File transfer protocol. More...

Collaboration diagram for FTP:

Data Structures
struct	FTPSESSION
	FTP session information structure. More...
Functions
int	NutFtpRespondOk (FTPSESSION *session, int code)
	Send a positive response.
int	NutFtpRespondBad (FTPSESSION *session, int code)
	Send a negative response.
int	NutFtpSendMode (FTPSESSION *session, int binary)
	Send a response including the specified transfer mode.
char *	CreateFullPathName (char root, char work, char *path)
	Create an absolute path name.
TCPSOCKET *	NutFtpDataConnect (FTPSESSION *session)
	Establish an FTP connection for data transfer.
int	NutRegisterFtpRoot (CONST char *path)
	Register the FTP server's root directory.
int	NutRegisterFtpUser (CONST char user, CONST char pass)
	Register an FTP user.
FTPSESSION *	NutFtpOpenSession (TCPSOCKET *sock)
	Open an FTP server session.
void	NutFtpCloseSession (FTPSESSION *session)
	Close an FTP server session.
int	NutFtpProcessCwd (FTPSESSION session, char path)
	Process an FTP client's CWD command.
int	NutFtpProcessDelete (FTPSESSION session, char path)
	Process an FTP client's DELE command.
int	NutFtpTransferFile (FTPSESSION session, char path, int mode)
	Transfer a file to or from the FTP client.
int	NutFtpTransferDirectoryOptions (FTPSESSION session, char path, int options)
	Process an FTP client's LIST or NLST command.
int	NutFtpTransferDirectory (FTPSESSION session, char path)
	Process an FTP client's LIST or NLST command.
int	NutFtpProcessMkd (FTPSESSION session, char path)
	Process an FTP client's MKD command.
int	NutFtpRenamePrepare (FTPSESSION session, char path)
int	NutFtpRenameAction (FTPSESSION session, char path)
int	NutFtpProcessPass (FTPSESSION session, char pass)
	Process an FTP client's PASS command.
int	NutFtpProcessPassiv (FTPSESSION *session)
	Process an FTP client's PASV command.
int	NutFtpProcessPort (FTPSESSION session, char args)
	Process an FTP client's PORT command.
int	NutFtpProcessPwd (FTPSESSION *session)
	Process an FTP client's PWD command.
int	NutFtpProcessRmd (FTPSESSION session, char path)
	Process an FTP client's RMD command.
int	NutFtpProcessSystem (FTPSESSION *session)
	Process an FTP client's SYST command.
int	NutFtpProcessType (FTPSESSION session, char typecode)
	Process an FTP client's TYPE command.
int	NutFtpProcessUser (FTPSESSION session, char user)
	Process an FTP client's USER command.
int	NutFtpProcessRequest (FTPSESSION session, char request)
	Process an FTP request.
int	NutFtpServerSession (TCPSOCKET *sock)
	Process an FTP sever session.
FTP Server Configuration
The Nut/OS Configurator may be used to override the default values.
#define	FTP_MAX_CMDBUF 128
	UDP port of DHCP server.
FTP Server Configuration
The Nut/OS Configurator may be used to override the default values.
#define	FTP_ROOTPATH "PNUT:"
	Default FTP root path.
#define	FTP_DATA_PORT 20
	Default data port.

Detailed Description

File transfer protocol.

Note, that FTP servers don't make much sense without a file system providing write access. Right now, FTP had been tested with the PNUT file system only.

Internet File Transfer Protocol Server.

Define Documentation

#define FTP_MAX_CMDBUF 128

UDP port of DHCP server.

Definition at line 71 of file ftpd.h.

Referenced by NutFtpServerSession().

#define FTP_ROOTPATH "PNUT:"

Default FTP root path.

Definition at line 138 of file ftpd.c.

Referenced by NutRegisterFtpRoot().

#define FTP_DATA_PORT 20

Default data port.

Definition at line 147 of file ftpd.c.

Referenced by NutFtpOpenSession().

Function Documentation

int NutFtpRespondOk	(	FTPSESSION *	session,
		int	code
	)

Send a positive response.

Parameters:

session	Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().
code	Response code.

Returns:: -1 if the session ended. Otherwise 0 is returned.

Definition at line 287 of file ftpd.c.

References fflush(), fprintf_P, FTPSESSION::ftp_stream, printf, and prog_char.

Referenced by NutFtpProcessCwd(), NutFtpProcessDelete(), NutFtpProcessMkd(), NutFtpProcessPass(), NutFtpProcessPort(), NutFtpProcessRequest(), NutFtpProcessRmd(), NutFtpProcessType(), NutFtpProcessUser(), NutFtpRenameAction(), NutFtpRenamePrepare(), NutFtpTransferDirectoryOptions(), and NutFtpTransferFile().

Here is the call graph for this function:

int NutFtpRespondBad	(	FTPSESSION *	session,
		int	code
	)

Send a negative response.

Parameters:

session	Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().
code	Response code.

Returns:: -1 if the session ended. Otherwise 0 is returned.

Definition at line 309 of file ftpd.c.

References fflush(), fprintf_P, FTPSESSION::ftp_stream, printf, and prog_char.

Referenced by NutFtpProcessCwd(), NutFtpProcessDelete(), NutFtpProcessMkd(), NutFtpProcessPass(), NutFtpProcessPort(), NutFtpProcessRequest(), NutFtpProcessRmd(), NutFtpProcessUser(), NutFtpRenameAction(), NutFtpRenamePrepare(), NutFtpServerSession(), NutFtpTransferDirectoryOptions(), and NutFtpTransferFile().

Here is the call graph for this function:

int NutFtpSendMode	(	FTPSESSION *	session,
		int	binary
	)

Send a response including the specified transfer mode.

Parameters:

session	Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().
binary	0 indicates ASCII transfer mode.

Returns:: -1 if the session ended. Otherwise 0 is returned.

Definition at line 331 of file ftpd.c.

References fflush(), fputs_P, FTPSESSION::ftp_stream, printf, and prog_char.

Referenced by NutFtpTransferDirectoryOptions(), and NutFtpTransferFile().

Here is the call graph for this function:

char* CreateFullPathName	(	char *	root,
		char *	work,
		char *	path
	)

Create an absolute path name.

Combines an absolute directory path with a relative path name to a full absolute path name. The absolute directory is split into two parts, the root and the current work directory. The resulting path will never be above the specified root.

Parameters:

root	Non-empty absolute root directory path including the device name, but without a trailing slash.
work	Absolute work directory path below root including a leading, but without a trailing slash. This path is ignored if the relative path starts with a slash.
path	Relative path name of a file or directory without any trailing slash.

Returns:: Pointer to the resulting path name. The buffer for this name is allocated from heap memory. The caller is responsible for freeing it. In case of an error, a NULL pointer is returned.

Definition at line 367 of file ftpd.c.

References malloc(), strcpy(), and strlen().

Referenced by NutFtpProcessRequest().

Here is the call graph for this function:

TCPSOCKET* NutFtpDataConnect ( FTPSESSION * session )

Establish an FTP connection for data transfer.

Parameters:

session Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().

Returns:: Socket descriptor of the newly created data connection or 0 if we were unable to establish the connection.

Definition at line 465 of file ftpd.c.

References FTPSESSION::ftp_data_ip, FTPSESSION::ftp_data_port, FTPSESSION::ftp_maxseg, FTPSESSION::ftp_passive, NutTcpAccept(), NutTcpCloseSocket(), NutTcpConnect(), NutTcpCreateSocket(), NutTcpError(), NutTcpSetSockOpt(), printf_P(), prog_char, puts_P(), and TCP_MAXSEG.

Referenced by NutFtpTransferDirectoryOptions(), and NutFtpTransferFile().

Here is the call graph for this function:

int NutRegisterFtpRoot ( CONST char * path )

Register the FTP server's root directory.

Only one root directory is supported. Subsequent calls will override previous settings.

Parameters:

path	Path name of the root directory. Must include the device name followed by a colon followed by an absolute directory path. May be set to NULL for the default FTP_ROOTPATH.

Returns:: 0 on success, -1 otherwise.

Definition at line 516 of file ftpd.c.

References free(), FTP_ROOTPATH, malloc(), strchr(), strcpy(), and strlen().

Referenced by main(), and NutFtpServerSession().

Here is the call graph for this function:

int NutRegisterFtpUser	(	CONST char *	user,
		CONST char *	pass
	)

Register an FTP user.

Only one username/password pair is supported. Subsequent calls will override previous settings.

Warning:: Not successfully registering any will make file systems accessible by anyone.

Parameters:

user	User's name.
pass	Uncrypted password for the specified user.

Returns:: 0 on success. -1 is returned on failures, in which case no protection may be assumed.

Definition at line 576 of file ftpd.c.

References free(), and strdup().

Here is the call graph for this function:

FTPSESSION* NutFtpOpenSession ( TCPSOCKET * sock )

Open an FTP server session.

Parameters:

sock	Socket of an established TCP connection.

Returns:: Pointer to an FTPSESSION structure, which can be used in subsequent API calls. NULL is returned in case of any error.

Definition at line 609 of file ftpd.c.

References _fdopen(), free(), FTPSESSION::ftp_cwd, FTPSESSION::ftp_data_port, FTP_DATA_PORT, FTPSESSION::ftp_maxseg, FTPSESSION::ftp_sock, FTPSESSION::ftp_stream, malloc(), memset(), and tcp_socket::so_mss.

Referenced by NutFtpServerSession().

Here is the call graph for this function:

void NutFtpCloseSession ( FTPSESSION * session )

Close an FTP server session.

Parameters:

session Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().

Definition at line 650 of file ftpd.c.

References fclose(), free(), FTPSESSION::ftp_cwd, FTPSESSION::ftp_renamesource, and FTPSESSION::ftp_stream.

Referenced by NutFtpServerSession().

Here is the call graph for this function:

int NutFtpProcessCwd	(	FTPSESSION *	session,
		char *	path
	)

Process an FTP client's CWD command.

Parameters:

session	Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().
path	Full absolute path name of the directory.

Returns:: 0 if the command has been processed or -1 if the session has been aborted.

Definition at line 675 of file ftpd.c.

References free(), FTPSESSION::ftp_cwd, NutFtpRespondBad(), NutFtpRespondOk(), S_ISDIR, stat::st_mode, stat(), strcmp(), strdup(), and strlen().

Referenced by NutFtpProcessRequest().

Here is the call graph for this function:

int NutFtpProcessDelete	(	FTPSESSION *	session,
		char *	path
	)

Process an FTP client's DELE command.

Causes the specified file to be deleted.

Parameters:

session	Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().
path	Full absolute path name of the file.

Returns:: 0 if the command has been processed or -1 if the session has been aborted.

Definition at line 716 of file ftpd.c.

References NutFtpRespondBad(), NutFtpRespondOk(), and unlink().

Referenced by NutFtpProcessRequest().

Here is the call graph for this function:

int NutFtpTransferFile	(	FTPSESSION *	session,
		char *	path,
		int	mode
	)

Transfer a file to or from the FTP client.

Parameters:

session	Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().
path	Full absolute path name of the file.
mode	If set to zero, the server will accept the data transferred via the data connection and to store the data as a file. If the file exists, then its contents will be replaced by the data being transferred. A new file is created, if the file does not already exist. If this parameter is not equal zero, then the server will transfer a copy of the specified file.

Returns:: 0 if the command has been processed or -1 if the session has been aborted.

Definition at line 741 of file ftpd.c.

References _close(), _O_BINARY, _O_CREAT, _O_RDONLY, _O_TRUNC, _open(), _read(), _write(), free(), FTPSESSION::ftp_tran_mode, malloc(), NutFtpDataConnect(), NutFtpRespondBad(), NutFtpRespondOk(), NutFtpSendMode(), NutSleep(), NutTcpCloseSocket(), NutTcpReceive(), NutTcpSend(), printf, prog_char, puts_P(), S_ISREG, tcp_socket::so_mss, stat::st_mode, stat(), and unlink().

Referenced by NutFtpProcessRequest().

Here is the call graph for this function:

int NutFtpTransferDirectoryOptions	(	FTPSESSION *	session,
		char *	path,
		int	options
	)

Process an FTP client's LIST or NLST command.

Causes a directory listing to be sent to the client.

Parameters:

session	Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().
path	Full absolute path name of the directory.
options	Set to 1 to incude filenames beginning with a "." (unix hidden files)

Returns:: 0 if the command has been processed or -1 if the session has been aborted.

Definition at line 860 of file ftpd.c.

References _fdopen(), closedir(), dirent::d_name, fclose(), fprintf_P, fputc(), fputs(), free(), gmtime(), malloc(), NutFtpDataConnect(), NutFtpRespondBad(), NutFtpRespondOk(), NutFtpSendMode(), NutTcpCloseSocket(), opendir(), prog_char, readdir(), S_ISDIR, stat::st_mode, stat::st_mtime, stat::st_size, stat(), strcat(), strcpy(), strlen(), _tm::tm_hour, _tm::tm_mday, _tm::tm_min, and _tm::tm_mon.

Referenced by NutFtpProcessRequest(), and NutFtpTransferDirectory().

Here is the call graph for this function:

int NutFtpTransferDirectory	(	FTPSESSION *	session,
		char *	path
	)

Process an FTP client's LIST or NLST command.

Causes a directory listing to be sent to the client.

Parameters:

session	Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().
path	Full absolute path name of the directory.

Returns:: 0 if the command has been processed or -1 if the session has been aborted.

Definition at line 938 of file ftpd.c.

References NutFtpTransferDirectoryOptions().

Here is the call graph for this function:

int NutFtpProcessMkd	(	FTPSESSION *	session,
		char *	path
	)

Process an FTP client's MKD command.

Causes the specified directory to be created.

Parameters:

session	Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().
path	Full absolute path name of the directory.

Returns:: 0 if the command has been processed or -1 if the session has been aborted.

Definition at line 955 of file ftpd.c.

References mkdir(), NutFtpRespondBad(), and NutFtpRespondOk().

Referenced by NutFtpProcessRequest().

Here is the call graph for this function:

int NutFtpRenamePrepare	(	FTPSESSION *	session,
		char *	path
	)

Definition at line 964 of file ftpd.c.

References free(), FTPSESSION::ftp_renamesource, NutFtpRespondBad(), NutFtpRespondOk(), stat(), and strdup().

Referenced by NutFtpProcessRequest().

Here is the call graph for this function:

int NutFtpRenameAction	(	FTPSESSION *	session,
		char *	path
	)

Definition at line 984 of file ftpd.c.

References free(), FTPSESSION::ftp_renamesource, NutFtpRespondBad(), NutFtpRespondOk(), and rename().

Referenced by NutFtpProcessRequest().

Here is the call graph for this function:

int NutFtpProcessPass	(	FTPSESSION *	session,
		char *	pass
	)

Process an FTP client's PASS command.

Only one login per session is accepted.

Parameters:

session	Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().
pass	Password.

Returns:: 0 if the command has been processed or -1 if the session has been aborted.

Definition at line 1019 of file ftpd.c.

References FTPSESSION::ftp_login, NutFtpRespondBad(), NutFtpRespondOk(), and strcmp().

Referenced by NutFtpProcessRequest().

Here is the call graph for this function:

int NutFtpProcessPassiv ( FTPSESSION * session )

Process an FTP client's PASV command.

This command requests the server to listen on a data port and to wait for a connection rather than initiate one upon receipt of a transfer command.

Parameters:

session Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().

Returns:: 0 if the command has been processed or -1 if the session has been aborted.

Definition at line 1044 of file ftpd.c.

References fflush(), fprintf_P, FTPSESSION::ftp_passive, FTPSESSION::ftp_sock, FTPSESSION::ftp_stream, prog_char, and tcp_socket::so_local_addr.

Referenced by NutFtpProcessRequest().

Here is the call graph for this function:

int NutFtpProcessPort	(	FTPSESSION *	session,
		char *	args
	)

Process an FTP client's PORT command.

Parameters:

session	Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().
args	Command argument, which is the concatenation of the 32-bit internet host address and a 16-bit TCP port address. This address information is broken into 8-bit fields and the value of each field is transmitted as a decimal number.

Returns:: 0 if the command has been processed or -1 if the session has been aborted.

Definition at line 1073 of file ftpd.c.

References FTPSESSION::ftp_data_ip, FTPSESSION::ftp_data_port, FTPSESSION::ftp_sock, NutFtpRespondBad(), NutFtpRespondOk(), and tcp_socket::so_remote_addr.

Referenced by NutFtpProcessRequest().

Here is the call graph for this function:

int NutFtpProcessPwd ( FTPSESSION * session )

Process an FTP client's PWD command.

Causes the name of the current working directory to be returned in the reply.

Parameters:

session Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().

Returns:: 0 if the command has been processed or -1 if the session has been aborted.

Definition at line 1096 of file ftpd.c.

References fprintf_P, FTPSESSION::ftp_cwd, FTPSESSION::ftp_stream, printf, and prog_char.

Referenced by NutFtpProcessRequest().

int NutFtpProcessRmd	(	FTPSESSION *	session,
		char *	path
	)

Process an FTP client's RMD command.

Causes the specified directory to be removed.

Parameters:

session	Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().
path	Full absolute path name of the directory.

Returns:: 0 if the command has been processed or -1 if the session has been aborted.

Definition at line 1118 of file ftpd.c.

References NutFtpRespondBad(), NutFtpRespondOk(), and rmdir().

Referenced by NutFtpProcessRequest().

Here is the call graph for this function:

int NutFtpProcessSystem ( FTPSESSION * session )

Process an FTP client's SYST command.

Parameters:

session Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().

Returns:: 0 if the command has been processed or -1 if the session has been aborted.

Definition at line 1135 of file ftpd.c.

References fputs_P, FTPSESSION::ftp_stream, printf, and prog_char.

Referenced by NutFtpProcessRequest().

int NutFtpProcessType	(	FTPSESSION *	session,
		char *	typecode
	)

Process an FTP client's TYPE command.

The type is not fully checked. Any argument starting with the letters 'A' or 'a' will switch the transfer mode to ASCII. Otherwise binary mode is set.

Parameters:

session	Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().
typecode	Command arguments.

Returns:: 0 if the command has been processed or -1 if the session has been aborted.

Definition at line 1159 of file ftpd.c.

References FTPSESSION::ftp_tran_mode, and NutFtpRespondOk().

Referenced by NutFtpProcessRequest().

Here is the call graph for this function:

int NutFtpProcessUser	(	FTPSESSION *	session,
		char *	user
	)

Process an FTP client's USER command.

Only one login per session is accepted.

Parameters:

session	Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().
user	User name.

Returns:: 0 if the command has been processed or -1 if the session has been aborted.

Definition at line 1177 of file ftpd.c.

References FTPSESSION::ftp_login, NutFtpRespondBad(), NutFtpRespondOk(), and strcmp().

Referenced by NutFtpProcessRequest().

Here is the call graph for this function:

int NutFtpProcessRequest	(	FTPSESSION *	session,
		char *	request
	)

Process an FTP request.

This routine implements the protocol interpreter of the FTP server.

Parameters:

session	Pointer to an FTPSESSION structure, obtained by a previous call to NutFtpOpenSession().
request	Request string.

Returns:: -1 if the session ended. Otherwise 0 is returned.

Definition at line 1208 of file ftpd.c.

References CreateFullPathName(), free(), FTPSESSION::ftp_cwd, FTPSESSION::ftp_login, FTPSESSION::ftp_renamesource, NutFtpProcessCwd(), NutFtpProcessDelete(), NutFtpProcessMkd(), NutFtpProcessPass(), NutFtpProcessPassiv(), NutFtpProcessPort(), NutFtpProcessPwd(), NutFtpProcessRmd(), NutFtpProcessSystem(), NutFtpProcessType(), NutFtpProcessUser(), NutFtpRenameAction(), NutFtpRenamePrepare(), NutFtpRespondBad(), NutFtpRespondOk(), NutFtpTransferDirectoryOptions(), NutFtpTransferFile(), printf, strchr(), strcmp_P, and strlen().

Referenced by NutFtpServerSession().

Here is the call graph for this function:

int NutFtpServerSession ( TCPSOCKET * sock )

Process an FTP sever session.

Processes FTP requests on an established connection with an FTP client. This routine completely implements an FTP server except TCP connect and disconnect.

For file transfers, the same maximum segment size and timeouts as set for this socket will be used for the data connection.

Parameters:

sock	Socket of an established TCP connection.

Returns:: 0 if the session ended successfully or -1 if the session has been aborted.

Definition at line 1363 of file ftpd.c.

References fflush(), fgets(), fprintf_P, free(), FTP_MAX_CMDBUF, FTPSESSION::ftp_stream, localtime(), malloc(), NutFtpCloseSession(), NutFtpOpenSession(), NutFtpProcessRequest(), NutFtpRespondBad(), NutRegisterFtpRoot(), NutVersionString(), printf, printf_P(), strlen(), time(), _tm::tm_hour, _tm::tm_mday, _tm::tm_min, _tm::tm_mon, and _tm::tm_sec.

Here is the call graph for this function:

Data Structures

Functions

FTP Server Configuration

FTP Server Configuration

Detailed Description

Define Documentation

Function Documentation
