FAT12/16/32 compatible file system. More...

Collaboration diagram for PHAT File System:

Data Structures
struct	_PHATFILE
	PHAT file descriptor structure. More...
Modules
	Volume Support
	Dealing with volumes.
	Directory Support
	Routines for reading and writing directories.
	PHAT12 Support
	PHAT12 specific routines.
	PHAT16 Support
	PHAT16 specific routines.
	PHAT32 Support
	PHAT32 specific routines.
	PHAT Block I/O
	Reading and writing data blocks.
	PHAT Utilities
	General utility routines used by the PHAT file system.
	PHAT Debugging Support
	Listing various PHAT structures.
Defines
#define	PHATEOC 0x0FFFFFF8
	Marks end of cluster chain.
Typedefs
typedef struct _PHATFILE	PHATFILE
	PHAT file descriptor structure.
Functions
uint32_t	AllocFirstCluster (NUTFILE *nfp)
	Allocate the first cluster of a file.
int	PhatFileClose (NUTFILE *nfp)
	Close a file.
NUTFILE *	PhatFileOpen (NUTDEVICE dev, CONST char path, int mode, int acc)
	Open a file.
int	PhatFileWrite (NUTFILE nfp, CONST void buffer, int len)
	Write data to a file.
int	PhatFileWrite_P (NUTFILE *nfp, PGM_P buffer, int len)
	Write data from program space to a file.
int	PhatFileRead (NUTFILE nfp, void buffer, int size)
	Read data from a file.
Variables
NUTDEVICE	devPhat0
	PHAT file system driver information structure.
NUTDEVICE	devPhat1
File attributes.
#define	PHAT_FATTR_RDONLY 0x01
#define	PHAT_FATTR_HIDDEN 0x02
#define	PHAT_FATTR_SYSTEM 0x04
#define	PHAT_FATTR_VOLID 0x08
#define	PHAT_FATTR_DIR 0x10
#define	PHAT_FATTR_ARCHIV 0x20
#define	PHAT_FATTR_LFN (PHAT_FATTR_RDONLY \| PHAT_FATTR_HIDDEN \| PHAT_FATTR_SYSTEM \| PHAT_FATTR_VOLID)
#define	PHAT_FATTR_FILEMASK 0x37

Detailed Description

FAT12/16/32 compatible file system.

Note:: This is alpha code and may contain severe bugs.

Define Documentation

#define PHATEOC 0x0FFFFFF8

Marks end of cluster chain.

Definition at line 123 of file phatfs.h.

Referenced by Phat12GetClusterLink(), Phat12ReleaseChain(), Phat16GetClusterLink(), Phat16ReleaseChain(), Phat32GetClusterLink(), Phat32ReleaseChain(), PhatFilePosSet(), PhatFileRead(), and PhatFileWrite().

#define PHAT_FATTR_RDONLY 0x01

Read only file.

Definition at line 131 of file phatfs.h.

Referenced by PhatDbgAttrList(), PhatDirReleaseChain(), and PhatFileWrite().

#define PHAT_FATTR_HIDDEN 0x02

Hidden file.

Definition at line 133 of file phatfs.h.

Referenced by PhatDbgAttrList().

#define PHAT_FATTR_SYSTEM 0x04

System file.

Definition at line 135 of file phatfs.h.

Referenced by PhatDbgAttrList().

#define PHAT_FATTR_VOLID 0x08

No file, but a volume label.

Definition at line 137 of file phatfs.h.

Referenced by PhatDbgAttrList().

#define PHAT_FATTR_DIR 0x10

File contains a subdirectory.

Definition at line 139 of file phatfs.h.

Referenced by PhatDbgAttrList(), PhatDirCreate(), PhatDirEntryStatus(), PhatDirOpen(), PhatDirRead(), PhatDirRemove(), PhatFilePosSet(), PhatFileRead(), and PhatFileWrite().

#define PHAT_FATTR_ARCHIV 0x20

File is not archived. This flag will be set when the file is created or modified.

Definition at line 143 of file phatfs.h.

Referenced by PhatDbgAttrList(), and PhatFileWrite().

#define PHAT_FATTR_LFN (PHAT_FATTR_RDONLY | PHAT_FATTR_HIDDEN | PHAT_FATTR_SYSTEM | PHAT_FATTR_VOLID)

Long filename entry.

Definition at line 146 of file phatfs.h.

#define PHAT_FATTR_FILEMASK 0x37

Only these flags are allowed for files and directories.

Definition at line 149 of file phatfs.h.

Referenced by PhatDirEntryStatus(), PhatDirOpen(), PhatDirRemove(), PhatDirRenameEntry(), and PhatFileOpen().

Typedef Documentation

typedef struct _PHATFILE PHATFILE

PHAT file descriptor structure.

Function Documentation

uint32_t AllocFirstCluster ( NUTFILE * nfp )

Allocate the first cluster of a file.

Parameters:

nfp	The file for which a cluster is allocated.

Returns:: Number of the allocated cluster, which is not lower than 2. Any value lower than 2 indicates an error.

Definition at line 224 of file phatfs.c.

References _NUTDEVICE::dev_dcb, _NUTFILE::nf_dev, _NUTFILE::nf_fcb, PHAT12CMASK, Phat12SetClusterLink(), PHAT16CMASK, Phat16SetClusterLink(), PHAT32CMASK, Phat32SetClusterLink(), _PHATVOL::vol_numfree, and _PHATVOL::vol_type.

Referenced by PhatDirCreate(), and PhatFileWrite().

Here is the call graph for this function:

int PhatFileClose ( NUTFILE * nfp )

Close a file.

Parameters:

nfp	File descriptor.

Returns:: 0 on success, -1 otherwise.

Definition at line 336 of file phatfs.c.

References EBADF, errno, free(), _NUTFILE::nf_fcb, NUTFILE_EOF, PhatDbgFileInfo(), and stdout.

Referenced by PhatDirCreate(), PhatDirDelEntry(), PhatDirEntryStatus(), PhatDirRemove(), PhatDirRenameEntry(), and PhatFileOpen().

Here is the call graph for this function:

NUTFILE* PhatFileOpen	(	NUTDEVICE *	dev,
		CONST char *	path,
		int	mode,
		int	acc
	)

Open a file.

This function is called by the low level open routine of the C runtime library, using the _NUTDEVICE::dev_open entry.

Parameters:

dev	Specifies the file system device.
path	Pathname of the file to open. If the last character is a slash, then a directory will be opened.
mode	Operation mode.
acc	File attribute.

Returns:: Pointer to a NUTFILE structure if successful or NUTFILE_EOF otherwise.

Bug:: Append mode not working as expected.

Definition at line 372 of file phatfs.c.

Referenced by PhatDirCreate(), and PhatDirRemove().

Here is the call graph for this function:

int PhatFileWrite	(	NUTFILE *	nfp,
		CONST void *	buffer,
		int	len
	)

Write data to a file.

Parameters:

nfp	Pointer to a NUTFILE structure, obtained by a previous call to PnutFileOpen().
buffer	Pointer to the data to be written. If zero, then the output buffer will be flushed.
len	Number of bytes to write.

Returns:: The number of bytes written. A return value of -1 indicates an error.

Definition at line 538 of file phatfs.c.

References AllocFirstCluster(), _PHATDIRENT::dent_adate, _PHATDIRENT::dent_attr, _PHATDIRENT::dent_fsize, _PHATDIRENT::dent_mdate, _PHATDIRENT::dent_mtime, _NUTDEVICE::dev_dcb, EACCES, ENOSPC, errno, _PHATFILE::f_clust, _PHATFILE::f_clust_pos, _PHATFILE::f_clust_prv, _PHATFILE::f_de_dirty, _PHATFILE::f_dirent, _PHATFILE::f_pos, _PHATFILE::f_sect_pos, GetDosTimeStamp(), IsFixedRootDir(), memcpy(), _NUTFILE::nf_dev, _NUTFILE::nf_fcb, PHAT12CMASK, Phat12GetClusterLink(), PHAT16CMASK, Phat16GetClusterLink(), PHAT32CMASK, Phat32GetClusterLink(), PHAT_FATTR_ARCHIV, PHAT_FATTR_DIR, PHAT_FATTR_RDONLY, PhatClusterSector(), PHATEOC, PhatSectorLoad(), _PHATSECTBUF::sect_data, _PHATSECTBUF::sect_dirty, _PHATVOL::vol_buf, _PHATVOL::vol_clustsz, _PHATVOL::vol_numfree, _PHATVOL::vol_rootsz, _PHATVOL::vol_sectsz, and _PHATVOL::vol_type.

Referenced by PhatDirCreate().

Here is the call graph for this function:

int PhatFileWrite_P	(	NUTFILE *	nfp,
		PGM_P	buffer,
		int	len
	)

Write data from program space to a file.

This function is not yet implemented and will always return -1.

Similar to PhatFileWrite() except that the data is located in program memory.

Parameters:

nfp	Pointer to a NUTFILE structure, obtained by a previous call to PnutFileOpen().
buffer	Pointer to the data in program space. If zero, then the output buffer will be flushed.
len	Number of bytes to write.

Returns:: The number of bytes written. A return value of -1 indicates an error.

Definition at line 706 of file phatfs.c.

int PhatFileRead	(	NUTFILE *	nfp,
		void *	buffer,
		int	size
	)

Read data from a file.

Parameters:

nfp	Pointer to a NUTFILE structure, obtained by a previous call to PnutFileOpen().
buffer	Pointer to the data buffer to fill.
size	Maximum number of bytes to read.

Returns:: The number of bytes actually read. A return value of -1 indicates an error.

Definition at line 723 of file phatfs.c.

References _PHATDIRENT::dent_attr, _PHATDIRENT::dent_fsize, _NUTDEVICE::dev_dcb, _PHATFILE::f_clust, _PHATFILE::f_clust_pos, _PHATFILE::f_clust_prv, _PHATFILE::f_dirent, _PHATFILE::f_pos, _PHATFILE::f_sect_pos, IsFixedRootDir(), memcpy(), _NUTFILE::nf_dev, _NUTFILE::nf_fcb, PHAT12CMASK, Phat12GetClusterLink(), PHAT16CMASK, Phat16GetClusterLink(), PHAT32CMASK, Phat32GetClusterLink(), PHAT_FATTR_DIR, PhatClusterSector(), PHATEOC, PhatSectorLoad(), _PHATSECTBUF::sect_data, _PHATVOL::vol_buf, _PHATVOL::vol_clustsz, _PHATVOL::vol_rootsz, _PHATVOL::vol_sectsz, and _PHATVOL::vol_type.

Referenced by PhatDirRemove().

Here is the call graph for this function:

Variable Documentation

NUTDEVICE devPhat0

Initial value:

 {
    0,
    {'P', 'H', 'A', 'T', '0', 0, 0, 0, 0}
    ,
    IFTYP_FS,
    0,
    0,
    0,
    0,
    PhatInit,
    PhatApiIOCtl,
    PhatApiFileRead,
    PhatApiFileWrite,

    PhatApiFileWrite_P,

    PhatApiFileOpen,
    PhatApiFileClose,
    PhatFileSize
}

PHAT file system driver information structure.

A pointer to this structure must be passed to NutRegisterDevice() to bind this file system driver to the Nut/OS kernel. An application may then call /verbatim _open("MMC0:1/PHAT0", _O_RDWR | _O_BINARY); /endverbatim to mount partition 1 on the previously registered block device (devMmc0 in this example).

Definition at line 1080 of file phatfs.c.

NUTDEVICE devPhat1

Initial value:

 {
    0,
    {'P', 'H', 'A', 'T', '1', 0, 0, 0, 0}
    ,
    IFTYP_FS,
    0,
    0,
    0,
    0,
    PhatInit,
    PhatApiIOCtl,
    PhatApiFileRead,
    PhatApiFileWrite,

    PhatApiFileWrite_P,

    PhatApiFileOpen,
    PhatApiFileClose,
    PhatFileSize
}

Definition at line 1101 of file phatfs.c.
