at91sam7se.h File Reference
Include dependency graph for at91sam7se.h:

Go to the source code of this file.

Defines

#define FLASH_BASE   0x100000UL
#define RAM_BASE   0x200000UL
#define TC_BASE   0xFFFA0000
 Timer/counter base address.
#define UDP_BASE   0xFFFB0000
 USB device port base address.
#define TWI_BASE   0xFFFB8000
 Two-wire interface base address.
#define USART0_BASE   0xFFFC0000
 USART 0 base address.
#define USART1_BASE   0xFFFC4000
 USART 1 base address.
#define PWMC_BASE   0xFFFCC000
 PWM controller base address.
#define SSC_BASE   0xFFFD4000
 Serial synchronous controller base address.
#define ADC_BASE   0xFFFD8000
 ADC base address.
#define SPI0_BASE   0xFFFE0000
 SPI0 base address.
#define AIC_BASE   0xFFFFF000
 AIC base address.
#define DBGU_BASE   0xFFFFF200
 DBGU base address.
#define PIOA_BASE   0xFFFFF400
 PIO A base address.
#define PIOB_BASE   0xFFFFF600
 PIO B base address.
#define PIOC_BASE   0xFFFFF800
 PIO C base address.
#define PMC_BASE   0xFFFFFC00
 PMC base address.
#define RSTC_BASE   0xFFFFFD00
 Resect controller register base address.
#define RTT_BASE   0xFFFFFD20
 Realtime timer base address.
#define PIT_BASE   0xFFFFFD30
 Periodic interval timer base address.
#define WDT_BASE   0xFFFFFD40
 Watch Dog register base address.
#define VREG_BASE   0xFFFFFD60
 Voltage regulator mode controller base address.
#define MC_BASE   0xFFFFFF00
 Memory controller base address.
#define EFC0_BASE   0xFFFFFF60
 EFC0 base address.
#define EFC1_BASE   0xFFFFFF70
 EFC1 base address.
#define EBI_BASE   0xFFFFFF80
 External bus interface base address.
#define SMC_BASE   0xFFFFFF90
 SMC base address.
#define SDRAMC_BASE   0xFFFFFFB0
 SDRAMC base address.
#define ECC_BASE   0xFFFFFFDC
 ECC base address.
#define PERIPH_RPR_OFF   0x00000100
 Receive pointer register offset.
#define PERIPH_RCR_OFF   0x00000104
 Receive counter register offset.
#define PERIPH_TPR_OFF   0x00000108
 Transmit pointer register offset.
#define PERIPH_TCR_OFF   0x0000010C
 Transmit counter register offset.
#define PERIPH_RNPR_OFF   0x00000110
 Receive next pointer register offset.
#define PERIPH_RNCR_OFF   0x00000114
 Receive next counter register offset.
#define PERIPH_TNPR_OFF   0x00000118
 Transmit next pointer register offset.
#define PERIPH_TNCR_OFF   0x0000011C
 Transmit next counter register offset.
#define PERIPH_PTCR_OFF   0x00000120
 PDC transfer control register offset.
#define PERIPH_PTSR_OFF   0x00000124
 PDC transfer status register offset.
#define PDC_RXTEN   0x00000001
 Receiver transfer enable.
#define PDC_RXTDIS   0x00000002
 Receiver transfer disable.
#define PDC_TXTEN   0x00000100
 Transmitter transfer enable.
#define PDC_TXTDIS   0x00000200
 Transmitter transfer disable.
#define EBI_HAS_CSA
#define SMC_HAS_CSR
#define DBGU_HAS_PDC
#define SPI_HAS_PDC
#define SSC_HAS_PDC
#define USART_HAS_PDC
#define USART_HAS_MODE
#define PIO_HAS_MULTIDRIVER
#define PIO_HAS_PULLUP
#define PIO_HAS_PERIPHERALSELECT
#define PIO_HAS_OUTPUTWRITEENABLE

Peripheral Identifiers and Interrupts

#define FIQ_ID   0
 Fast interrupt ID.
#define SYSC_ID   1
 System interrupt ID.
#define PIOA_ID   2
 Parallel I/O controller A ID.
#define PIOB_ID   3
 Parallel I/O controller B ID.
#define PIOC_ID   4
 Parallel I/O controller C ID.
#define SPI0_ID   5
 Serial peripheral interface 0 ID.
#define US0_ID   6
 USART 0 ID.
#define US1_ID   7
 USART 1 ID.
#define SSC_ID   8
 Synchronous serial controller ID.
#define TWI_ID   9
 Two-wire interface ID.
#define PWMC_ID   10
 PWM controller ID.
#define UDP_ID   11
 USB device port ID.
#define TC0_ID   12
 Timer 0 ID.
#define TC1_ID   13
 Timer 1 ID.
#define TC2_ID   14
 Timer 2 ID.
#define ADC_ID   15
 Analog to digital converter ID.
#define IRQ0_ID   29
 External interrupt 0 ID.
#define IRQ1_ID   30
 External interrupt 1 ID.

Historical SPI0 Peripheral Multiplexing Names

#define SPI0_NPCS0_PA11A   11
 Port bit number on PIO-A Perpheral A.
#define SPI0_NPCS1_PA09B   9
 Port bit number on PIO-A Perpheral B.
#define SPI0_NPCS1_PA31A   31
 Port bit number on PIO-A Perpheral A.
#define SPI0_NPCS2_PA10B   10
 Port bit number on PIO-A Perpheral B.
#define SPI0_NPCS2_PA30B   30
 Port bit number on PIO-A Perpheral B.
#define SPI0_NPCS3_PA03B   3
 Port bit number on PIO-A Perpheral B.
#define SPI0_NPCS3_PA05B   5
 Port bit number on PIO-A Perpheral B.
#define SPI0_NPCS3_PA22B   22
 Port bit number on PIO-A Perpheral B.
#define SPI0_MISO_PA12A   12
 Port bit number on PIO-A Perpheral A.
#define SPI0_MOSI_PA13A   13
 Port bit number on PIO-A Perpheral A.
#define SPI0_SPCK_PA14A   14
 Port bit number on PIO-A Perpheral A.

USART Peripheral Multiplexing

#define PA5_RXD0_A   5
#define PA6_TXD0_A   6
#define PB2_SCK0_A   2
#define PA7_RTS0_A   7
#define PA8_CTS0_A   8
#define PA21_RXD1_A   21
#define PA22_TXD1_A   22
#define PA23_SCK1_A   23
#define PA24_RTS1_A   24
#define PC8_RTS1_B   8
#define PA25_CTS1_A   25
#define PA26_DCD1_A   26
#define PA27_DTR1_A   27
#define PC9_DTR1_B   9
#define PA28_DSR1_A   28
#define PA29_RI1_A   29

SPI Peripheral Multiplexing

#define PA12_SPI0_MISO_A   12
#define PA13_SPI0_MOSI_A   13
#define PA14_SPI0_SPCK_A   14
#define PA11_SPI0_NPCS0_A   11
#define PA31_SPI0_NPCS1_A   31
#define PB9_SPI0_NPCS1_A   9
#define PB10_SPI0_NPCS2_A   10
#define PC14_SPI0_NPCS1_B   14
#define PB30_SPI0_NPCS2_A   30
#define PB3_SPI0_NPCS3_A   3
#define PB5_SPI0_NPCS3_A   5
#define PB22_SPI0_NPCS3_A   22
#define SPI0_PINS   _BV(PA12_SPI0_MISO_A) | _BV(PA13_SPI0_MOSI_A) | _BV(PA14_SPI0_SPCK_A)
#define SPI0_PIO_BASE   PIOA_BASE
#define SPI0_PSR_OFF   PIO_ASR_OFF
#define SPI0_CS0_PIN   _BV(PA11_SPI0_NPCS0_A)
#define SPI0_CS0_PIO_BASE   PIOA_BASE
#define SPI0_CS0_PSR_OFF   PIO_ASR_OFF
#define SPI0_CS1_PIN   _BV(PA31_SPI0_NPCS1_A)
#define SPI0_CS1_PIO_BASE   PIOA_BASE
#define SPI0_CS1_PSR_OFF   PIO_ASR_OFF

External Bus Interface Multiplexing

#define PA0_A0_B   0
#define PB0_A0_B   0
#define PA1_A1_B   1
#define PB1_A1_B   1
#define PA2_A2_B   2
#define PB2_A2_B   2
#define PA3_A3_B   3
#define PB3_A3_B   3
#define PA4_A4_B   4
#define PB4_A4_B   4
#define PA5_A5_B   5
#define PB5_A5_B   5
#define PA6_A6_B   6
#define PB6_A6_B   6
#define PA7_A7_B   7
#define PB7_A7_B   7
#define PA8_A8_B   8
#define PB8_A8_B   8
#define PA9_A9_B   9
#define PB9_A9_B   9
#define PA10_A10_B   10
#define PB10_A10_B   10
#define PA11_A11_B   11
#define PB11_A11_B   11
#define PA12_A12_B   12
#define PB12_A12_B   12
#define PA13_A13_B   13
#define PB13_A13_B   13
#define PA14_A14_B   14
#define PB14_A14_B   14
#define PA15_A15_B   15
#define PB15_A15_B   15
#define PA16_A16_B   16
#define PB16_A16_B   16
#define PA17_A17_B   17
#define PB17_A17_B   17
#define PC16_A18_A   16
#define PC17_A19_A   17
#define PC18_A20_A   18
#define PC19_A21_A   19
#define PC20_A22_A   20
#define PC0_D0_A   0
#define PC1_D1_A   1
#define PC2_D2_A   2
#define PC3_D3_A   3
#define PC4_D4_A   4
#define PC5_D5_A   5
#define PC6_D6_A   6
#define PC7_D7_A   7
#define PC8_D8_A   8
#define PC9_D9_A   9
#define PC10_D10_A   10
#define PC11_D11_A   11
#define PC12_D12_A   12
#define PC13_D13_A   13
#define PC14_D14_A   14
#define PC15_D15_A   15
#define PB18_D16_B   18
#define PB19_D17_B   19
#define PB20_D18_B   20
#define PB21_D19_B   21
#define PB22_D20_B   22
#define PB23_D21_B   23
#define PB24_D22_B   24
#define PB25_D23_B   25
#define PB26_D24_B   26
#define PB27_D25_B   27
#define PB28_D26_B   28
#define PB29_D27_B   29
#define PB30_D28_B   30
#define PB31_D29_B   31
#define PA30_D30_B   30
#define PA31_D31_B   31
#define PA19_NCS4_B   19
#define PA20_NCS2_B   20
#define PA21_NCS6_B   21
#define PA22_NCS5_B   22
#define PA26_NCS1_B   26
#define PC15_NCS3_B   15
#define PC20_NCS7_B   20
#define PC23_NCS0_B   23
#define PA18_NBS3_B   18
#define PA23_NWR1_B   23
#define PA24_SDA10_B   24
#define PA25_SDCKE_B   25
#define PA27_SDWE_B   27
#define PA28_CAS_B   28
#define PA29_RAS_B   29
#define PC16_NWAIT_B   16
#define PC17_NANDOE_B   17
#define PC18_NANDWE_B   18
#define PC21_NWR0_B   21
#define PC22_NRD_B   22
#define PC23_CFRNW_A   23

Debug Unit Peripheral Multiplexing

#define PA9_DRXD_A   9
#define PA10_DTXD_A   10

Synchronous Serial Controller Peripheral Multiplexing

#define PA17_TD_A   17
 Transmit data pin.
#define PA18_RD_A   18
 Receive data pin.
#define PA16_TK_A   16
 Transmit clock pin.
#define PA19_RK_A   19
 Receive clock pin.
#define PA15_TF_A   15
 Transmit frame sync. pin.
#define PA20_RF_A   20
 Receive frame sync. pin.

Two Wire Interface Peripheral Multiplexing

#define PA3_TWD_A   3
 Two wire serial data pin.
#define PA4_TWCK_A   4
 Two wire serial clock pin.

Timer/Counter Peripheral Multiplexing

#define PB0_TIOA0_A   0
#define PB1_TIOB0_A   1
#define PB4_TCLK0_A   4
#define PB15_TIOA1_A   15
#define PB16_TIOB1_A   16
#define PB28_TCLK1_A   28
#define PB26_TIOA2_A   26
#define PB27_TIOB2_A   27
#define PB29_TCLK2_A   29

Clocks, Oscillators and PLLs Peripheral Multiplexing

#define PB6_PCK0_A   6
#define PC10_PCK0_B   10
#define PB17_PCK1_A   17
#define PB21_PCK1_A   21
#define PC11_PCK1_B   11
#define PB18_PCK2_A   18
#define PB31_PCK2_A   31
#define PC12_PCK2_B   12

Advanced Interrupt Controller Peripheral Multiplexing

#define PB19_FIQ_A   19
#define PB20_IRQ0_A   20
#define PA30_IRQ1_A   30

ADC Interface Peripheral Multiplexing

#define PB8_ADTRG_A   8
 ADC trigger pin.

PWM Peripheral Multiplexing

#define PA0_PWM0_A   0
#define PB11_PWM0_A   11
#define PB23_PWM0_A   23
#define PA1_PWM1_A   1
#define PB12_PWM1_A   12
#define PB24_PWM1_A   24
#define PA2_PWM2_A   2
#define PB13_PWM2_A   13
#define PB25_PWM2_A   25
#define PB7_PWM3_A   7
#define PB14_PWM3_A   14

Define Documentation

#define FLASH_BASE   0x100000UL

Definition at line 44 of file at91sam7se.h.

#define RAM_BASE   0x200000UL

Definition at line 45 of file at91sam7se.h.

#define TC_BASE   0xFFFA0000

Timer/counter base address.

Definition at line 47 of file at91sam7se.h.

#define UDP_BASE   0xFFFB0000

USB device port base address.

Definition at line 48 of file at91sam7se.h.

#define TWI_BASE   0xFFFB8000

Two-wire interface base address.

Definition at line 49 of file at91sam7se.h.

#define USART0_BASE   0xFFFC0000

USART 0 base address.

Definition at line 50 of file at91sam7se.h.

#define USART1_BASE   0xFFFC4000

USART 1 base address.

Definition at line 51 of file at91sam7se.h.

#define PWMC_BASE   0xFFFCC000

PWM controller base address.

Definition at line 52 of file at91sam7se.h.

#define SSC_BASE   0xFFFD4000

Serial synchronous controller base address.

Definition at line 53 of file at91sam7se.h.

#define ADC_BASE   0xFFFD8000

ADC base address.

Definition at line 54 of file at91sam7se.h.

#define SPI0_BASE   0xFFFE0000

SPI0 base address.

Definition at line 55 of file at91sam7se.h.

#define AIC_BASE   0xFFFFF000

AIC base address.

Definition at line 57 of file at91sam7se.h.

#define DBGU_BASE   0xFFFFF200

DBGU base address.

Definition at line 58 of file at91sam7se.h.

#define PIOA_BASE   0xFFFFF400

PIO A base address.

Definition at line 59 of file at91sam7se.h.

#define PIOB_BASE   0xFFFFF600

PIO B base address.

Definition at line 60 of file at91sam7se.h.

#define PIOC_BASE   0xFFFFF800

PIO C base address.

Definition at line 61 of file at91sam7se.h.

#define PMC_BASE   0xFFFFFC00

PMC base address.

Definition at line 62 of file at91sam7se.h.

#define RSTC_BASE   0xFFFFFD00

Resect controller register base address.

Definition at line 63 of file at91sam7se.h.

#define RTT_BASE   0xFFFFFD20

Realtime timer base address.

Definition at line 64 of file at91sam7se.h.

#define PIT_BASE   0xFFFFFD30

Periodic interval timer base address.

Definition at line 65 of file at91sam7se.h.

#define WDT_BASE   0xFFFFFD40

Watch Dog register base address.

Definition at line 66 of file at91sam7se.h.

#define VREG_BASE   0xFFFFFD60

Voltage regulator mode controller base address.

Definition at line 67 of file at91sam7se.h.

#define MC_BASE   0xFFFFFF00

Memory controller base address.

Definition at line 68 of file at91sam7se.h.

#define EFC0_BASE   0xFFFFFF60

EFC0 base address.

Definition at line 69 of file at91sam7se.h.

#define EFC1_BASE   0xFFFFFF70

EFC1 base address.

Definition at line 70 of file at91sam7se.h.

#define EBI_BASE   0xFFFFFF80

External bus interface base address.

Definition at line 71 of file at91sam7se.h.

#define SMC_BASE   0xFFFFFF90

SMC base address.

Definition at line 72 of file at91sam7se.h.

#define SDRAMC_BASE   0xFFFFFFB0

SDRAMC base address.

Definition at line 73 of file at91sam7se.h.

#define ECC_BASE   0xFFFFFFDC

ECC base address.

Definition at line 74 of file at91sam7se.h.

#define PERIPH_RPR_OFF   0x00000100

Receive pointer register offset.

Definition at line 76 of file at91sam7se.h.

#define PERIPH_RCR_OFF   0x00000104

Receive counter register offset.

Definition at line 77 of file at91sam7se.h.

#define PERIPH_TPR_OFF   0x00000108

Transmit pointer register offset.

Definition at line 78 of file at91sam7se.h.

#define PERIPH_TCR_OFF   0x0000010C

Transmit counter register offset.

Definition at line 79 of file at91sam7se.h.

#define PERIPH_RNPR_OFF   0x00000110

Receive next pointer register offset.

Definition at line 80 of file at91sam7se.h.

#define PERIPH_RNCR_OFF   0x00000114

Receive next counter register offset.

Definition at line 81 of file at91sam7se.h.

#define PERIPH_TNPR_OFF   0x00000118

Transmit next pointer register offset.

Definition at line 82 of file at91sam7se.h.

#define PERIPH_TNCR_OFF   0x0000011C

Transmit next counter register offset.

Definition at line 83 of file at91sam7se.h.

#define PERIPH_PTCR_OFF   0x00000120

PDC transfer control register offset.

Definition at line 84 of file at91sam7se.h.

#define PERIPH_PTSR_OFF   0x00000124

PDC transfer status register offset.

Definition at line 85 of file at91sam7se.h.

#define PDC_RXTEN   0x00000001

Receiver transfer enable.

Definition at line 87 of file at91sam7se.h.

#define PDC_RXTDIS   0x00000002

Receiver transfer disable.

Definition at line 88 of file at91sam7se.h.

#define PDC_TXTEN   0x00000100

Transmitter transfer enable.

Definition at line 89 of file at91sam7se.h.

#define PDC_TXTDIS   0x00000200

Transmitter transfer disable.

Definition at line 90 of file at91sam7se.h.

#define EBI_HAS_CSA

Definition at line 92 of file at91sam7se.h.

#define SMC_HAS_CSR

Definition at line 93 of file at91sam7se.h.

#define DBGU_HAS_PDC

Definition at line 95 of file at91sam7se.h.

#define SPI_HAS_PDC

Definition at line 96 of file at91sam7se.h.

#define SSC_HAS_PDC

Definition at line 97 of file at91sam7se.h.

#define USART_HAS_PDC

Definition at line 98 of file at91sam7se.h.

#define USART_HAS_MODE

Definition at line 99 of file at91sam7se.h.

#define PIO_HAS_MULTIDRIVER

Definition at line 101 of file at91sam7se.h.

#define PIO_HAS_PULLUP

Definition at line 102 of file at91sam7se.h.

#define PIO_HAS_PERIPHERALSELECT

Definition at line 103 of file at91sam7se.h.

#define PIO_HAS_OUTPUTWRITEENABLE

Definition at line 104 of file at91sam7se.h.
