PAP

Password authentication protocol. More...

Collaboration diagram for PAP:

Functions
void	PapRxAuthReq (NUTDEVICE *dev, uint8_t id, NETBUF *nb)
void	PapRxAuthAck (NUTDEVICE *dev, uint8_t id, NETBUF *nb)
void	PapRxAuthNak (NUTDEVICE *dev, uint8_t id, NETBUF *nb)
void	NutPapInput (NUTDEVICE *dev, NETBUF *nb)
	Handle incoming PAP packets.
int	NutPapOutput (NUTDEVICE *dev, uint8_t code, uint8_t id, NETBUF *nb)
	Send a PAP packet.
void	PapTxAuthReq (NUTDEVICE *dev, uint8_t id)

---

Detailed Description

Password authentication protocol.

---

Function Documentation

void PapRxAuthReq	(	NUTDEVICE *	dev,
		uint8_t	id,
		NETBUF *	nb
	)

Definition at line 86 of file papin.c.

References NutPapOutput(), and XCP_CONFACK.

Referenced by NutPapInput().

Here is the call graph for this function:

void PapRxAuthAck	(	NUTDEVICE *	dev,
		uint8_t	id,
		NETBUF *	nb
	)

Definition at line 91 of file papin.c.

References _PPPDCB::dcb_auth_state, _NUTDEVICE::dev_dcb, IpcpLowerUp(), PAPCS_AUTHREQ, and PAPCS_OPEN.

Referenced by NutPapInput().

Here is the call graph for this function:

void PapRxAuthNak	(	NUTDEVICE *	dev,
		uint8_t	id,
		NETBUF *	nb
	)

Definition at line 104 of file papin.c.

References _PPPDCB::dcb_auth_state, _NUTDEVICE::dev_dcb, IpcpLowerDown(), PAPCS_AUTHREQ, and PAPCS_BADAUTH.

Referenced by NutPapInput().

Here is the call graph for this function:

void NutPapInput	(	NUTDEVICE *	dev,
		NETBUF *	nb
	)

Handle incoming PAP packets.

Parameters:

dev	Identifies the device that received the packet.
nb	Pointer to a network buffer structure containing the PAP packet.

Definition at line 122 of file papin.c.

References htons, _NETBUF::nb_ap, _NETBUF::nb_nw, NutNetBufFree(), PapRxAuthAck(), PapRxAuthNak(), PapRxAuthReq(), _NBDATA::sz, _NBDATA::vp, xcphdr::xch_code, xcphdr::xch_id, xcphdr::xch_len, XCP_CONFACK, XCP_CONFNAK, and XCP_CONFREQ.

Referenced by NutPppInput().

Here is the call graph for this function:

int NutPapOutput	(	NUTDEVICE *	dev,
		uint8_t	code,
		uint8_t	id,
		NETBUF *	nb
	)

Send a PAP packet.

Note:

Applications typically do not call this function.

Parameters:

dev	Identifies the device to use.
code	Type subcode.
id	Exchange identifier.
nb	Network buffer structure containing the packet to send or null if the packet contains no information. The structure must have been allocated by a previous call NutNetBufAlloc() and will be freed when this function returns.

Returns:

0 on success, -1 in case of any errors.

Definition at line 167 of file papout.c.

References htons, _NETBUF::nb_ap, _NETBUF::nb_nw, _NETBUF::nb_tp, NBAF_NETWORK, NutNetBufAlloc(), NutNetBufFree(), NutPppOutput(), PPP_PAP, _NBDATA::sz, _NBDATA::vp, xcphdr::xch_code, xcphdr::xch_id, and xcphdr::xch_len.

Referenced by PapRxAuthReq(), and PapTxAuthReq().

Here is the call graph for this function:

void PapTxAuthReq	(	NUTDEVICE *	dev,
		uint8_t	id
	)

Definition at line 188 of file papout.c.

References _PPPDCB::dcb_auth_state, _PPPDCB::dcb_pass, _PPPDCB::dcb_reqid, _PPPDCB::dcb_user, _NUTDEVICE::dev_dcb, memcpy(), _NETBUF::nb_ap, NBAF_APPLICATION, NutNetBufAlloc(), NutPapOutput(), PAPCS_AUTHREQ, strlen(), _NBDATA::vp, and XCP_CONFREQ.

Referenced by NutPppSm().

Here is the call graph for this function:
