pppsm.c File Reference

#include <cfg/os.h>
#include <cfg/ppp.h>
#include <string.h>
#include <io.h>
#include <fcntl.h>
#include <dev/uart.h>
#include <sys/thread.h>
#include <sys/heap.h>
#include <sys/event.h>
#include <sys/timer.h>
#include <net/if_var.h>
#include <dev/ppp.h>
#include <netinet/if_ppp.h>
#include <netinet/ppp_fsm.h>
#include <net/netdebug.h>

Include dependency graph for pppsm.c:

Go to the source code of this file.

Defines
#define	NUT_THREAD_PPPSMSTACK   512
Functions
void	NutPppSm (void *arg)
	PPP state machine timeout thread.
int	NutPppInitStateMachine (NUTDEVICE *dev)
	Initialize the PPP state machine.
void	LcpOpen (NUTDEVICE *dev)
	Trigger LCP open event.
void	LcpClose (NUTDEVICE *dev)
	Trigger LCP close event.
void	LcpLowerUp (NUTDEVICE *dev)
	Trigger LCP lower up event.
void	LcpLowerDown (NUTDEVICE *dev)
	Trigger LCP lower down event.
void	IpcpOpen (NUTDEVICE *dev)
	Trigger IPCP open event.
void	IpcpClose (NUTDEVICE *dev)
	Trigger IPCP close event.
void	IpcpLowerUp (NUTDEVICE *dev)
void	IpcpLowerDown (NUTDEVICE *dev)
Variables
uint32_t	new_magic = 0x12345678

---

Define Documentation

#define NUT_THREAD_PPPSMSTACK   512

Definition at line 100 of file pppsm.c.

Referenced by NutPppInitStateMachine().
