#include <cfg/os.h>#include <cfg/arch/avr.h>#include <string.h>#include <sys/atom.h>#include <sys/heap.h>#include <sys/thread.h>#include <sys/event.h>#include <sys/timer.h>#include <sys/confnet.h>#include <netinet/if_ether.h>#include <net/ether.h>#include <net/if_var.h>#include <dev/irqreg.h>#include <dev/cs8900a.h>#include <stdio.h>#include <arch/arm/lpc2xxx.h>#include <__armlib.h>
Go to the source code of this file.
Data Structures | |
| struct | _NICINFO |
| Network interface controller information structure. More... | |
Defines | |
| #define | cli() __ARMLIB_disableIRQ() |
| #define | sei() __ARMLIB_enableIRQ() |
| #define | CS_DATA_P0 (cs_base + 0x0000UL) |
| #define | CS_DATA_P1 (cs_base + 0x0002UL) |
| #define | CS_TX_CMD_I (cs_base + 0x0004UL) |
| #define | CS_TX_LEN_I (cs_base + 0x0006UL) |
| #define | CS_INT_STAT (cs_base + 0x0008UL) |
| #define | CS_PP_PTR (cs_base + 0x000AUL) |
| #define | CS_PP_DATA0 (cs_base + 0x000CUL) |
| #define | CS_PP_DATA1 (cs_base + 0x000EUL) |
| #define | CS_PROD_ID 0x0000 |
| #define | CS_IO_BASE 0x0020 |
| #define | CS_INT_NUM 0x0022 |
| #define | CS_DMA_CHAN 0x0024 |
| #define | CS_DMA_SOF 0x0026 |
| #define | CS_DMA_FCNT 0x0028 |
| #define | CS_DMA_RXCNT 0x002A |
| #define | CS_MEM_BASE 0x002C |
| #define | CS_BOOT_BASE 0x0030 |
| #define | CS_BOOT_MASK 0x0034 |
| #define | CS_EE_CMD 0x0040 |
| #define | CS_EE_DATA 0x0042 |
| #define | CS_RX_FRM_CNT 0x0050 |
| #define | CS_ISQ 0x0120 |
| #define | CS_RX_CFG 0x0102 |
| #define | CS_RX_EVENT 0x0124 |
| #define | CS_RX_CTL 0x0104 |
| #define | CS_TX_CFG 0x0106 |
| #define | CS_TX_EVENT 0x0128 |
| #define | CS_TX_CMD_P 0x0108 |
| #define | CS_BUF_CFG 0x010A |
| #define | CS_BUF_EVENT 0x012C |
| #define | CS_RX_MISS 0x0130 |
| #define | CS_TX_COLL 0x0132 |
| #define | CS_LINE_CTRL 0x0112 |
| #define | CS_LINE_STAT 0x0134 |
| #define | CS_SELF_CTRL 0x0114 |
| #define | CS_SELF_STAT 0x0136 |
| #define | CS_BUS_CTRL 0x0116 |
| #define | CS_BUS_STAT 0x0138 |
| #define | CS_TEST_CTRL 0x0118 |
| #define | CS_AUI_TDR 0x013C |
| #define | CS_PP_TX_CMD 0x0144 |
| #define | CS_PP_TX_LEN 0x0146 |
| #define | CS_IEEE_ADDR 0x0158 |
Typedefs | |
| typedef struct _NICINFO | NICINFO |
| Network interface controller information type. | |
Functions | |
| void | CSWrite16 (uint32_t addr, uint16_t data) |
| void | CSWritePP16 (uint16_t addr, uint16_t data) |
| uint16_t | CSRead16 (uint32_t addr) |
| uint16_t | CSReadPP16 (uint16_t addr) |
| void | CSBeginFrame (void) |
| void | CSEndFrame (void) |
| void | CSWriteFrameByte (uint8_t data) |
| void | CSSoftwareWakeup (void) |
| void | CSSoftwareReset (void) |
| void | CSNICrx (void *arg) |
| NIC receiver thread. | |
| int | cs8900Output (NUTDEVICE *dev, NETBUF *nb) |
| Send Ethernet packet. | |
| int | cs8900Init (NUTDEVICE *dev) |
| Initialize Ethernet hardware. | |
Variables | |
| volatile uint32_t | cs_base = 0x82000000UL |
| NUTDEVICE | devCS8900A |
| Device information structure. | |
| #define cli | ( | ) | __ARMLIB_disableIRQ() |
Definition at line 136 of file cs8900a.c.
Referenced by CSEndFrame(), CSRead16(), CSReadPP16(), CSWrite16(), and CSWritePP16().
| #define sei | ( | ) | __ARMLIB_enableIRQ() |
Definition at line 137 of file cs8900a.c.
Referenced by CSEndFrame(), CSRead16(), and CSWrite16().
| #define CS_DATA_P0 (cs_base + 0x0000UL) |
Definition at line 146 of file cs8900a.c.
Referenced by CSEndFrame(), CSNICrx(), CSSoftwareReset(), and CSWriteFrameByte().
| #define CS_PP_PTR (cs_base + 0x000AUL) |
Definition at line 151 of file cs8900a.c.
Referenced by CSReadPP16(), CSReadPP32(), CSSoftwareReset(), CSSoftwareWakeup(), and CSWritePP16().
| #define CS_PP_DATA0 (cs_base + 0x000CUL) |
Definition at line 152 of file cs8900a.c.
Referenced by CSReadPP16(), CSReadPP32(), and CSWritePP16().
| #define CS_PROD_ID 0x0000 |
Definition at line 157 of file cs8900a.c.
Referenced by cs8900Init(), and CSNicInit().
| #define CS_RX_CTL 0x0104 |
Definition at line 174 of file cs8900a.c.
Referenced by cs8900Init(), and CSNicInit().
| #define CS_LINE_CTRL 0x0112 |
Definition at line 182 of file cs8900a.c.
Referenced by cs8900Init(), and CSNicInit().
| #define CS_SELF_CTRL 0x0114 |
Definition at line 184 of file cs8900a.c.
Referenced by CSSoftwareReset(), and CSSoftwareWakeup().
| #define CS_IEEE_ADDR 0x0158 |
Definition at line 194 of file cs8900a.c.
Referenced by cs8900Init(), and CSNicInit().
