#include <arch/arm/v5te.h>
#include <arch/arm/atmel/at91_rtc.h>
#include <arch/arm/atmel/at91_ecc.h>
#include <arch/arm/atmel/at91_ebi.h>
#include <arch/arm/atmel/at91_tc.h>
#include <arch/arm/atmel/at91_us.h>
#include <arch/arm/atmel/at91_dbgu.h>
#include <arch/arm/atmel/at91_emac.h>
#include <arch/arm/atmel/at91_spi.h>
#include <arch/arm/atmel/at91_aic.h>
#include <arch/arm/atmel/at91_pio.h>
#include <arch/arm/atmel/at91_pmc.h>
#include <arch/arm/atmel/at91_rstc.h>
#include <arch/arm/atmel/at91_wdt.h>
#include <arch/arm/atmel/at91_ssc.h>
#include <arch/arm/atmel/at91_twi.h>
#include <arch/arm/atmel/at91_smc.h>
#include <arch/arm/atmel/at91_mci.h>
#include <arch/arm/atmel/at91_matrix.h>
#include <arch/arm/atmel/at91_ccfg.h>
#include <arch/arm/atmel/at91_sdramc.h>
#include <arch/arm/atmel/at91_adc.h>
#include <arch/arm/atmel/at91_pit.h>
#include <arch/arm/atmel/at91_lcdc.h>
#include <arch/arm/atmel/at91_tsadcc.h>
Go to the source code of this file.
Defines | |
#define | FLASH_BASE 0x100000UL |
#define | RAM_BASE 0x200000UL |
#define | NAND_FLASH_BASE 0x40000000 |
#define | LCDC_BASE 0x00500000 |
USB device port base address. | |
#define | UDP_BASE 0xFFF78000 |
USB device port base address. | |
#define | TC_BASE 0xFFF7C000 |
Timer/counter base address. (TC0-TC2) | |
#define | MCI_BASE 0xFFF80000 |
MMC/SDCard interface base address. (MCI0) | |
#define | TWI_BASE 0xFFF84000 |
Two-wire interface base address. (TWI0-TWI1) | |
#define | USART0_BASE 0xFFF8C000 |
USART 0 base address. | |
#define | USART1_BASE 0xFFF90000 |
USART 1 base address. | |
#define | USART2_BASE 0xFFF94000 |
USART 2 base address. | |
#define | USART3_BASE 0xFFF98000 |
USART 2 base address. | |
#define | SSC_BASE 0xFFF9C000 |
Serial synchronous controller base address. (SSC0-SSC1) | |
#define | SPI0_BASE 0xFFFA4000 |
SPI0 0 base address. | |
#define | SPI1_BASE 0xFFFA8000 |
SPI0 1 base address. | |
#define | AC97_BASE 0xFFFAC000 |
AC97 Codec interface. | |
#define | TSADCC_BASE 0xFFFB0000 |
Touch screen ADC controller. | |
#define | ISI_BASE 0xFFFB4000 |
Image sensor interface base address. | |
#define | PWMC_BASE 0xFFFB8000 |
PWM controller base address. | |
#define | EMAC_BASE 0xFFFBC000 |
EMAC base address. | |
#define | TRNG_BASE 0xFFFCC000 |
True random number generator. | |
#define | MCI1_BASE 0xFFFD0000 |
MMC/SDCard interface base address. (MCI1) | |
#define | TC345_BASE 0xFFFD4000 |
Timer/counter base address. (TC3-TC5) | |
#define | DDRSDRC1_BASE 0xFFFFE400 |
DDRSDRC1 base address. | |
#define | DDRSDRC0_BASE 0xFFFFE600 |
DDRSDRC0 base address. | |
#define | SMC_BASE 0xFFFFE800 |
SMC base address. | |
#define | MATRIX_BASE 0xFFFFEA00 |
MATRIX base address. | |
#define | DMAC_BASE 0xFFFFEC00 |
DMA controller base address. | |
#define | DBGU_BASE 0xFFFFEE00 |
DBGU base address. | |
#define | AIC_BASE 0xFFFFF000 |
AIC base address. | |
#define | PIOA_BASE 0xFFFFF200 |
PIO A base address. | |
#define | PIOB_BASE 0xFFFFF400 |
PIO B base address. | |
#define | PIOC_BASE 0xFFFFF600 |
PIO C base address. | |
#define | PIOD_BASE 0xFFFFF800 |
PIO D base address. | |
#define | PIOE_BASE 0xFFFFFA00 |
PIO E base address. | |
#define | PMC_BASE 0xFFFFFC00 |
PMC base address. | |
#define | RSTC_BASE 0xFFFFFD00 |
Resect controller register base address. | |
#define | SHDWC_BASE 0xFFFFFD10 |
Shutdown controller. | |
#define | RTT_BASE 0xFFFFFD20 |
Realtime timer base address. | |
#define | PIT_BASE 0xFFFFFD30 |
Periodic interval timer base address. | |
#define | WDT_BASE 0xFFFFFD40 |
Watch Dog register base address. | |
#define | SCKCR_BASE 0xFFFFFD50 |
Slow clock control register. | |
#define | GPBR_BASE 0xFFFFFD60 |
General purpose backup registers. | |
#define | RTC_BASE 0xFFFFFDB0 |
RTC. | |
#define | ECC_BASE 0xFFFFE200 |
ECC base address. | |
#define | PERIPH_RPR_OFF 0x00000100 |
Receive pointer register offset. | |
#define | PERIPH_RCR_OFF 0x00000104 |
Receive counter register offset. | |
#define | PERIPH_TPR_OFF 0x00000108 |
Transmit pointer register offset. | |
#define | PERIPH_TCR_OFF 0x0000010C |
Transmit counter register offset. | |
#define | PERIPH_RNPR_OFF 0x00000110 |
Receive next pointer register offset. | |
#define | PERIPH_RNCR_OFF 0x00000114 |
Receive next counter register offset. | |
#define | PERIPH_TNPR_OFF 0x00000118 |
Transmit next pointer register offset. | |
#define | PERIPH_TNCR_OFF 0x0000011C |
Transmit next counter register offset. | |
#define | PERIPH_PTCR_OFF 0x00000120 |
PDC transfer control register offset. | |
#define | PERIPH_PTSR_OFF 0x00000124 |
PDC transfer status register offset. | |
#define | PDC_RXTEN 0x00000001 |
Receiver transfer enable. | |
#define | PDC_RXTDIS 0x00000002 |
Receiver transfer disable. | |
#define | PDC_TXTEN 0x00000100 |
Transmitter transfer enable. | |
#define | PDC_TXTDIS 0x00000200 |
Transmitter transfer disable. | |
#define | DBGU_HAS_PDC |
#define | SPI_HAS_PDC |
#define | SSC_HAS_PDC |
#define | USART_HAS_PDC |
#define | USART_HAS_MODE |
#define | MCI_HAS_PDC |
#define | PMC_HAS_PLLB |
#define | PMC_HAS_MDIV |
#define | EBI_HAS_CSA |
#define | PIO_HAS_MULTIDRIVER |
#define | PIO_HAS_PULLUP |
#define | PIO_HAS_PERIPHERALSELECT |
#define | PIO_HAS_OUTPUTWRITEENABLE |
Peripheral Identifiers and Interrupts | |
#define | FIQ_ID 0 |
Fast interrupt. | |
#define | SYSC_ID 1 |
System interrupt. | |
#define | PIOA_ID 2 |
Parallel I/O controller A. | |
#define | PIOB_ID 3 |
Parallel I/O controller B. | |
#define | PIOC_ID 4 |
Parallel I/O controller C. | |
#define | PIODE_ID 5 |
Parallel I/O controller C. | |
#define | RNG_ID 6 |
Analog to digital converter. | |
#define | US0_ID 7 |
USART 0. | |
#define | US1_ID 8 |
USART 1. | |
#define | US2_ID 9 |
USART 2. | |
#define | US3_ID 10 |
USART 3. | |
#define | MCI0_ID 11 |
MMC interface. | |
#define | TWI0_ID 12 |
Two wire interface. | |
#define | TWI1_ID 13 |
Two wire interface. | |
#define | SPI0_ID 14 |
Serial peripheral 0. | |
#define | SPI1_ID 15 |
Serial peripheral 1. | |
#define | SSC0_ID 16 |
Serial peripheral interface. | |
#define | SSC1_ID 17 |
Serial peripheral interface. | |
#define | TC0_ID 18 |
Timer/counter 0. | |
#define | TC1_ID 18 |
Timer/counter 1. | |
#define | TC2_ID 18 |
Timer/counter 2. | |
#define | TC3_ID 18 |
Timer/counter 3. | |
#define | TC4_ID 18 |
Timer/counter 4. | |
#define | TC5_ID 18 |
Timer/counter 5. | |
#define | PWMC_ID 19 |
Pulse Width Modulation Controller. | |
#define | TSADCC_ID 20 |
Touch Screen ADC Controller. | |
#define | DMA_ID 21 |
DMA Controller. | |
#define | UHP_ID 22 |
USB host port. | |
#define | LCDC_ID 23 |
LCD controller. | |
#define | AC97_ID 24 |
AC97 controller. | |
#define | EMAC_ID 25 |
Ethernet MAC. | |
#define | ISI_ID 26 |
Image sensor interface. | |
#define | UDP_ID 27 |
USB device port. | |
#define | MCI1_ID 29 |
MMC interface. | |
#define | IRQ0_ID 31 |
External interrupt 0. | |
#define | TWI_ID TWI0_ID |
Two wire interface. | |
#define | MCI_ID MCI0_ID |
MMC interface. | |
#define | SSC_ID SSC0_ID |
Serial peripheral interface. | |
USART Peripheral Multiplexing | |
#define | PB16_SCK0_B 16 |
Channel 0 serial clock pin. | |
#define | PB19_TXD0_A 19 |
Channel 0 transmit data pin. | |
#define | PB18_RXD0_A 18 |
Channel 0 receive data pin. | |
#define | PB15_CTS0_B 15 |
Channel 0 clear to send pin. | |
#define | PB17_RTS0_B 17 |
Channel 0 request to send pin. | |
#define | PD29_SCK1_B 29 |
Channel 1 serial clock pin. | |
#define | PB4_TXD1_A 4 |
Channel 1 transmit data pin. | |
#define | PB5_RXD1_A 5 |
Channel 1 receive data pin. | |
#define | PD17_CTS1_A 17 |
Channel 1 clear to send pin. | |
#define | PD16_RTS1_A 16 |
Channel 1 request to send pin. | |
#define | PD30_SCK2_B 30 |
Channel 2 serial clock pin. | |
#define | PB6_TXD2_A 6 |
Channel 2 transmit data pin. | |
#define | PB7_RXD2_A 7 |
Channel 2 receive data pin. | |
#define | PC11_CTS2_B 11 |
Channel 2 clear to send pin. | |
#define | PC9_RTS2_B 9 |
Channel 2 request to send pin. | |
#define | PA22_SCK3_B 22 |
Channel 3 serial clock pin. | |
#define | PB8_TXD3_A 8 |
Channel 3 transmit data pin. | |
#define | PB9_RXD3_A 9 |
Channel 3 receive data pin. | |
#define | PA24_CTS3_B 24 |
Channel 3 clear to send pin. | |
#define | PA23_RTS3_B 23 |
Channel 3 request to send pin. | |
SPI Peripheral Multiplexing | |
#define | PB0_SPI0_MISO_A 0 |
Channel 0 master input slave output pin. | |
#define | PB1_SPI0_MOSI_A 1 |
Channel 0 master output slave input pin. | |
#define | PB2_SPI0_SPCK_A 2 |
Channel 0 serial clock pin. | |
#define | PB3_SPI0_NPCS0_A 3 |
Channel 0 chip select 0 pin. | |
#define | PB18_SPI0_NPCS1_B 18 |
Channel 0 chip select 1 pin. | |
#define | PD24_SPI0_NPCS1_A 24 |
Channel 0 chip select 1 pin. | |
#define | PB19_SPI0_NPCS2_B 19 |
Channel 0 chip select 2 pin. | |
#define | PD25_SPI0_NPCS2_A 25 |
Channel 0 chip select 1 pin. | |
#define | PD27_SPI0_NPCS3_B 27 |
Channel 0 chip select 3 pin. | |
#define | SPI0_PINS _BV(PB0_SPI0_MISO_A) | _BV(PB1_SPI0_MOSI_A) | _BV(PB2_SPI0_SPCK_A) |
#define | SPI0_PIO_BASE PIOA_BASE |
#define | SPI0_PSR_OFF PIO_ASR_OFF |
#define | SPI0_CS0_PIN _BV(PB3_SPI0_NPCS0_A) |
#define | SPI0_CS0_PIO_BASE PIOB_BASE |
#define | SPI0_CS0_PSR_OFF PIO_ASR_OFF |
#define | SPI0_CS1_PIN _BV(PB18_SPI0_NPCS1_B) |
#define | SPI0_CS1_PIO_BASE PIOB_BASE |
#define | SPI0_CS1_PSR_OFF PIO_BSR_OFF |
#define | PB14_SPI1_MISO_A 14 |
Channel 1 master input slave output pin. | |
#define | PB15_SPI1_MOSI_A 15 |
Channel 1 master output slave input pin. | |
#define | PB16_SPI1_SPCK_A 16 |
Channel 1 serial clock pin. | |
#define | PB17_SPI1_NPCS0_A 17 |
Channel 1 chip select 0 pin. | |
#define | PD28_SPI1_NPCS1_B 28 |
Channel 1 chip select 1 pin. | |
#define | PD18_SPI1_NPCS2_A 18 |
Channel 1 chip select 2 pin. | |
#define | PD19_SPI1_NPCS3_A 19 |
Channel 1 chip select 3 pin. | |
#define | SPI1_PINS _BV(PB14_SPI1_MISO_A) | _BV(PB15_SPI1_MOSI_A) | _BV(PB16_SPI1_SPCK_A) |
#define | SPI1_PIO_BASE PIOB_BASE |
#define | SPI1_PSR_OFF PIO_ASR_OFF |
#define | SPI1_CS0_PIN _BV(PB17_SPI1_NPCS0_A) |
#define | SPI1_CS0_PIO_BASE PIOB_BASE |
#define | SPI1_CS0_PSR_OFF PIO_ASR_OFF |
#define | SPI1_CS3_PIN _BV(PD19_SPI1_NPCS3_A) |
#define | SPI1_CS3_PIO_BASE PIOD_BASE |
#define | SPI1_CS3_PSR_OFF PIO_ASR_OFF |
Image Sensor Interface Peripheral Multiplexing | |
#define | PB20_ISI_D0_A 20 |
Image sensor data bit 0 pin. | |
#define | PB21_ISI_D1_A 21 |
Image sensor data bit 1 pin. | |
#define | PB22_ISI_D2_A 22 |
Image sensor data bit 2 pin. | |
#define | PB23_ISI_D3_A 23 |
Image sensor data bit 3 pin. | |
#define | PB24_ISI_D4_A 24 |
Image sensor data bit 4 pin. | |
#define | PB25_ISI_D5_A 25 |
Image sensor data bit 5 pin. | |
#define | PB26_ISI_D6_A 26 |
Image sensor data bit 6 pin. | |
#define | PB27_ISI_D7_A 27 |
Image sensor data bit 7 pin. | |
#define | PB10_ISI_D8_B 10 |
Image sensor data bit 8 pin. | |
#define | PB11_ISI_D9_B 11 |
Image sensor data bit 9 pin. | |
#define | PB12_ISI_D10_B 12 |
Image sensor data bit 10 pin. | |
#define | PB13_ISI_D11_B 13 |
Image sensor data bit 11 pin. | |
#define | PB28_ISI_PCK_A 28 |
Image sensor data clock pin. | |
#define | PB29_ISI_VSYNC_A 29 |
Image sensor vertical sync pin. | |
#define | PB30_ISI_HSYNC_A 30 |
Image sensor horizontal sync pin. | |
#define | PB31_ISI_MCK_A 31 |
Image sensor reference clock pin. | |
EMAC Interface Peripheral Multiplexing | |
#define | PA6_ETX2_B 6 |
Transmit data bit 2 pin. | |
#define | PA7_ETX3_B 7 |
Transmit data bit 3 pin. | |
#define | PA10_ETX0_A 10 |
Transmit data bit 0 pin. | |
#define | PA11_ETX1_A 11 |
Transmit data bit 1 pin. | |
#define | PA12_ERX0_A 12 |
Receive data bit 0 pin. | |
#define | PA13_ERX1_A 13 |
Receive data bit 1 pin. | |
#define | PA14_ETXEN_A 14 |
Transmit enable pin. | |
#define | PA15_ERXDV_A 15 |
Data valid pin. | |
#define | PA16_ERXER_A 16 |
Receive error pin. | |
#define | PA17_ETXCK_A 17 |
Transmit clock pin. | |
#define | PA18_EMDC_A 18 |
Management data clock pin. | |
#define | PA19_EMDIO_A 19 |
Management data I/O pin. | |
#define | PA27_ETXER_B 27 |
Transmit error pin. | |
#define | PA8_ERX2_B 8 |
Receive data bit 2 pin. | |
#define | PA9_ERX3_B 9 |
Receive data bit 3 pin. | |
#define | PA28_ERXCK_B 28 |
Receive clock pin. | |
#define | PA29_ECRS_B 29 |
Carrier sense pin. | |
#define | PA30_ECOL_B 30 |
Collision detect pin. | |
AT91SAM9G45-EKES-Specific LAN defintitions | |
#define | PHY_MODE_RMII |
#define | EMAC_PIO_ASR PIO_ASR_OFF |
#define | PHY_MII_PINS_A |
#define | EMAC_PIO_BSR PIO_BSR_OFF |
#define | PHY_MII_PINS_B (PA6_ETX2_B | PA7_ETX3_B | PA27_ETXER_B | PA8_ERX2_B | PA9_ERX3_B | PA28_ERXCK_B | PA29_ECRS_B | PA30_ECOL_B) |
#define | EMAC_PIO_PDR PIOA_PDR |
ADC Interface Peripheral Multiplexing | |
#define | PD28_ADTRG_A 28 |
ADC trigger pin. | |
Debug Unit Peripheral Multiplexing | |
#define | PB12_DRXD_A 12 |
Debug unit receive data pin. | |
#define | PB13_DTXD_A 13 |
Debug unit transmit data pin. | |
Synchronous Serial Controller Peripheral Multiplexing | |
#define | PD2_TD0_A 2 |
Transmit data pin. | |
#define | PD3_RD0_A 3 |
Receive data pin. | |
#define | PD0_TK0_A 0 |
Transmit clock pin. | |
#define | PD4_RK0_A 4 |
Receive clock pin. | |
#define | PD1_TF0_A 1 |
Transmit frame sync. pin. | |
#define | PD5_RF0_A 5 |
Receive frame sync. pin. | |
Two Wire Interface Peripheral Multiplexing | |
#define | PA20_TWD0_A 20 |
Two wire serial data pin. | |
#define | PA21_TWCK0_A 21 |
Two wire serial clock pin. | |
#define | PB10_TWD1_A 10 |
Two wire serial data pin. | |
#define | PB11_TWCK1_A 11 |
Two wire serial clock pin. | |
Timer/Counter Peripheral Multiplexing | |
#define | PD23_TCLK0_A 23 |
Timer/counter 0 external clock input. | |
#define | PD20_TIOA0_A 20 |
Timer/counter 0 I/O line A. | |
#define | PD30_TIOB0_A 30 |
Timer/counter 0 I/O line B. | |
#define | PD29_TCLK1_A 29 |
Timer/counter 1 external clock input. | |
#define | PD21_TIOA1_A 21 |
Timer/counter 1 I/O line A. | |
#define | PD31_TIOB1_A 31 |
Timer/counter 1 I/O line B. | |
#define | PC10_TCLK2_B 10 |
Timer/counter 2 external clock input. | |
#define | PD22_TIOA2_A 22 |
Timer/counter 2 I/O line A. | |
#define | PA26_TIOB2_B 26 |
Timer/counter 2 I/O line B. | |
#define | PA0_TCLK3_B 0 |
Timer/counter 3 external clock input. | |
#define | PA1_TIOA3_B 1 |
Timer/counter 3 I/O line A. | |
#define | PA2_TIOB3_B 2 |
Timer/counter 3 I/O line B. | |
#define | PA3_TCLK4_B 3 |
Timer/counter 4 external clock input. | |
#define | PA4_TIOA4_B 4 |
Timer/counter 4 I/O line A. | |
#define | PA5_TIOB4_B 5 |
Timer/counter 4 I/O line B. | |
#define | PD9_TCLK5_B 9 |
Timer/counter 5 external clock input. | |
#define | PD7_TIOA5_B 7 |
Timer/counter 5 I/O line A. | |
#define | PD8_TIOB5_B 8 |
Timer/counter 5 I/O line B. | |
Clocks, Oscillators and PLLs Peripheral Multiplexing | |
#define | PD26_PCK0_A 26 |
Programmable clock 0 output pin. | |
#define | PE0_PCK0_B 0 |
Programmable clock 0 output pin. | |
#define | PD27_PCK1_A 27 |
Programmable clock 1 output pin. | |
#define | PE31_PCK1_B 31 |
Programmable clock 1 output pin. | |
CompactFlash Peripheral Multiplexing | |
#define | PC12_A25_CFRNW_A 12 |
Read not write pin. | |
#define | PC10_NCS4_CFCS0_A 10 |
Chip select line 0 pin. | |
#define | PC11_NCS5_CFCS1_A 11 |
Chip select line 1 pin. | |
#define | PC8_CFCE1_A 8 |
Chip enable line 1 pin. | |
#define | PC9_CFCE2_A 9 |
Chip enable line 2 pin. | |
External Bus Interface Peripheral Multiplexing | |
#define | PC16_D16_A 16 |
Data bus bit 16 pin. | |
#define | PC17_D17_A 17 |
Data bus bit 17 pin. | |
#define | PC18_D18_A 18 |
Data bus bit 18 pin. | |
#define | PC19_D19_A 19 |
Data bus bit 19 pin. | |
#define | PC20_D20_A 20 |
Data bus bit 20 pin. | |
#define | PC21_D21_A 21 |
Data bus bit 21 pin. | |
#define | PC22_D22_A 22 |
Data bus bit 22 pin. | |
#define | PC23_D23_A 23 |
Data bus bit 23 pin. | |
#define | PC24_D24_A 24 |
Data bus bit 24 pin. | |
#define | PC25_D25_A 25 |
Data bus bit 25 pin. | |
#define | PC26_D26_A 26 |
Data bus bit 26 pin. | |
#define | PC27_D27_A 27 |
Data bus bit 27 pin. | |
#define | PC28_D28_A 28 |
Data bus bit 28 pin. | |
#define | PC29_D29_A 29 |
Data bus bit 29 pin. | |
#define | PC30_D30_A 30 |
Data bus bit 30 pin. | |
#define | PC31_D31_A 31 |
Data bus bit 31 pin. | |
#define | PC6_A23_A 6 |
Address bus bit 23 pin. | |
#define | PC7_A24_A 7 |
Address bus bit 24 pin. | |
#define | PC13_NCS2_A 13 |
Negated chip select 2 pin. | |
#define | PC14_NCS3_NANDCS_A 14 |
Negated chip select 3 pin. | |
#define | PC15_NWAIT_A 15 |
External wait signal pin. | |
Advanced Interrupt Controller Peripheral Multiplexing | |
#define | PD19_FIQ_B 19 |
Fast interrupt input pin. | |
#define | PC18_IRQ_B 18 |
External interrupt input pin. | |
LCD Port definition | |
#define | LCDC_PIO_BASE PIOE_BASE |
#define | LCDC_PINS_A 0x6FEFFFDE |
#define | LCDC_PINS_B 0x10100000 |
#define | LCDC_PINS (LCDC_PINS_A | LCDC_PINS_B) |
#define | LCDC_PIO_ASR PIOE_ASR |
#define | LCDC_PIO_BSR PIOE_BSR |
#define | LCDC_PIO_PDR PIOE_PDR |
#define FLASH_BASE 0x100000UL |
Definition at line 49 of file at91sam9g45.h.
#define RAM_BASE 0x200000UL |
Definition at line 50 of file at91sam9g45.h.
#define NAND_FLASH_BASE 0x40000000 |
Definition at line 51 of file at91sam9g45.h.
#define LCDC_BASE 0x00500000 |
USB device port base address.
Definition at line 54 of file at91sam9g45.h.
#define UDP_BASE 0xFFF78000 |
USB device port base address.
Definition at line 56 of file at91sam9g45.h.
#define TC_BASE 0xFFF7C000 |
Timer/counter base address. (TC0-TC2)
Definition at line 57 of file at91sam9g45.h.
#define MCI_BASE 0xFFF80000 |
MMC/SDCard interface base address. (MCI0)
Definition at line 58 of file at91sam9g45.h.
#define TWI_BASE 0xFFF84000 |
Two-wire interface base address. (TWI0-TWI1)
Definition at line 59 of file at91sam9g45.h.
#define USART0_BASE 0xFFF8C000 |
USART 0 base address.
Definition at line 60 of file at91sam9g45.h.
#define USART1_BASE 0xFFF90000 |
USART 1 base address.
Definition at line 61 of file at91sam9g45.h.
#define USART2_BASE 0xFFF94000 |
USART 2 base address.
Definition at line 62 of file at91sam9g45.h.
#define USART3_BASE 0xFFF98000 |
USART 2 base address.
Definition at line 63 of file at91sam9g45.h.
#define SSC_BASE 0xFFF9C000 |
Serial synchronous controller base address. (SSC0-SSC1)
Definition at line 64 of file at91sam9g45.h.
#define SPI0_BASE 0xFFFA4000 |
SPI0 0 base address.
Definition at line 65 of file at91sam9g45.h.
#define SPI1_BASE 0xFFFA8000 |
SPI0 1 base address.
Definition at line 66 of file at91sam9g45.h.
#define AC97_BASE 0xFFFAC000 |
AC97 Codec interface.
Definition at line 67 of file at91sam9g45.h.
#define TSADCC_BASE 0xFFFB0000 |
Touch screen ADC controller.
Definition at line 68 of file at91sam9g45.h.
#define ISI_BASE 0xFFFB4000 |
Image sensor interface base address.
Definition at line 69 of file at91sam9g45.h.
#define PWMC_BASE 0xFFFB8000 |
PWM controller base address.
Definition at line 70 of file at91sam9g45.h.
#define EMAC_BASE 0xFFFBC000 |
EMAC base address.
Definition at line 71 of file at91sam9g45.h.
#define TRNG_BASE 0xFFFCC000 |
True random number generator.
Definition at line 72 of file at91sam9g45.h.
#define MCI1_BASE 0xFFFD0000 |
MMC/SDCard interface base address. (MCI1)
Definition at line 73 of file at91sam9g45.h.
#define TC345_BASE 0xFFFD4000 |
Timer/counter base address. (TC3-TC5)
Definition at line 74 of file at91sam9g45.h.
#define DDRSDRC1_BASE 0xFFFFE400 |
DDRSDRC1 base address.
Definition at line 77 of file at91sam9g45.h.
#define DDRSDRC0_BASE 0xFFFFE600 |
DDRSDRC0 base address.
Definition at line 78 of file at91sam9g45.h.
#define SMC_BASE 0xFFFFE800 |
SMC base address.
Definition at line 79 of file at91sam9g45.h.
#define MATRIX_BASE 0xFFFFEA00 |
MATRIX base address.
Definition at line 80 of file at91sam9g45.h.
#define DMAC_BASE 0xFFFFEC00 |
DMA controller base address.
Definition at line 81 of file at91sam9g45.h.
#define DBGU_BASE 0xFFFFEE00 |
DBGU base address.
Definition at line 82 of file at91sam9g45.h.
#define AIC_BASE 0xFFFFF000 |
AIC base address.
Definition at line 83 of file at91sam9g45.h.
#define PIOA_BASE 0xFFFFF200 |
PIO A base address.
Definition at line 84 of file at91sam9g45.h.
#define PIOB_BASE 0xFFFFF400 |
PIO B base address.
Definition at line 85 of file at91sam9g45.h.
#define PIOC_BASE 0xFFFFF600 |
PIO C base address.
Definition at line 86 of file at91sam9g45.h.
#define PIOD_BASE 0xFFFFF800 |
PIO D base address.
Definition at line 87 of file at91sam9g45.h.
#define PIOE_BASE 0xFFFFFA00 |
PIO E base address.
Definition at line 88 of file at91sam9g45.h.
#define PMC_BASE 0xFFFFFC00 |
PMC base address.
Definition at line 89 of file at91sam9g45.h.
#define RSTC_BASE 0xFFFFFD00 |
Resect controller register base address.
Definition at line 90 of file at91sam9g45.h.
#define SHDWC_BASE 0xFFFFFD10 |
Shutdown controller.
Definition at line 91 of file at91sam9g45.h.
#define RTT_BASE 0xFFFFFD20 |
Realtime timer base address.
Definition at line 92 of file at91sam9g45.h.
#define PIT_BASE 0xFFFFFD30 |
Periodic interval timer base address.
Definition at line 93 of file at91sam9g45.h.
#define WDT_BASE 0xFFFFFD40 |
Watch Dog register base address.
Definition at line 94 of file at91sam9g45.h.
#define SCKCR_BASE 0xFFFFFD50 |
Slow clock control register.
Definition at line 95 of file at91sam9g45.h.
#define GPBR_BASE 0xFFFFFD60 |
General purpose backup registers.
Definition at line 96 of file at91sam9g45.h.
#define RTC_BASE 0xFFFFFDB0 |
RTC.
Definition at line 97 of file at91sam9g45.h.
#define ECC_BASE 0xFFFFE200 |
ECC base address.
Definition at line 100 of file at91sam9g45.h.
#define PERIPH_RPR_OFF 0x00000100 |
Receive pointer register offset.
Definition at line 103 of file at91sam9g45.h.
#define PERIPH_RCR_OFF 0x00000104 |
Receive counter register offset.
Definition at line 104 of file at91sam9g45.h.
#define PERIPH_TPR_OFF 0x00000108 |
Transmit pointer register offset.
Definition at line 105 of file at91sam9g45.h.
#define PERIPH_TCR_OFF 0x0000010C |
Transmit counter register offset.
Definition at line 106 of file at91sam9g45.h.
#define PERIPH_RNPR_OFF 0x00000110 |
Receive next pointer register offset.
Definition at line 107 of file at91sam9g45.h.
#define PERIPH_RNCR_OFF 0x00000114 |
Receive next counter register offset.
Definition at line 108 of file at91sam9g45.h.
#define PERIPH_TNPR_OFF 0x00000118 |
Transmit next pointer register offset.
Definition at line 109 of file at91sam9g45.h.
#define PERIPH_TNCR_OFF 0x0000011C |
Transmit next counter register offset.
Definition at line 110 of file at91sam9g45.h.
#define PERIPH_PTCR_OFF 0x00000120 |
PDC transfer control register offset.
Definition at line 111 of file at91sam9g45.h.
#define PERIPH_PTSR_OFF 0x00000124 |
PDC transfer status register offset.
Definition at line 112 of file at91sam9g45.h.
#define PDC_RXTEN 0x00000001 |
Receiver transfer enable.
Definition at line 115 of file at91sam9g45.h.
#define PDC_RXTDIS 0x00000002 |
Receiver transfer disable.
Definition at line 116 of file at91sam9g45.h.
#define PDC_TXTEN 0x00000100 |
Transmitter transfer enable.
Definition at line 117 of file at91sam9g45.h.
#define PDC_TXTDIS 0x00000200 |
Transmitter transfer disable.
Definition at line 118 of file at91sam9g45.h.
#define DBGU_HAS_PDC |
Definition at line 121 of file at91sam9g45.h.
#define SPI_HAS_PDC |
Definition at line 122 of file at91sam9g45.h.
#define SSC_HAS_PDC |
Definition at line 123 of file at91sam9g45.h.
#define USART_HAS_PDC |
Definition at line 124 of file at91sam9g45.h.
#define USART_HAS_MODE |
Definition at line 125 of file at91sam9g45.h.
#define MCI_HAS_PDC |
Definition at line 126 of file at91sam9g45.h.
#define PMC_HAS_PLLB |
Definition at line 127 of file at91sam9g45.h.
#define PMC_HAS_MDIV |
Definition at line 128 of file at91sam9g45.h.
#define EBI_HAS_CSA |
Definition at line 129 of file at91sam9g45.h.
#define PIO_HAS_MULTIDRIVER |
Definition at line 132 of file at91sam9g45.h.
#define PIO_HAS_PULLUP |
Definition at line 133 of file at91sam9g45.h.
#define PIO_HAS_PERIPHERALSELECT |
Definition at line 134 of file at91sam9g45.h.
#define PIO_HAS_OUTPUTWRITEENABLE |
Definition at line 135 of file at91sam9g45.h.
