ds1307rtc.c File Reference

RTC and RAM routines for the Dallas DS1307 clock chip. More...

#include <cfg/os.h>
#include <dev/twif.h>
#include <sys/event.h>
#include <sys/timer.h>
#include <stdlib.h>
#include <string.h>
#include <dev/ds1307rtc.h>
Include dependency graph for ds1307rtc.c:

Go to the source code of this file.

Defines

#define I2C_SLA_RTC   0x68

Functions

int DS1307RtcReadRegs (uint8_t reg, uint8_t *buff, size_t cnt)
 Read RTC registers.
int DS1307RtcWrite (CONST uint8_t *buff, size_t cnt)
 Write to RTC registers.
int DS1307RtcGetClock (struct _tm *tm)
 Get date and time from an DS1307 hardware clock.
int DS1307RtcSetClock (CONST struct _tm *tm)
 Set the DS1307 hardware clock.
int DS1307RamRead (uint8_t addr, uint8_t *buff, size_t cnt)
 Read contents from DS1307 RAM.
int DS1307RamWrite (uint8_t addr, CONST void *buff, size_t len)
 Store buffer contents in DS1307 RAM.
int DS1307Init (void)
 Initialize the interface to an Dallas DS1307 hardware clock.

Variables

NUTRTC rtcDs1307

Detailed Description

RTC and RAM routines for the Dallas DS1307 clock chip.

 *
 * $Log$
 * Revision 1.6  2008/08/11 06:59:42  haraldkipp
 * BSD types replaced by stdint types (feature request #1282721).
 *
 * Revision 1.5  2007/09/11 17:32:30  haraldkipp
 * Last minute fix (bug #1786271)
 *
 * Revision 1.4  2006/10/08 16:39:33  haraldkipp
 * Corrected range check in DS1307RamRead(). Thanks to Helmut Holbach.
 *
 * Revision 1.3  2006/10/05 17:18:49  haraldkipp
 * Hardware independant RTC layer added.
 *
 * Revision 1.2  2006/08/25 13:42:55  olereinhardt
 * avr-gcc 3.4 does not understand binary representation of numbers,
 * changed to hex
 *
 * Revision 1.1  2006/06/30 22:05:51  christianwelzel
 * Initial check in.
 *
 *
 *

Definition in file ds1307rtc.c.


Define Documentation

#define I2C_SLA_RTC   0x68

Definition at line 76 of file ds1307rtc.c.

Referenced by DS1307RamWrite(), DS1307RtcReadRegs(), and DS1307RtcWrite().


Function Documentation

int DS1307RtcReadRegs ( uint8_t  reg,
uint8_t buff,
size_t  cnt
)

Read RTC registers.

Parameters:
regThe first register to read.
buffPointer to a buffer that receives the register contents.
cntThe number of registers to read.
Returns:
0 on success or -1 in case of an error.

Definition at line 89 of file ds1307rtc.c.

References I2C_SLA_RTC, NUT_WAIT_INFINITE, and TwMasterTransact().

Referenced by DS1307Init(), DS1307RamRead(), and DS1307RtcGetClock().

Here is the call graph for this function:

int DS1307RtcWrite ( CONST uint8_t buff,
size_t  cnt
)

Write to RTC registers.

Parameters:
buffThis buffer must contain all bytes to be transfered to the RTC chip, including the register address.
cntNumber of valid bytes in the buffer.
Returns:
0 on success or -1 in case of an error.

Definition at line 110 of file ds1307rtc.c.

References I2C_SLA_RTC, NUT_WAIT_INFINITE, and TwMasterTransact().

Referenced by DS1307Init(), and DS1307RtcSetClock().

Here is the call graph for this function:

int DS1307RtcGetClock ( struct _tm tm)

Get date and time from an DS1307 hardware clock.

Parameters:
tmPoints to a structure that receives the date and time information.
Returns:
0 on success or -1 in case of an error.

Definition at line 126 of file ds1307rtc.c.

References BCD2BIN, DS1307RtcReadRegs(), _tm::tm_hour, _tm::tm_mday, _tm::tm_min, _tm::tm_mon, _tm::tm_sec, _tm::tm_wday, and _tm::tm_year.

Here is the call graph for this function:

int DS1307RtcSetClock ( CONST struct _tm tm)

Set the DS1307 hardware clock.

Parameters:
tmPoints to a structure which contains the date and time information.
Returns:
0 on success or -1 in case of an error.

Definition at line 151 of file ds1307rtc.c.

References BIN2BCD, DS1307RtcWrite(), and memset().

Here is the call graph for this function:

int DS1307RamRead ( uint8_t  addr,
uint8_t buff,
size_t  cnt
)

Read contents from DS1307 RAM.

Parameters:
addrStart location.
buffPoints to a buffer that receives the contents.
cntNumber of bytes to read.
Returns:
0 on success or -1 in case of an error.

Definition at line 178 of file ds1307rtc.c.

References DS1307RtcReadRegs().

Here is the call graph for this function:

int DS1307RamWrite ( uint8_t  addr,
CONST void *  buff,
size_t  len
)

Store buffer contents in DS1307 RAM.

Parameters:
addrStorage start location.
buffPoints to a buffer that contains the bytes to store.
lenNumber of valid bytes in the buffer.
Returns:
0 on success or -1 in case of an error.

Definition at line 199 of file ds1307rtc.c.

References CONST, free(), I2C_SLA_RTC, malloc(), memcpy(), NUT_WAIT_INFINITE, and TwMasterTransact().

Here is the call graph for this function:

int DS1307Init ( void  )

Initialize the interface to an Dallas DS1307 hardware clock.

Returns:
0 on success or -1 in case of an error.

Definition at line 228 of file ds1307rtc.c.

References DS1307RtcReadRegs(), DS1307RtcWrite(), and TwInit().

Here is the call graph for this function:


Variable Documentation

Initial value:
 {
    DS1307Init,
    DS1307RtcGetClock,
    DS1307RtcSetClock,
    NULL,
    NULL,
    NULL,
    NULL
}

Definition at line 252 of file ds1307rtc.c.
