blk_num, and _BLOCKVOLUME::vol_blk_off.
